AB239749

PD-L1 Antibody Panel (28-8, 73-10, SP142, CAL10)

Recombinant
What is this?

Be the first to review this product! Submit a review

(4 Publications)

PD-L1 Antibody Panel (28-8, 73-10, SP142, CAL10) (ab239749) is part of our antibody panels range. Abcam offers high-quality biological reagents and tools including antibodies, proteins, assays, cell lines and lysates.

2 Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - PD-L1 Antibody Panel (28-8, 73-10, SP142, CAL10) (AB239749)

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - PD-L1 Antibody Panel (28-8, 73-10, SP142, CAL10) (AB239749)

IHC image of ab228462 staining PD-L1 in human tonsil formalin fixed paraffin embedded tissue sections*, performed on a Leica BOND RX (standard Protocol F, Polymer Refine kit). The section was pre-treated using heat mediated antigen retrieval with EDTA buffer (pH9, epitope retrieval solution 2) for 30 mins at 98°C. The section was then incubated with ab228462, 1/400 working dilution, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system for 8 minutes at room temperature. DAB was used as the chromogen for 10 minutes at room temperature. The section was then counterstained with hematoxylin, blued, dehydrated, cleared and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - PD-L1 Antibody Panel (28-8, 73-10, SP142, CAL10) (AB239749)

IHC image of ab205921 staining PD-L1 in human tonsil formalin fixed paraffin embedded tissue sections*, performed on a Leica BOND RX (Polymer Refine kit). The section was pre-treated using heat mediated antigen retrieval with EDTA buffer (pH9, epitope retrieval solution 2) for 30 mins at 98°C. The section was then incubated with ab205921, 5μg/ml working concentration, for 60 mins at room temperature and detected using an HRP conjugated compact polymer system for 8 minutes at room temperature. DAB was used as the chromogen for 10 minutes at room temperature. The section was then counterstained with hematoxylin, blued, dehydrated, cleared and mounted with DPX.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

Key facts

style

left-column

style

left-column

Product details

PD-L1 Antibody Panel ab239749 is a panel of 4 recombinant rabbit monoclonal antibodies against human PD-L1. They are provided in small sizes to allow you to easily evaluate which is the best PD-L1 antibody for your human PD-L1 research assay needs. For guidelines on how to use each antibody within the panel, please consult the individual datasheet for each antibody.Panel contains: - Rabbit monoclonal [73-10] to PD-L1 (10 µL) ab228415 - Rabbit monoclonal [28-8] to PD-L1 (10 µL) ab205921 - Rabbit monoclonal [SP142] to PD-L1 (25 µL) ab228462 - Rabbit monoclonal [CAL10] to PD-L1 (10 µL) ab237726See our to help you find the optimal recombinant monoclonal PD-L1 antibody clone for your research.

All of the antibodies are ideal for use with immunohistochemistry with paraffin-embedded / formalin-fixed sections (as well as with other techniques).

Explore our range of antibody sample panels designed to provide you with a variety of trial-size antibodies in a convenient and cost-effective format.

Carrier-free formulations of our recombinant antibodies are also available for easy conjugation to labels of your choice and for multiplex applications. Use our intuitive search and select carrier-free or your label of choice. For bespoke conjugations or large volumes email bespoke@abcam.com.

style

left-column

What's included?

{ "values": { "1Kit": { "sellingSize": "1 Kit", "publicAssetCode":"ab239749-1Kit", "assetComponentDetails": [ { "size":"1 x 25 µL", "name":"Anti-PD-L1 antibody [SP142] - C-terminal", "number":"AB239749-CMP01", "productcode":"AB228462" }, { "size":"1 x 10 µL", "name":"Anti-PD-L1 antibody [73-10]", "number":"AB239749-CMP03", "productcode":"AB228415" }, { "size":"1 x 10 µL", "name":"Anti-PD-L1 antibody [CAL10]", "number":"AB239749-CMP04", "productcode":"AB237726" }, { "size":"1 x 10 µL", "name":"Anti-PD-L1 antibody [28-8]", "number":"AB239749-CMP02", "productcode":"AB205921" } ] } } }

style

left-column

Properties and storage information

Shipped at conditions

Blue Ice

Appropriate short-term storage conditions

-20°C

Appropriate long-term storage conditions

-20°C

Storage information

-20°C

style

left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

PD-L1 also known as Programmed Death-Ligand 1 or CD274 is a protein involved in immune modulation. Mechanically PD-L1 interacts with its receptors particularly PD-1 to regulate cellular immune responses. This transmembrane protein has a calculated molecular weight of approximately 33 kDa. PD-L1 is expressed on various cell types including tumor cells and immune cells such as dendritic cells macrophages and B cells. Its expression is often upregulated in response to inflammatory cytokines.

Biological function summary

PD-L1 plays a central role in immune evasion mechanisms utilized by tumors. It is not part of a larger protein complex but directly interacts with PD-1 and CD80. When PD-L1 binds to PD-1 it sends inhibitory signals leading to decreased T cell activation and proliferation allowing cancer cells to avoid immune destruction. PD-L1 expression provides a mechanism for tumors to suppress immune surveillance facilitating tumor progression.

Pathways

PD-L1 is integral to the immune checkpoint pathway which is an important regulator of immune response. The interaction between PD-L1 and PD-1 provides a mechanism for immune tolerance which is part of the broader adaptive immune system pathway. PD-L1 is related to other immune checkpoint proteins such as CTLA-4 in its function to limit autoreactivity and promote immune homeostasis.

PD-L1 is most associated with cancer particularly in tumors such as melanoma and non-small cell lung cancer. PD-L1 expression on tumor cells often correlates with poor prognosis. PD-L1 directly interacts with PD-1 in these cancers a target for immunotherapies such as checkpoint inhibitors which aim to block this interaction and restore immune activity against tumors. PD-L1 involvement extends to autoimmune disorders where altered expression can impact tolerance and lead to immune-related tissue damage.

style

left-column

Product protocols

Visit the General protocols
Visit the Troubleshooting

style

left-column

Target data

style

left-column

Publications (4)

Recent publications for all applications. Explore the full list and refine your search

Frontiers in medicine 12:1614012 PubMed40959429

2025

A mitochondrial ferroptosis-related gene signature predicts prognosis and immune landscape in colon cancer.

Applications

Unspecified application

Species

Unspecified reactive species

Hou Wang

Pharmaceutics 14: PubMed36297644

2022

Autologous Genetically Enriched Leucoconcentrate in the Preventive and Acute Phases of Stroke Treatment in a Mini-Pig Model.

Applications

Unspecified application

Species

Unspecified reactive species

Zufar Safiullov,Andrei Izmailov,Mikhail Sokolov,Vage Markosyan,Grayr Kundakchan,Ravil Garifulin,Maksim Shmarov,Boris Naroditsky,Denis Logunov,Rustem Islamov

Acta obstetricia et gynecologica Scandinavica 101:1007-1016 PubMed35689468

2022

PD-L1 in gestational trophoblastic disease: an antibody evaluation.

Applications

Unspecified application

Species

Unspecified reactive species

Yvonne M Hoeijmakers,Michiel Simons,Johan Bulten,Mark A J Gorris,Petronella B Ottevanger,I Jolanda M de Vries,Fred C G J Sweep

Molecular cancer 20:11 PubMed33413365

2021

A comparability study of natural and deglycosylated PD-L1 levels in lung cancer: evidence from immunohistochemical analysis.

Applications

IHC-P

Species

Human

Jie Mei,Junying Xu,Xuejing Yang,Dingyi Gu,Weijian Zhou,Huiyu Wang,Chaoying Liu

View all publications
