Abcam's Mitochondrial Staining Reagent - NIR | Cytopainter (ab176833) is part of a series of new fluorogenic probes to label mitochondria of live cells.


Images

Fluorescence Microscopy - Mitochondrial Staining Reagent - NIR - Cytopainter (AB176833), expandable thumbnail
  • Fluorescence Microscopy - Mitochondrial Staining Reagent - NIR - Cytopainter (AB176833), expandable thumbnail

Publications

Key facts

Sample types
Suspension cells, Adherent cells
Assay type
Cell-based (qualitative)
Reactive species
Mammals

Associated Products

Select an associated product type

1 product for Alternative Product

What's included?

500 Test
Components
CytoPainter MitoNIR Indicator Reagent
1 x 500 Test

Recommended products

Abcam's Mitochondrial Staining Reagent - NIR | Cytopainter (ab176833) is part of a series of new fluorogenic probes to label mitochondria of live cells.

Key facts

Sample types
Suspension cells, Adherent cells
Assay type
Cell-based (qualitative)
Reactive species
Mammals
Assay Platform
Fluorescence microscope

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage conditions
-20°C
Appropriate long-term storage conditions
-20°C
Storage information
-20°C

Notes

Abcam's Mitochondrial Staining Reagent - NIR | Cytopainter (ab176833) is part of a series of new fluorogenic probes to label mitochondria of live cells. The proprietary mitochondria dye selectively accumulates in mitochondria probably via the mitochondrial membrane potential gradient. The mitochondrial indicator is a hydrophobic compound that easily permeates intact live cells and becomes trapped in mitochondria after it gets into cells. The fluorescent mitochondrial indicator is retained in mitochondria for a long time since it carries a cell-retaining group. This key feature significantly increases the staining efficiency; make it useful for a variety of studies, including cell adhesion, chemotaxis, multidrug resistance, cell viability, apoptosis and cytotoxicity.

Review other dyes and kits for mitochondrial staining, or the live cell staining fluorescent dyes guide

Mitochondria are membrane-enclosed organelles found in most eukaryotic cells. Mitochondria are sometimes described as "cellular power plants" because they generate most of the cellular supply of ATP. In addition to supplying cellular energy, mitochondria are involved in a range of other processes, such as signaling, cellular differentiation, cell death, as well as the control of the cell cycle and cell growth. Mitochondria have been implicated in several human diseases, including mitochondrial disorders and cardiac dysfunction, and may play a role in the aging process. Although most of a cellular DNA is contained in the cell nucleus, the mitochondrion has its own independent genome.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

2 product images

  • Fluorescence Microscopy - Mitochondrial Staining Reagent - NIR - Cytopainter (ab176833), expandable thumbnail

    Fluorescence Microscopy - Mitochondrial Staining Reagent - NIR - Cytopainter (ab176833)

    HeLa cells mitochondria were stained with Abcam's CytoPainter MitoNIR Indicator Reagent (ab176833), and nuclei were stained with Hoechst 33342 in a Costar black 96-well plate.

  • Fluorescence Microscopy - Mitochondrial Staining Reagent - NIR - Cytopainter (ab176833), expandable thumbnail

    Fluorescence Microscopy - Mitochondrial Staining Reagent - NIR - Cytopainter (ab176833)

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
