MW 747.1 Da, Purity >99%. Ca2+ ionophore. Useful when calcium-dose response data are not required. Ion specificity Mn2+>Ca2+>Mg2+>Sr2+>Ba2+.

Be the first to review this product! Submit a review

Images

Chemical Structure - Ionomycin Ca2+ Salt, Ca2+ ionophore (AB120116), expandable thumbnail
  • Immunoprecipitation - Ionomycin Ca2+ Salt, Ca2+ ionophore (AB120116), expandable thumbnail
  • Flow Cytometry (Intracellular) - Ionomycin Ca2+ Salt, Ca2+ ionophore (AB120116), expandable thumbnail
  • Immunoprecipitation - Ionomycin Ca2+ Salt, Ca2+ ionophore (AB120116), expandable thumbnail
  • Flow Cytometry (Intracellular) - Ionomycin Ca2+ Salt, Ca2+ ionophore (AB120116), expandable thumbnail

Publications

Key facts

CAS number
56092-82-1
Purity
> 99%
Form
Solid
Source
Streptomyces conglobatus
Molecular weight
747.1 Da
Molecular formula
C41H70CaO9
PubChem identifier
6446270
Nature
Native

Target data

Recommended products

MW 747.1 Da, Purity >99%. Ca2+ ionophore. Useful when calcium-dose response data are not required. Ion specificity Mn2+>Ca2+>Mg2+>Sr2+>Ba2+.

Key facts

Purity
> 99%
Source
Streptomyces conglobatus
PubChem identifier
6446270
Biochemical name
Ionomycin calcium
Biological description

Ca2+ ionophore. Useful when calcium-dose response data are not required. Ion specificity Mn2+>Ca2+>Mg2+>Sr2+>Ba2+.

Canonical SMILES
CC(CCC(=O)[O-])CC(C)CC(C)C(=O)C=C(C(C)CC(C)CC=CC(C)C(C(C)C(CC1CCC(O1)(C)C2CCC(O2)(C)C(C)O)O)O)[O-].[Ca+2]
Isomeric SMILES
C[C@H](CCC(=O)[O-])C[C@H](C)C[C@H](C)C(=O)/C=C(/[C@H](C)C[C@H](C)C/C=C/[C@@H](C)[C@H]([C@@H](C)[C@H](C[C@@H]1CC[C@@](O1)(C)[C@H]2CC[C@@](O2)(C)[C@@H](C)O)O)O)\[O-].[Ca+2]
InChI
InChI=1S/C41H72O9.Ca/c1-25(21-29(5)34(43)24-35(44)30(6)22-27(3)20-26(2)14-15-38(46)47)12-11-13-28(4)39(48)31(7)36(45)23-33-16-18-41(10,49-33)37-17-19-40(9,50-37)32(8)42;/h11,13,24-33,36-37,39,42-43,45,48H,12,14-23H2,1-10H3,(H,46,47);/q;+2/p-2/b13-11+,34-24-;/t25-,26-,27+,28-,29-,30+,31+,32-,33+,36+,37-,39-,40+,41+;/m1./s1
InChIKey
WKRWUYKLUMMAKG-WYGBAUISSA-L
IUPAC name
calcium;(4R,6S,8S,10Z,12R,14R,16E,18R,19R,20S,21S)-19,21-dihydroxy-22-[(2S,5S)-5-[(2R,5S)-5-[(1R)-1-hydroxyethyl]-5-methyloxolan-2-yl]-5-methyloxolan-2-yl]-4,6,8,12,14,18,20-heptamethyl-11-oxido-9-oxodocosa-10,16-dienoate

Storage

Shipped at conditions
Ambient - Can Ship with Ice
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
+4°C
Storage information
Store under desiccating conditions, The product can be stored for up to 12 months

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

8 product images

  • Chemical Structure - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Chemical Structure - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    2D chemical structure image of ab120116, Ionomycin Ca2+ Salt, Ca2+ ionophore

  • Immunoprecipitation - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Immunoprecipitation - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    Histone H3 (citrulline R8) was immunoprecipitated from 0.35 mg of HEK-293T (Human epithelial cell line from embryonic kidney) transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate with Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] ab219406 at 1/30 dilution.

    Western blot was performed from the immunoprecipitate using Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] ab219406 at 1/1000 dilution.

    VeriBlot for IP Detection Reagent (HRP) (VeriBlot for IP Detection Reagent (HRP) ab131366), was used for detection at 1/10000 dilution.

    Lane 1: HEK-293T transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate 10 μg (Input).
    Lane 2: Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] ab219406 IP in HEK-293T transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate.
    Lane 3: Rabbit monoclonal IgG (Rabbit IgG, monoclonal [EPR25A] - Isotype Control ab172730) instead of Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] ab219406 in HEK-293T transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate.

    Blocking and dilution buffer: 5% NFDM/TBST.

    All lanes: Immunoprecipitation - Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] (Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] ab219406)

    Predicted band size: 15 kDa

    Exposure time: 1s

  • Flow Cytometry (Intracellular) - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Flow Cytometry (Intracellular) - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    Flow cytometric analysis of 4% paraformaldehyde-fixed HEK-293T (Human epithelial cell line from embryonic kidney) transfected with empty vector (left panel) or PADI4 (WT, right panel), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, labeling Histone H3 (citrulline R8) with Anti-Histone H3 (citrulline R8) antibody [EPR20358-13] ab219406 at 1/500 dilution, followed by Goat anti rabbit IgG (Alexa Fluor® 647) at 1/2000 dilution.

    Positive signal is obtained from HEK-293T cells transfected with WT PADI4 treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours.

  • Immunoprecipitation - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Immunoprecipitation - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    Histone H3 (citrulline R17) was immunoprecipitated from 0.35 mg of HEK-293T (Human epithelial cell line from embryonic kidney) transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate with Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] ab219407 at 1/30 dilution.

    Western blot was performed from the immunoprecipitate using Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] ab219407 at 1/1000 dilution.

    VeriBlot for IP secondary antibody (HRP) (VeriBlot for IP Detection Reagent (HRP) ab131366), was used for detection at 1/10000 dilution.

    Lane 1: HEK-293T transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate 10 μg (Input).
    Lane 2: Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] ab219407 IP in HEK-293T transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate.
    Lane 3: Rabbit monoclonal IgG (Rabbit IgG, monoclonal [EPR25A] - Isotype Control ab172730) instead of Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] ab219407 in HEK-293T transfected with PADI4 (WT), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, whole cell lysate.

    Blocking/Dilution buffer: 5% NFDM/TBST.

    All lanes: Immunoprecipitation - Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] (Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] ab219407)

    Predicted band size: 15 kDa

    Exposure time: 1s

  • Flow Cytometry (Intracellular) - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Flow Cytometry (Intracellular) - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    Flow cytometric analysis of 4% paraformaldehyde-fixed HEK-293T (Human epithelial cell line from embryonic kidney) transfected with empty vector (left panel) or PADI4 (WT, right panel), then treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours, labeling Histone H3 (citrulline R17) with Anti-Histone H3 (citrulline R17) antibody [EPR20358-120] ab219407 at 1/500 dilution, followed by Goat anti rabbit IgG (Alexa Fluor® 647) at 1/2000 dilution.

    Positive signal is obtained from HEK-293T cells transfected with WT PADI4 treated with 10mM CaCl2 and 10μM Ionomycin (ab120116) for 2 hours.

  • Functional Studies - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Functional Studies - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    ab58668 staining ATF3 in A549 cells treated with ionomycin Ca2+ salt (ab120116), by ICC/IF. Increase in ATF3 expression correlates with increased concentration of ionomycin Ca2+ salt, as described in literature.
    The cells were incubated at 37°C for 2h in media containing different concentrations of ab120116 (ionomycin Ca2+ salt) in DMSO, fixed with 4% formaldehyde for 10 minutes at room temperature and blocked with PBS containing 10% goat serum, 0.3 M glycine, 1% BSA and 0.1% tween for 2h at room temperature. Staining of the treated cells with ab58668 (10 μg/ml) was performed overnight at 4°C in PBS containing 1% BSA and 0.1% tween. A DyLight 488 goat anti-mouse polyclonal antibody (Goat Anti-Mouse IgG H&L (DyLight® 488) preadsorbed ab96879) at 1/250 dilution was used as the secondary antibody. Nuclei were counterstained with DAPI and are shown in blue.

  • Sandwich ELISA - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Sandwich ELISA - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    Sandwich ELISA - IFN gamma Human ELISA Kit (Human IFN gamma ELISA Kit ab46025)

    Jurkat were stimulated for 48 hours with 50 ng x mL-1 of PMA (Phorbol 12-myristate 13-acetate (PMA), PKC activator ab120297) and 1 uM Ionomycin (ab120116) and PBMCs were stimulated for 48 hours with 2 % PHA-M (LifeTechnologies). Cell free supernatants were tested, showing results after background signal was subtracted (duplicates +/- SD).

  • Western blot - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116), expandable thumbnail

    Western blot - Ionomycin Ca2+ Salt, Ca2+ ionophore (ab120116)

    Blocking and diluting buffer and concentration: 5% NFDM/TBST.

    The expression profile/ molecular weight observed is consistent with what has been described in the literature (PMID:23129404 and PMID: 6423641).

    In Western blot, Anti-GAPDH antibody [EPR16891] - Loading Control (Anti-GAPDH antibody [EPR16891] - Loading Control ab181602) staining at 1/200000 dilution.

    All lanes: Western blot - Anti-Interferon gamma antibody [RM1245] (Anti-Interferon gamma antibody [RM1245] ab322926) at 1/1000 dilution

    Lane 1: Untreated No-GFP-CD16.NK-92 (CD16 ectopically expressed natural killer(NK-92®) cell with no GFP tag) whole cell lysate at 20 µg

    Lane 2: No-GFP-CD16.NK-92 treated with 80nM PMA(TPA) (Phorbol 12-myristate 13-acetate (PMA), PKC activator ab120297) and 3uM Ionomycin (ab120116) for 5 hours, 300 ng/ml BFA was added for last 4 hours whole cell lysate at 20 µg

    Secondary

    All lanes: Western blot - Goat Anti-Rabbit IgG H&L (HRP) (Goat Anti-Rabbit IgG H&L (HRP) ab97051) at 1/20000 dilution

    Observed band size: 17 kDa, 19 kDa, 23 kDa, 36 kDa

    Exposure time: 92s

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
