AB120241

U0126, Selective MKK inhibitor

Be the first to review this product! Submit a review

|

(23 Publications)

MW 380.5 Da, Purity >98%. Selective non-competitive inhibitor of MAP kinase kinase (MKK). Inhibits MKK1, MKK2 (IC50 values of 0.07 and 0.06 μM, respectively) and MKK5 with little or no effect on a wide range of other kinases. Centrally active following systemic administration in vivo.

View Alternative Names

CFC syndrome, CFC4, Cardiofaciocutaneous syndrome, Dual specificity mitogen-activated protein kinase kinase 1, Dual specificity mitogen-activated protein kinase kinase 2, ERK activator kinase 1, ERK activator kinase 2, FLJ26075, MAP kinase kinase 1, MAP kinase kinase 2, MAP kinase/Erk kinase 1, MAP2K1, MAP2K2, MEK 1, MEK 2, MEKK 1, MKK 1, MKK 2, MP2K1_HUMAN, Microtubule associated protein kinase kinase 2, Mitogen Activated Protein Kinase Kinase 1, Mitogen activated protein kinase kinase 2, OTTHUMP00000165826, OTTHUMP00000165827, PRKMK 1, PRKMK 2, Protein kinase mitogen activated kinase 1 (MAP kinase kinase 1), protein kinase mitogen-activated kinase 1

2 Images
Western blot - U0126, Selective MKK inhibitor (AB120241)
  • WB

Unknown

Western blot - U0126, Selective MKK inhibitor (AB120241)

Performed under reducing conditions; Samples loaded at 30 µg/lane. Membrane blocking and secondary antibody incubation performed in 5% milk/PBST. Primary antibody incubation performed in 5% BSA/PBST.

Lane 1 : Marker
Lane 2 : A431 lysate starved
Lane 3 : A431 lysate starved treated with 100 ng/mL of EGF for 30 min
Lane 4 : A431 lysate starved and pretreated for 2 hours with 10µM U0126 (ab120241)
Lane 5 : A431 lysate starved and pretreated for 2 hours with 30µM Ly294002 (ab120243)

Primary : AKT/MAPK signaling pathway antibody cocktail at 1/250 dilution

Secondary : HRP conjugated Goat anti-Rabbit secondary antibody at 1 : 10,000 dilution.

Observed bands :
RSK1p90 (pS380) band size : 83 kDa
AKT1 (pS473) band size : 56 kDa
ERK1 (pY204) and ERK2 (pY187) band size : 43 kDa
RPS6 (pS235/236) band size : 31 kDa
Rab11a band size : 24 kDa
Unknown band : 130kDa
Performed under reducing conditions; Samples l

false

Chemical Structure - U0126, Selective MKK inhibitor (AB120241)
  • Chemical Structure

Lab

Chemical Structure - U0126, Selective MKK inhibitor (AB120241)

2D chemical structure image of ab120241, U0126, Selective MKK inhibitor

Key facts

CAS number

109511-58-2

Purity

>98%

Form

Solid

form

Molecular weight

380.5 Da

Molecular formula

C<sub>1</sub><sub>8</sub>H<sub>1</sub><sub>6</sub>N<sub>6</sub>S<sub>2</sub>

PubChem

3006531

Nature

Synthetic

Solubility

Soluble in DMSO to 100 mM

Biochemical name

1,4-Diamino-2,3-dicyano-1,4-bis(o-aminophenylmercapto)butadiene

Biological description

Selective non-competitive inhibitor of MAP kinase kinase (MKK). Inhibits MKK1, MKK2 (IC50 values of 0.07 and 0.06 μM, respectively) and MKK5 with little or no effect on a wide range of other kinases. Centrally active following systemic administration in vivo.

Canonical smiles

C1=CC=C(C(=C1)N)SC(=C(C#N)C(=C(N)SC2=CC=CC=C2N)C#N)N

Isomeric smiles

C1=CC=C(C(=C1)N)S/C(=C(/C(=C(/SC2=CC=CC=C2N)\N)/C#N)\C#N)/N

InChi

InChI=1S/C18H16N6S2/c19-9-11(17(23)25-15-7-3-1-5-13(15)21)12(10-20)18(24)26-16-8-4-2-6-14(16)22/h1-8H,21-24H2/b17-11+,18-12+

InChiKey

DVEXZJFMOKTQEZ-JYFOCSDGSA-N

IUPAC Name

(2Z,3Z)-2,3-bis[amino-(2-aminophenyl)sulfanylmethylidene]butanedinitrile

Properties and storage information

Shipped at conditions
Ambient - Can Ship with Ice
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
+4°C
Storage information
Store under desiccating conditions|The product can be stored for up to 12 months

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

MEK1 and MEK2 also known as MAP2K1 and MAP2K2 are protein kinases with molecular weights approximately 43 kDa and 45 kDa respectively. These proteins belong to the MAPKK family and function as dual-specificity kinases phosphorylating both serine/threonine and tyrosine residues. MEK1 and MEK2 are expressed ubiquitously in human tissues indicating their widespread role in cellular processes. Their main mechanical role is to activate ERK1/2 which is important in various signal transduction pathways. As part of the MAPK/ERK cascade MEK proteins serve as a conduit for signals from the membrane to the nucleus.
Biological function summary

MEK1 and MEK2 participate in transmitting signals that regulate cell proliferation differentiation and survival. Their role in these processes involves forming part of a signaling complex that includes RAF kinases and ERK1/2. This assembly ensures precise regulation of cell cycle events and growth responses to extracellular signals. The activity of MEK proteins allows cells to modulate responses to external growth factors and stress maintaining cellular homoeostasis. Given their involvement in key biological processes MEK1 and MEK2 are essential for normal cellular function.

Pathways

MEK1 and MEK2 play significant roles in the MAPK/ERK and PI3K/Akt pathways. Their activation by upstream kinases like RAF enables downstream phosphorylation and activation of ERK1/2 key regulators of gene expression and cellular activities. The MAPK/ERK pathway interconnects with other pathways such as the PI3K/Akt pathway creating a network of signals important for cell fate decisions. Through these pathways MEK1 and MEK2 interact with a variety of proteins including PI3K and Akt linking growth factor signaling to broader cellular outcomes.

MEK1 and MEK2 exhibit distinct connections to cancers and RASopathies. Aberrant activation of the MAPK/ERK pathway often through mutations in MEK1/2 contributes to oncogenesis in several cancer types including melanoma and colorectal cancer. Additionally changes in these proteins are implicated in RASopathies such as Noonan syndrome a series of genetic disorders caused by dysregulation of the RAS-MAPK pathway. In these conditions MEK proteins often show altered interactions with other proteins like RAF and RAS correlating with disease pathogenesis and progression.

Product protocols

Publications (23)

Recent publications for all applications. Explore the full list and refine your search

Acta pharmaceutica Sinica. B 14:635-652 PubMed38322333

2024

mediates memory decline by targeting MKP-1 to reduce surface GluA1-containing AMPA receptors in a mouse model of Alzheimer's disease.

Applications

Unspecified application

Species

Unspecified reactive species

Man Luo,Yayan Pang,Junjie Li,Lilin Yi,Bin Wu,Qiuyun Tian,Yan He,Maoju Wang,Lei Xia,Guiqiong He,Weihong Song,Yehong Du,Zhifang Dong

Journal of neuropathology and experimental neurology 83:161-167 PubMed38263262

2024

Angiogenic responses are enhanced by recombinant human erythropoietin in a model of periventricular white matter damage of neonatal rats through EPOR-ERK1 signaling.

Applications

Unspecified application

Species

Unspecified reactive species

Lihua Zhu,Qichao Yuan,Chunping Jing,Lingxian Sun,Li Jiang

Cellular and molecular life sciences : CMLS 80:224 PubMed37480481

2023

Transcriptomic landscape reveals germline potential of porcine skin-derived multipotent dermal fibroblast progenitors.

Applications

Unspecified application

Species

Unspecified reactive species

Wen-Xiang Liu,Chun-Xiao Li,Xin-Xiang Xie,Wei Ge,Tian Qiao,Xiao-Feng Sun,Wei Shen,Shun-Feng Cheng

Adipocyte 11:315-324 PubMed35531859

2022

Oncostatin M promotes lipolysis in white adipocytes.

Applications

Unspecified application

Species

Unspecified reactive species

Pim P van Krieken,Julian Roos,Pamela Fischer-Posovszky,Stephan Wueest,Daniel Konrad

Molecular medicine reports 24: PubMed34590154

2021

MAPK inhibitors protect against early‑stage osteoarthritis by activating autophagy.

Applications

Unspecified application

Species

Unspecified reactive species

Chun-Na Lan,Wei-Jun Cai,Jie Shi,Zhong-Jie Yi

Molecular metabolism 54:101341 PubMed34547509

2021

Oncostatin M suppresses browning of white adipocytes via gp130-STAT3 signaling.

Applications

Unspecified application

Species

Unspecified reactive species

Pim P van Krieken,Timothy S Odermatt,Marcela Borsigova,Matthias Blüher,Stephan Wueest,Daniel Konrad

Nature communications 12:1910 PubMed33771995

2021

Cardiac macrophages prevent sudden death during heart stress.

Applications

Unspecified application

Species

Unspecified reactive species

Junichi Sugita,Katsuhito Fujiu,Yukiteru Nakayama,Takumi Matsubara,Jun Matsuda,Tsukasa Oshima,Yuxiang Liu,Yujin Maru,Eriko Hasumi,Toshiya Kojima,Hiroshi Seno,Keisuke Asano,Ayumu Ishijima,Naoki Tomii,Masatoshi Yamazaki,Fujimi Kudo,Ichiro Sakuma,Ryozo Nagai,Ichiro Manabe,Issei Komuro

The international journal of biochemistry & cell b 112:123-133 PubMed31121283

2019

Studying the ShcD and ERK interaction under acute oxidative stress conditions in melanoma cells.

Applications

Unspecified application

Species

Unspecified reactive species

Samrein B M Ahmed,Sara Amer,Mira Emad,Mohamed Rahmani,Sally A Prigent

Cell reports 27:1712-1725.e6 PubMed31067458

2019

Linking YAP to Müller Glia Quiescence Exit in the Degenerative Retina.

Applications

Unspecified application

Species

Unspecified reactive species

Annaïg Hamon,Diana García-García,Divya Ail,Juliette Bitard,Albert Chesneau,Deniz Dalkara,Morgane Locker,Jérôme E Roger,Muriel Perron

Journal of cellular biochemistry : PubMed30793366

2019

Metformin promotes survivin degradation through AMPK/PKA/GSK-3β-axis in non-small cell lung cancer.

Applications

Unspecified application

Species

Unspecified reactive species

Zhuang Luo,Wei Chen,Wenjuan Wu,Wei Luo,Tingting Zhu,Gang Guo,Liyan Zhang,Chu Wang,Min Li,Shaoqing Shi
View all publications

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.
For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
