AB267628

Human Calprotectin ELISA kit (S100A8/S100A9)

Be the first to review this product! Submit a review

|

(8 Publications)

Human Calprotectin ELISA kit (S100A8/S100A9) is a sandwich ELISA designed to quantify Human Calprotectin (S100A8/S100A9) with a sensitivity of 35 pg/mL.

- Colorimetric sandwich ELISA - 450 nm readout - works on any plate reader
- Wide dynamic range - quantifies 32.77 - 8000 pg/mL

View Alternative Names

CAGB, CFAG, MRP14, S100A9, Protein S100-A9, Calgranulin-B, Calprotectin L1H subunit, Leukocyte L1 complex heavy chain, Migration inhibitory factor-related protein 14, S100 calcium-binding protein A9, MRP-14, p14

1 Images
Sandwich ELISA - Human Calprotectin ELISA kit (S100A8/S100A9) (AB267628)
  • sELISA

Supplier Data

Sandwich ELISA - Human Calprotectin ELISA kit (S100A8/S100A9) (AB267628)

This standard curve is for demonstration only. A standard curve must be run with each assay.

Key facts

Detection method

Colorimetric

Sample types

Plasma, Cell culture supernatant, Serum

Reacts with

Human

Assay type

Sandwich (quantitative)

Sensitivity

= 35 pg/mL

Range

32.77 - 8000 pg/mL

Assay Platform

Pre-coated microplate (12 x 8 well strips)

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Reactivity", "Dilution Info", "Notes"] }, "values": { "sELISA": { "reactivity":"TESTED_AND_REACTS", "dilution-info":"", "notes":"<p></p>" } } }

Product details

Human Calprotectin ELISA kit (S100A8/S100A9) ab267628 is a sandwich ELISA to measure Human Calprotectin (S100A8/S100A9) in serum, plasma, cell culture supernatant with a sensitivity of 35 pg/ml.

How the assay works

This assay employs an antibody specific for human Calprotectin coated on a 96-well plate. Standards and samples are pipetted into the wells and Calprotectin present in a sample is bound to the wells by the immobilized antibody. The wells are washed and biotinylated anti-human Calprotectin antibody is added. After washing away unbound biotinylated antibody, HRP-conjugated streptavidin is pipetted to the wells. The wells are again washed, a TMB substrate solution is added to the wells and color develops in proportion to the amount of Calprotectin bound. The Stop Solution changes the color from blue to yellow, and the intensity of the color is measured at 450 nm.

Assay Specificity

Our ELISA kits are rigorously validated to ensure the highest level of consistency and reproducibility. Please check the protocol booklet for more details

Human Calprotectin ELISA kit (S100A8/S100A9) ab267628 protocol summary

1. Add 100 μL standard or sample to each well. Incubate 2.5 hours at room temperature.
Add 100 μL prepared biotin antibody to each well. Incubate 1 hour at room temperature.
Add 100 μL prepared Streptavidin solution. Incubate 45 minutes at room temperature.
2. Add 100 μL TMB One-Step Substrate Reagent to each well. Incubate 30 minutes at room temperature.
3. Add 50 μL Stop Solution to each well. Read at 450 nm immediately.

Precision

[ { "reproducibilityType": "Inter", "sample": "Overall", "replicates": 0, "mean": null, "standardDeviation": null, "coefficientOfVariability": "< 12" }, { "reproducibilityType": "Intra", "sample": "Overall", "replicates": 0, "mean": null, "standardDeviation": null, "coefficientOfVariability": "< 10" } ]

Recovery

[ { "sample": "Serum", "range": "107 - 117 %", "average": "= 112.8" }, { "sample": "Plasma", "range": "88 - 107 %", "average": "= 97.34" }, { "sample": "Cell culture media", "range": "106 - 124 %", "average": "= 114.4" } ]

What's included?

{ "values": { "1x96Tests": { "sellingSize": "1 x 96 Tests", "publicAssetCode":"ab267628-1x96Tests", "assetComponentDetails": [ { "size":"1 x 15 mL", "name":"5X Assay Diluent", "number":"AB267628-CMP02", "productcode":"" }, { "size":"1 x 25 mL", "name":"20X Wash Buffer", "number":"AB267628-CMP06", "productcode":"" }, { "size":"1 x 200 µL", "name":"900X HRP-Streptavidin Concentrate", "number":"AB267628-CMP07", "productcode":"" }, { "size":"1 x 8 mL", "name":"Stop Solution", "number":"AB267628-CMP04", "productcode":"" }, { "size":"1 x 1 Unit", "name":"Anti-Human Calprotectin coated Microplate (12 x 8 wells)", "number":"AB267628-CMP08", "productcode":"" }, { "size":"2 x 1 Vial", "name":"Biotinylated Anti-Human Calprotectin Detection Antibody", "number":"AB267628-CMP01", "productcode":"" }, { "size":"2 x 1 Vial", "name":"Human Calprotectin Standard (Lyophilized)", "number":"AB267628-CMP03", "productcode":"" }, { "size":"1 x 12 mL", "name":"TMB Substrate Solution", "number":"AB267628-CMP05", "productcode":"" } ] } } }

Properties and storage information

Shipped at conditions
Blue Ice
Appropriate short-term storage conditions
-20°C
Appropriate long-term storage conditions
-20°C
Storage information
-20°C

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

S100A8 and S100A9 often known together as calprotectin are proteins that form a heterodimer and function as a complex. Each protein has a mass of approximately 10.8 kDa for S100A8 and 13.2 kDa for S100A9. These proteins express mainly in neutrophils and monocytes acting as calcium-binding proteins. Their expression can modulate various cellular functions like migration and inflammation responses.
Biological function summary

Calprotectin serves as an important player in the immune response. This complex possesses antimicrobial properties and contributes to the body's defense by modulating inflammation. It binds to zinc and manganese to deprive pathogens of essential nutrients an action called nutrient bioavailability restriction. In immune cells calprotectin's presence signals the activation and recruitment of further immune components.

Pathways

S100A8 and S100A9 influence the NF-kB signaling pathway which governs immune responses and inflammation. Their function affects other pathways such as MAPK by mediating pro-inflammatory cytokines' production and release. These proteins often engage with Toll-like receptors impacting the innate immune system and contributing to the body's defensive mechanisms against pathogens.

High levels of calprotectin are associated with inflammatory diseases like rheumatoid arthritis and inflammatory bowel disease. Its involvement in these conditions makes it a valuable biomarker. Calprotectin often interacts with other inflammatory molecules like TNF-alpha an important factor in propagating inflammation. The calprotectin ELISA test kit plasma calprotectin immunoassay and similar tools can aid in diagnosing and monitoring these conditions providing insight into disease progression and response to treatment.

Product protocols

Target data

S100A9 is a calcium- and zinc-binding protein which plays a prominent role in the regulation of inflammatory processes and immune response (PubMed : 12626582, PubMed : 15331440, PubMed : 16258195, PubMed : 19122197, PubMed : 20103766, PubMed : 21325622, PubMed : 8423249). It can induce neutrophil chemotaxis, adhesion, can increase the bactericidal activity of neutrophils by promoting phagocytosis via activation of SYK, PI3K/AKT, and ERK1/2 and can induce degranulation of neutrophils by a MAPK-dependent mechanism (PubMed : 12626582, PubMed : 15331440, PubMed : 20103766). Predominantly found as calprotectin (S100A8/A9) which has a wide plethora of intra- and extracellular functions (PubMed : 16258195, PubMed : 19122197, PubMed : 8423249). The intracellular functions include : facilitating leukocyte arachidonic acid trafficking and metabolism, modulation of the tubulin-dependent cytoskeleton during migration of phagocytes and activation of the neutrophilic NADPH-oxidase (PubMed : 15331440, PubMed : 21325622). Participates also in regulatory T-cell differentiation together with CD69 (PubMed : 26296369). Activates NADPH-oxidase by facilitating the enzyme complex assembly at the cell membrane, transferring arachidonic acid, an essential cofactor, to the enzyme complex and S100A8 contributes to the enzyme assembly by directly binding to NCF2/P67PHOX (PubMed : 15642721, PubMed : 22808130). The extracellular functions involve pro-inflammatory, antimicrobial, oxidant-scavenging and apoptosis-inducing activities (PubMed : 19534726, PubMed : 8423249). Its pro-inflammatory activity includes recruitment of leukocytes, promotion of cytokine and chemokine production, and regulation of leukocyte adhesion and migration (PubMed : 15598812, PubMed : 21487906). Acts as an alarmin or a danger associated molecular pattern (DAMP) molecule and stimulates innate immune cells via binding to pattern recognition receptors such as Toll-like receptor 4 (TLR4) and receptor for advanced glycation endproducts (AGER) (PubMed : 19402754). Binding to TLR4 and AGER activates the MAP-kinase and NF-kappa-B signaling pathways resulting in the amplification of the pro-inflammatory cascade (PubMed : 19402754, PubMed : 22804476). Has antimicrobial activity towards bacteria and fungi and exerts its antimicrobial activity probably via chelation of Zn(2+) which is essential for microbial growth (PubMed : 19087201). Can induce cell death via autophagy and apoptosis and this occurs through the cross-talk of mitochondria and lysosomes via reactive oxygen species (ROS) and the process involves BNIP3 (PubMed : 19935772). Can regulate neutrophil number and apoptosis by an anti-apoptotic effect; regulates cell survival via ITGAM/ITGB and TLR4 and a signaling mechanism involving MEK-ERK (PubMed : 22363402). Its role as an oxidant scavenger has a protective role in preventing exaggerated tissue damage by scavenging oxidants (PubMed : 21912088, PubMed : 22489132). Can act as a potent amplifier of inflammation in autoimmunity as well as in cancer development and tumor spread (PubMed : 16258195). Has transnitrosylase activity; in oxidatively-modified low-densitity lipoprotein (LDL(ox))-induced S-nitrosylation of GAPDH on 'Cys-247' proposed to transfer the NO moiety from NOS2/iNOS to GAPDH via its own S-nitrosylated Cys-3 (PubMed : 25417112). The iNOS-S100A8/A9 transnitrosylase complex is proposed to also direct selective inflammatory stimulus-dependent S-nitrosylation of multiple targets such as ANXA5, EZR, MSN and VIM by recognizing a [IL]-x-C-x-x-[DE] motif (PubMed : 25417112).
See full target information S100A9

Additional targets

S100A9

Publications (8)

Recent publications for all applications. Explore the full list and refine your search

International journal of molecular sciences 24: PubMed37629174

2023

CD74 Promotes a Pro-Inflammatory Tumor Microenvironment by Inducing S100A8 and S100A9 Secretion in Pancreatic Cancer.

Applications

Unspecified application

Species

Unspecified reactive species

Woosol Chris Hong,Da Eun Lee,Hyeon Woong Kang,Myeong Jin Kim,Minsoo Kim,Ju Hyun Kim,Sungsoon Fang,Hyo Jung Kim,Joon Seong Park

Molecular & cellular proteomics : MCP 22:100526 PubMed36889440

2023

Integrated MicroRNA and Secretome Analysis of Human Endometrial Organoids Reveal the miR-3194-5p/Aquaporin/S100A9 Module in Regulating Trophoblast Functions.

Applications

Unspecified application

Species

Unspecified reactive species

Yang Dong,Jianlin Li,Dandan Cao,Jiangming Zhong,Xiaofeng Liu,Yong-Gang Duan,Kai-Fai Lee,William S B Yeung,Cheuk-Lun Lee,Philip C N Chiu

Frontiers in neurology 13:886040 PubMed36003300

2022

Identification of protein biomarkers in host cerebrospinal fluid for differential diagnosis of tuberculous meningitis and other meningitis.

Applications

Unspecified application

Species

Unspecified reactive species

Mailing Huang,Zeyu Ding,Wensheng Li,Weibi Chen,Yadong Du,Hongyan Jia,Qi Sun,Boping Du,Rongrong Wei,Aiying Xing,Qi Li,Naihui Chu,Liping Pan

BMJ open gastroenterology 9: PubMed35790301

2022

Small bowel stomas are associated with higher risk of circulating food-specific-IgG than patients with organic gastrointestinal conditions and colostomies.

Applications

Unspecified application

Species

Unspecified reactive species

Walker K Carson,Joseph L Baumert,Jennifer L Clarke,Jacques Izard

Frontiers in immunology 13:911997 PubMed35799787

2022

Proteomic Analyses Reveal Higher Levels of Neutrophil Activation in Men Than in Women With Systemic Lupus Erythematosus.

Applications

Unspecified application

Species

Unspecified reactive species

Ming-Long Cai,Lan Gui,He Huang,Yu-Kun Zhang,Li Zhang,Zhu Chen,Yu-Jun Sheng

Experimental biology and medicine (Maywood, N.J.) 247:1570-1576 PubMed35723053

2022

TFPI and FXIII negatively and S100A8/A9 and Cystatin C positively correlate with D-dimer in COVID-19.

Applications

Unspecified application

Species

Unspecified reactive species

Anamika Gupta,Rizwan Qaisar,Rabih Halwani,Meganathan Kannan,Firdos Ahmad

Experimental biology and medicine (Maywood, N.J.) 247:1205-1213 PubMed35466734

2022

Lipocalin-2, S100A8/A9, and cystatin C: Potential predictive biomarkers of cardiovascular complications in COVID-19.

Applications

Unspecified application

Species

Unspecified reactive species

Anamika Gupta,Abaher O Al-Tamimi,Rabih Halwani,Hend Alsaidi,Meganathan Kannan,Firdos Ahmad

Frontiers in medicine 9:795392 PubMed35242775

2022

The Expansion of Myeloid-Derived Suppressor Cells Correlates With the Severity of Pneumonia in Kidney Transplant Patients.

Applications

Unspecified application

Species

Unspecified reactive species

Bo Peng,Yulin Luo,Quan Zhuang,Junhui Li,Pengpeng Zhang,Min Yang,Yu Zhang,Gangcheng Kong,Ke Cheng,Yingzi Ming
View all publications
