Rabbit Recombinant Monoclonal AGRIN antibody. Suitable for IHC-Fr and reacts with Mouse, Rat samples.

Be the first to review this product! Submit a review

Images

Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (AB316965), expandable thumbnail
  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (AB316965), expandable thumbnail
  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (AB316965), expandable thumbnail
  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (AB316965), expandable thumbnail
  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (AB316965), expandable thumbnail

Key facts

Isotype

IgG

Host species

Rabbit

Storage buffer

pH: 7.2 - 7.4
Preservative: 0.01% Sodium azide
Constituents: 59% PBS, 40% Glycerol (glycerin, glycerine), 0.05% BSA

Form

Liquid

Clonality

Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-FrWBIHC-PICC/IFFlow CytIP
Human
Not recommended
Not recommended
Not recommended
Not recommended
Not recommended
Not recommended
Mouse
Tested
Not recommended
Not recommended
Not recommended
Not recommended
Not recommended
Rat
Tested
Not recommended
Not recommended
Not recommended
Not recommended
Not recommended

Tested
Tested

Species

Mouse

Dilution info

1/100

Notes

-

Species

Rat

Dilution info

1/100

Notes

-

Not recommended
Not recommended

Species

Human

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Human, Mouse, Rat

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Human, Mouse, Rat

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Mouse, Rat, Human

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Mouse, Rat, Human

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Mouse, Rat, Human

Dilution info

-

Notes

-

Target data

Function

Isoform 1Heparan sulfate basal lamina glycoprotein that plays a central role in the formation and the maintenance of the neuromuscular junction (NMJ) and directs key events in postsynaptic differentiation. This neuron-specific (z+) isoform is a component of the AGRN-LRP4 receptor complex that induces the phosphorylation and activation of MUSK. The activation of MUSK in myotubes induces the formation of NMJ by regulating different processes including the transcription of specific genes and the clustering of AChR in the postsynaptic membrane. Calcium ions are required for maximal AChR clustering. AGRN function in neurons is highly regulated by alternative splicing, glycan binding and proteolytic processing. Modulates calcium ion homeostasis in neurons, specifically by inducing an increase in cytoplasmic calcium ions. Functions differentially in the central nervous system (CNS) by inhibiting the alpha(3)-subtype of Na+/K+-ATPase and evoking depolarization at CNS synapses. This transmembrane agrin (TM-agrin) isoform, the predominate form in neurons of the brain, induces dendritic filopodia and synapse formation in mature hippocampal neurons in large part due to the attached glycosaminoglycan chains and the action of Rho-family GTPases.Isoform 2 and isoform 3: these isoforms lacking the 'z' insert (z0) are muscle-specific, have no AChR clustering ability and may be involved in nervous system endothelial cell differentiation.Agrin N-terminal 110 kDa subunitInvolved in regulation of neurite outgrowth probably due to the presence of the glycosaminoglcan (GAG) side chains of heparan and chondroitin sulfate attached to the Ser/Thr- and Gly/Ser-rich regions. Also involved in modulation of growth factor signaling (By similarity).Agrin C-terminal 22 kDa fragmentThis released fragment is important for agrin signaling and to exert a maximal dendritic filopodia-inducing effect. All 'z' splice variants (z+) of this fragment also show an increase in the number of filopodia.

Alternative names

Agrin

Recommended products

Rabbit Recombinant Monoclonal AGRIN antibody. Suitable for IHC-Fr and reacts with Mouse, Rat samples.

Key facts

Isotype

IgG

Form

Liquid

Clonality

Monoclonal

Immunogen
  • The exact immunogen used to generate this antibody is proprietary information.
Clone number

EPR28044-74

Purification technique

Affinity purification Protein A

Concentration
Loading...

Storage

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle

Notes

Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.

Activity summary

Agrin also known as AGRN is a large heparan sulfate proteoglycan with a molecular mass of approximately 200 kDa. This protein is mainly expressed in the neuromuscular junction and the central nervous system. Agrin has significant roles in synapse formation. It influences the clustering of acetylcholine receptors at the neuromuscular junction which is essential for communication between nerve and muscle cells. This activity is mechanically mediated through interactions with the receptor tyrosine kinase MuSK and LRP4.

Biological function summary

The Agrin protein contributes to the stabilization of synaptic structures. Its ability to induce acetylcholine receptor clustering is fundamental for the proper formation and maintenance of neuromuscular synapses. Agrin is not a lone player; it is a part of a larger signaling complex. This complex includes other proteins like MuSK which acts as a receptor playing an essential role in complex signaling pathways that regulate synaptogenesis and synaptic plasticity.

Pathways

Many molecules associate to facilitate communication and synapse integrity via Agrin's activity. Agrin engages primarily with the MAPK/ERK signaling pathway and the PI3K/AKT pathway. These pathways are central for cell growth and differentiation in the central nervous system. The relationship with MuSK through these pathways highlights Agrin's importance in orchestrating the synapse assembly and stability.

Associated diseases and disorders

Mutations or alterations in Agrin can lead to conditions such as congenital myasthenic syndromes and potentially impact neurodegenerative disorders like amyotrophic lateral sclerosis. In these cases its interaction with proteins like MuSK is affected leading to impaired neuromuscular transmission. Understanding the anti-Agrin antibody's function might enhance methodologies to treat these neuromuscular disorders.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

5 product images

  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965)

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Rat kidney (fresh frozen) tissue labeling Agrin with ab316965 at 1/100 (5.01 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 (2 ug/ml) dilution (Green).

    Confocal image showing positive staining in glomeruli of rat kidney. The nuclear counterstain was DAPI (Blue). The section was incubated with ab316965 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 (2 ug/ml) dilution.

  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965)

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Rat cerebrum (fresh frozen) tissue labeling Agrin with ab316965 at 1/100 (5.01 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 (2 ug/ml) dilution (Green).

    Confocal image showing positive staining in endothelial cells on rat cerebrum. The nuclear counterstain was DAPI (Blue). The section was incubated with ab316965 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 (2 ug/ml) dilution.

  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965)

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse lung (fresh frozen) tissue labeling Agrin with ab316965 at 1/100 (5.01 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 (2 ug/ml) dilution (Green).

    Confocal image showing positive staining in endothelial cells on mouse lung. The nuclear counterstain was DAPI (Blue). The section was incubated with ab316965 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 (2 ug/ml) dilution.

  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965)

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse kidney (fresh frozen) tissue labeling Agrin with ab316965 at 1/100 (5.01 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 (2 ug/ml) dilution (Green).

    Confocal image showing positive staining in glomeruli of mouse kidney. The nuclear counterstain was DAPI (Blue). The section was incubated with ab316965 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 (2 ug/ml) dilution.

  • Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Agrin antibody [EPR28044-74] (ab316965)

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse cerebrum (fresh frozen) tissue labeling Agrin with ab316965 at 1/100 (5.01 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 (2 ug/ml) dilution (Green).

    Confocal image showing positive staining in endothelial cells on mouse cerebrum. The nuclear counterstain was DAPI (Blue). The section was incubated with ab316965 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 (2 ug/ml) dilution.

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
