Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker

5 product images

•

  Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031)

  ab185031 staining alpha-Tubulin in HeLa cells. The cells were fixed with 100% methanol (5min) and then blocked in 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated with ab185031 at a working dilution of 1 in 100 overnight at +4°C (shown in green). Alexa Fluor^® 350 WGA was used at a 1/200 dilution and incubated for 1h with the cells, to label plasma membranes (shown in blue). Nuclear DNA was labelled in red with 1.25 μM DRAQ5™ (DRAQ5™ ab108410).

•

  Flow Cytometry (Intracellular) - Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031)

  Overlay histogram showing HeLa cells stained with ab185031 (red line). The cells were fixed with 80% methanol (5 min) and then permeabilized with 0.1% PBS-Triton X-100 for 20 min. The cells were then incubated in 1x PBS / 10% normal goat serum / 0.3M glycine to block non-specific protein-protein interactions followed by the antibody (ab185031, 1/500 dilution) for 30 min at 22°C. Isotype control antibody (black line) was rabbit IgG (monoclonal) Alexa Fluor® 488 used at the same concentration and conditions as the primary antibody. Unlabelled sample (blue line) was also used as a control.

  Acquisition of >5,000 events were collected using a 20mW Argon ion laser (488nm) and 525/30 bandpass filter.

  This antibody gave a positive signal in HeLa fixed with 4% formaldehyde (10 min)/permeabilized with 0.1% PBS-Triton X-100 for 20 min used under the same conditions.

•

  This image is courtesy of a customer review submitted by Shijian Zhang

  Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031)

  ab185031 staining alpha Tubulin in HeLa cells by ICC/IF (Immunocytochemistry/immunofluorescence). Cells were fixed with formaldehyde, permeabilized with 0.1% Triton X-100 in 1X PBS and blocked with 2% BSA for 30 minutes at 25°C. Samples were incubated with primary antibody (1/100) for 1 hour at 25°C.

•

  Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031)

  Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized HUVEC (human umbilical vein endothelial cell) cells labelling CD63 with PE Anti-CD63 antibody [KILL150A] ab322728 at 1/50 (10.0 ug/ml) dilution (Green).

  Confocal image showing cytoplasmic staining in HUVEC cells (shown in magenta). The counterstain was observed in green. Nuclear DNA was labeled with DAPI (shown in blue).

  Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  ab185031 Recombinant Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031) was used to counterstain tubulin at 1/200 2.5ug/ml dilution (Magenta). The Nuclear counterstain was DAPI (Blue).

•

  Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031)

  Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized SK-MEL-28 (human malignant melanoma cell) cells labelling CD63 with PE Anti-CD63 antibody [KILL150A] ab322728 at 1/50 (10.0 ug/ml) dilution (Green).

  Confocal image showing cytoplasmic staining in SK-MEL-28 cell line(shown in magenta). The counterstain was observed in green. Nuclear DNA was labeled with DAPI (shown in blue).

  Low expression: Jurkat

  Image was taken with a confocal microscope(Leica-Microsystems, TCS SP8).

  ab185031 Recombinant Alexa Fluor® 488 Anti-alpha Tubulin antibody [EP1332Y] - Microtubule Marker (ab185031) was used to counterstain tubulin at 1/200 2.5ug/ml dilution (Magenta). The Nuclear counterstain was DAPI (Blue).
