Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker (AB302977)

Immunohistochemical analysis of paraffin-embedded human cerebrum tissue labeling GFAP with ab302977 at 1/100 dilution (5.0 µg/mL). Positive staining is observed on astrocytes of human cerebrum. The section was incubated with ab302977 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins was used.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker (AB302977)

Immunohistochemical analysis of paraffin-embedded human astrocytoma tissue labeling GFAP with ab302977 at 1/100 dilution (5.0 µg/mL). Positive staining is observed on human astrocytoma. The section was incubated with ab302977 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins was used.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker (AB302977)

Immunohistochemical analysis of paraffin-embedded rat cerebrum tissue labeling GFAP with ab302977 at 1/50 dilution (10.0 µg/mL). Positive staining is observed on astrocytes of rat cerebrum. The section was incubated with ab302977 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins was used.

• ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker (AB302977)

Immunofluorescent analysis of 4% paraformaldehyde-fixed, 0.1% Triton X-100 permeabilized rat primary neural/glia cells labeling GFAP with ab302977 at 1/50 dilution (10 µg/ml) (Green). Confocal image showing positive staining in rat primary glia cell. Confocal scanning Z step was set as 0.3 μm followed by image processing with maximum Z projection. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Anti-Glial Fibrillary Acidic Protein (GFAP) mouse monoclonal antibody was used as counterstain at 1/100 (1ug/ml) dilution (Red). The nuclear counterstain was DAPI (Blue).

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker (AB302977)

Immunohistochemical analysis of paraffin-embedded mouse cerebrum tissue labeling GFAP with ab302977 at 1/50 dilution (10.0 µg/mL). Positive staining is observed on astrocytes of mouse cerebrum. The section was incubated with ab302977 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins was used.

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-GFAP antibody [EP672Y] - Astrocyte marker (AB302977)

Immunofluorescence staining of GFAP staining in a section of formalin-fixed paraffin-embedded human Alzheimer’s brain*.

Performed on a Leica BOND. The section was pre-treated using heat mediated antigen retrieval with EDTA (Ph9.0) using retrieval settings of 100°C for 40 minutes. The section was then incubated at room temperature for 1 hour with ab302977 at 1/500 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Dako Fluorescence Mounting Medium ^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre.
