Mouse Monoclonal GRIM19 antibody - conjugated to Alexa Fluor® 488. Suitable for ICC/IF and reacts with Mouse samples.

Be the first to review this product! Submit a review

Images

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-GRIM19 antibody [6E1BH7] (AB197965), expandable thumbnail

Key facts

Isotype

IgG2b

Host species

Mouse

Conjugation

Alexa Fluor® 488

Excitation/Emission

Ex: 495nm, Em: 519nm

Storage buffer

pH: 7.4
Preservative: 0.02% Sodium azide
Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Form

Liquid

Clonality

Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
ICC/IF
Mouse
Tested

Tested
Tested

Species

Mouse

Dilution info

1/50

Notes

This product gave a positive signal in MEF1 cells fixed with 100% methanol (5 min).

Associated Products

Select an associated product type

2 products for Alternative Product

    1 products for Alternative Version

      Target data

      Function

      Accessory subunit of the mitochondrial membrane respiratory chain NADH dehydrogenase (Complex I), that is believed not to be involved in catalysis (PubMed:27626371). Complex I functions in the transfer of electrons from NADH to the respiratory chain. The immediate electron acceptor for the enzyme is believed to be ubiquinone (PubMed:27626371). Involved in the interferon/all-trans-retinoic acid (IFN/RA) induced cell death. This apoptotic activity is inhibited by interaction with viral IRF1. Prevents the transactivation of STAT3 target genes. May play a role in CARD15-mediated innate mucosal responses and serve to regulate intestinal epithelial cell responses to microbes (PubMed:15753091).

      Alternative names

      NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 13, Cell death regulatory protein GRIM-19, Complex I-B16.6, Gene associated with retinoic and interferon-induced mortality 19 protein, NADH-ubiquinone oxidoreductase B16.6 subunit, CI-B16.6, GRIM-19, Gene associated with retinoic and IFN-induced mortality 19 protein, CDA016, CGI-39, GRIM19, NDUFA13

      Recommended products

      1. Loading...
      2. Loading...
      3. Loading...
      4. Loading...

      Mouse Monoclonal GRIM19 antibody - conjugated to Alexa Fluor® 488. Suitable for ICC/IF and reacts with Mouse samples.

      Alternative names

      NADH dehydrogenase [ubiquinone] 1 alpha subcomplex subunit 13, Cell death regulatory protein GRIM-19, Complex I-B16.6, Gene associated with retinoic and interferon-induced mortality 19 protein, NADH-ubiquinone oxidoreductase B16.6 subunit, CI-B16.6, GRIM-19, Gene associated with retinoic and IFN-induced mortality 19 protein, CDA016, CGI-39, GRIM19, NDUFA13

      Key facts

      Isotype

      IgG2b

      Conjugation

      Alexa Fluor® 488

      Excitation/Emission

      Ex: 495nm, Em: 519nm

      Form

      Liquid

      Clonality

      Monoclonal

      Immunogen
      • The exact immunogen used to generate this antibody is proprietary information.
      Clone number

      6E1BH7

      Purification technique

      Affinity purification

      Light chain type

      kappa

      Concentration
      Loading...

      Storage

      Shipped at conditions

      Blue Ice

      Appropriate short-term storage duration

      1-2 weeks

      Appropriate short-term storage conditions

      +4°C

      Appropriate long-term storage conditions

      -20°C

      Aliquoting information

      Upon delivery aliquot

      Storage information

      Avoid freeze / thaw cycle, Store in the dark

      Notes

      Abcam is leading the way to address reproducibility in scientific research with our highly validated recombinant monoclonal and recombinant multiclonal antibodies. Search & select one of Abcam's thousands of recombinant alternatives to eliminate batch-variability and unnecessary animal use.

      If you do not find a host species to meet your needs, our catalogue and custom Chimeric range provides scientists the specificity of Abcam's RabMAbs in the species backbone of your choice. Remember to also review our range of edited cell lines, proteins and biochemicals relevant to your target that may help you further your research goals.

      Abcam antibodies are extensively validated in a wide range of species and applications, so please check the reagent specifications meet your scientific needs before purchasing. If you have any questions or bespoke requirements, simply visit the Contact Us page to send us an inquiry or contact our Support Team ahead of purchase.

      Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

      Supplementary info

      Activity summary

      GRIM19 also known as NDUFA13 is a small protein with a molecular mass of approximately 16 kDa. It expresses mainly in mitochondria where it forms an integral component of the mitochondrial respiratory chain complex I. GRIM19 plays an important role in the functioning of complex I by facilitating the assembly and stabilization of the complex enabling efficient electron transport and ATP synthesis.

      Biological function summary

      GRIM19 interacts with several complexes and proteins within the mitochondrial inner membrane. As a part of complex I also known as NADH:ubiquinone oxidoreductase it contributes to the initial step of mitochondrial oxidative phosphorylation. GRIM19 also participates in the regulation of apoptosis and its expression is influenced during cellular stress situations highlighting its significance in cellular survival and energy production.

      Pathways

      GRIM19 integrates closely with mitochondrial apoptosis and energy metabolism pathways. Its interactions within oxidative phosphorylation place it in concert with both the electron transport chain and the apoptosis regulatory network. GRIM19 shares associations with related proteins such as cytochrome c oxidase and other complex I subunits highlighting its essential contribution to these important biological processes.

      Associated diseases and disorders

      GRIM19 demonstrates links to various pathologies including cancer and mitochondrial diseases. Alterations in GRIM19 expression or function have been implicated in the progression of certain cancers such as colorectal and thyroid cancer where GRIM19's usual regulatory role in apoptosis can be disrupted. Additionally its involvement in mitochondrial disease connects to proteins like COX-A1 emphasizing the importance of maintaining functional complexes for cellular health.

      Product promise

      We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

      In the unlikely event of one of our products not working as expected, you are covered by our product promise.

      Full details and terms and conditions can be found here:
      Terms & Conditions.

      1 product image

      • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-GRIM19 antibody [6E1BH7] (ab197965), expandable thumbnail

        Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-GRIM19 antibody [6E1BH7] (ab197965)

        ab197965 staining GRIM19 in MEF1 cells. The cells were fixed with 100% methanol (5 min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab197965 at a 1/50 dilution (shown in green) and Alexa Fluor® 594 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker ab195889, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 594), at a 1/250 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue).

        Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

      Downloads

      Product protocols

      For this product, it's our understanding that no specific protocols are required. You can:

      Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
