Rabbit Monoclonal Lamin B1 antibody - conjugated to Alexa Fluor® 488. Nuclear Envelope marker. Suitable for IHC-P, ICC/IF and reacts with Mouse, Rat, Human samples. Cited in 4 publications.

Be the first to review this product! Submit a review

Images

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106), expandable thumbnail
  • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106), expandable thumbnail

Publications

Key facts

Isotype
IgG
Host species
Rabbit
Conjugation
Alexa Fluor® 488
Excitation/Emission
Ex: 495nm, Em: 519nm
Storage buffer

pH: 7.4
Preservative: 0.02% Sodium azide
Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Form
Liquid
Clonality
Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-PICC/IF
Human
Tested
Tested
Mouse
Tested
Tested
Rat
Tested
Tested

Tested
Tested

Species
Mouse
Dilution info
1/100
Notes

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Species
Rat
Dilution info
1/100
Notes

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Species
Human
Dilution info
1/100
Notes

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Tested
Tested

Species
Human
Dilution info
1/100
Notes

-

Species
Mouse
Dilution info
1/100
Notes

-

Species
Rat
Dilution info
1/100
Notes

-

Associated Products

Select an associated product type

6 products for Alternative Product

4 products for Alternative Version

Target data

Function

Lamins are intermediate filament proteins that assemble into a filamentous meshwork, and which constitute the major components of the nuclear lamina, a fibrous layer on the nucleoplasmic side of the inner nuclear membrane (PubMed:28716252, PubMed:32910914). Lamins provide a framework for the nuclear envelope, bridging the nuclear envelope and chromatin, thereby playing an important role in nuclear assembly, chromatin organization, nuclear membrane and telomere dynamics (PubMed:28716252, PubMed:32910914). The structural integrity of the lamina is strictly controlled by the cell cycle, as seen by the disintegration and formation of the nuclear envelope in prophase and telophase, respectively (PubMed:28716252, PubMed:32910914).

Alternative names

LMN2, LMNB, LMNB1, Lamin-B1

Recommended products

Rabbit Monoclonal Lamin B1 antibody - conjugated to Alexa Fluor® 488. Nuclear Envelope marker. Suitable for IHC-P, ICC/IF and reacts with Mouse, Rat, Human samples. Cited in 4 publications.

Key facts

Isotype
IgG
Conjugation
Alexa Fluor® 488
Excitation/Emission
Ex: 495nm, Em: 519nm
Form
Liquid
Clonality
Monoclonal
Immunogen
  • The exact immunogen used to generate this antibody is proprietary information.
Clone number
EPR8985(B)
Purification technique
Affinity purification Protein A
Dissociation constant
1.95 x 10-10 M
Concentration
Loading...

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle, Store in the dark

Notes

Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.
Activity summary

Lamin B1 also known as LMNB1 is a protein that plays an important role in the structure of the nuclear lamina a dense fibrillar network inside the nucleus of cells. This protein belongs to the lamin family and has an approximate molecular weight of 66 kDa. Lamin B1 is expressed in nearly all types of cells acting as a structural component by interacting with chromatin and anchoring the nuclear envelope. It contributes to regulating nuclear stability and mechanical support which is essential for proper cell function.

Biological function summary

Lamin B1 serves many important functions by providing structural integrity and regulating gene expression through chromatin organization. Part of the nuclear lamina complex Lamin B1 interacts with other lamin proteins such as Lamin A and Lamin C forming a mesh-like structure that supports the nuclear envelope. This protein also affects cellular processes such as DNA replication RNA transcription and cell division indicating its broad impact on various cellular activities.

Pathways

Lamin B1 plays an important role in gene expression regulation and cell cycle control. It interacts with pathways involved in chromatin remodeling influencing the access of transcription factors to DNA which affects gene expression profiles. Lamin B1 associates with related proteins such as Lamin A/C and other nuclear matrix proteins to maintain cellular architecture stability and normal cell function. This organization is vital to ensure the accuracy of cellular processes and prevent anomalies during cell division.

Associated diseases and disorders

Mutations or altered expression of Lamin B1 have been associated with several pathological conditions. One noteworthy disorder is autosomal dominant adult-onset leukodystrophy where Lamin B1 expression levels are abnormal. This protein also connects to multiple sclerosis through its role in maintaining nuclear architecture. Additionally changes in Lamin B1 expression levels can influence pathways involving Lamin A/C and potentially lead to other laminopathies highlighting its influence in maintaining cellular health and contributing to disease development.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

5 product images

  • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106)

    ab194106 staining Lamin B1 in HeLa cells. The cells were fixed with 100% methanol (5 min), permeabilised in 0.1% Triton X-100 for 5 minutes and then blocked in 1% BSA/10% normal goat serum/0.3M glycine in 0.1%PBS-Tween for 1h. The cells were then incubated with ab194106 at 1/100 dilution (shown in green) and Alexa Fluor® 594 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker ab195889, Mouse monoclonal [DM1A] to alpha Tubulin (Alexa Fluor® 594, shown in red) at 1/250 dilution overnight at +4°C. Nuclear DNA was labelled in blue with DAPI.

    Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106)

    ab194106 staining Lamin B1 in wild-type HAP1 cells (top panel) and Lamin B1 knockout HAP1 cells (bottom panel). The cells were fixed with 100% methanol (5 min), permeabilised in 0.1% Tween for 5 minutes and then blocked in 1% BSA/10% normal goat serum/0.3M glycine in 0.1%PBS-Tween for 1h. The cells were then incubated with ab194106 at 1/100 dilution (shown in green) and Alexa Fluor® 594 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker ab195889, Mouse monoclonal [DM1A] to alpha Tubulin (Alexa Fluor® 594, shown in red) at 1/250 dilution overnight at +4°C. Nuclear DNA was labelled in blue with DAPI.

    Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106)

    Immunohistochemistry analysis of paraffin-embedded rat cerebrum tissue sections labelling Lamin B1 with ab194106 at 1/100 dilution. The section was incubated with ab194106 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins.
    Nuclear envelope staining on rat cerebrum tissue. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Negative control : The negative control is PBS.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106)

    Immunohistochemistry analysis of paraffin-embedded mouse cerebrum cortex tissue sections labelling Lamin B1 with ab194106 at 1/100 dilution. The section was incubated with ab194106 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins.
    Nuclear envelope staining on mouse cerebrum cortex tissue. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Negative control : The negative control is PBS.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (ab194106)

    Immunohistochemistry analysis of paraffin-embedded human bladder transitional cell carcinoma tissue sections labelling Lamin B1 with ab194106 at 1/100 dilution. The section was incubated with ab194106 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins.
    Nuclear envelope staining on human bladder transitional cell carcinoma tissue. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Negative control : The negative control is PBS.

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.

For licensing inquiries, please contact partnerships@abcam.com
