AB194106

Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker

BOND RX™ Validated
RabMAb
Recombinant
KO Validated
What is this?

Be the first to review this product! Submit a review

(6 Publications)

Rabbit Recombinant Monoclonal Lamin B1 antibody - conjugated to Alexa Fluor^® 488. Nuclear Envelope marker. Suitable for IHC-P, ICC/IF and reacts with Mouse, Rat, Human samples. Cited in 4 publications.

- Recommended for methanol-fixed samples in ICC only. Use ab229025 for compatibility with both methanol and PFA.

View Alternative Names

LMN2, LMNB, LMNB1, Lamin-B1

5 Images

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

ab194106 staining Lamin B1 in wild-type HAP1 cells (top panel) and Lamin B1 knockout HAP1 cells (bottom panel). The cells were fixed with 100% methanol (5 min), permeabilised in 0.1% Tween for 5 minutes and then blocked in 1% BSA/10% normal goat serum/0.3M glycine in 0.1%PBS-Tween for 1h. The cells were then incubated with ab194106 at 1/100 dilution (shown in green) and ab195889, Mouse monoclonal [DM1A] to alpha Tubulin (Alexa Fluor^® 594, shown in red) at 1/250 dilution overnight at +4°C. Nuclear DNA was labelled in blue with DAPI.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

ab194106 staining Lamin B1 in HeLa cells. The cells were fixed with 100% methanol (5 min), permeabilised in 0.1% Triton X-100 for 5 minutes and then blocked in 1% BSA/10% normal goat serum/0.3M glycine in 0.1%PBS-Tween for 1h. The cells were then incubated with ab194106 at 1/100 dilution (shown in green) and ab195889, Mouse monoclonal [DM1A] to alpha Tubulin (Alexa Fluor^® 594, shown in red) at 1/250 dilution overnight at +4°C. Nuclear DNA was labelled in blue with DAPI.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

Immunohistochemistry analysis of paraffin-embedded human bladder transitional cell carcinoma tissue sections labelling Lamin B1 with ab194106 at 1/100 dilution. The section was incubated with ab194106 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount^®. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins.
Nuclear envelope staining on human bladder transitional cell carcinoma tissue. The immunostaining was performed on a Leica Biosystems BOND^® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Negative control : The negative control is PBS.

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

Immunohistochemistry analysis of paraffin-embedded mouse cerebrum cortex tissue sections labelling Lamin B1 with ab194106 at 1/100 dilution. The section was incubated with ab194106 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount^®. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins.
Nuclear envelope staining on mouse cerebrum cortex tissue. The immunostaining was performed on a Leica Biosystems BOND^® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Negative control : The negative control is PBS.

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker (AB194106)

Immunohistochemistry analysis of paraffin-embedded rat cerebrum tissue sections labelling Lamin B1 with ab194106 at 1/100 dilution. The section was incubated with ab194106 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount^®. Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 mins.
Nuclear envelope staining on rat cerebrum tissue. The immunostaining was performed on a Leica Biosystems BOND^® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Negative control : The negative control is PBS.

665 Alexa Fluor® 647

Alexa Fluor® 647 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker
HRP

HRP Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Loading Control
617 Alexa Fluor® 594

Alexa Fluor® 594 Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker
Unconjugated

Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker
Carrier free

Anti-Lamin B1 antibody [EPR8985(B)] - BSA and Azide free
Unconjugated

Anti-Lamin B1 antibody [EPR8985(B)] - Nuclear Envelope Marker - Mouse IgG1 (Chimeric)

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR8985(B)

Isotype

IgG

Conjugation

Alexa Fluor® 488

Excitation/Emission

Ex: 495nm, Em: 519nm

Carrier free

Reacts with

Human, Mouse, Rat

Applications

ICC/IF, IHC-P

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": " Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.", "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100", "ICCIF-species-notes": "Recommended for methanol-fixed samples in ICC only. Use <a href='/en-us/products/primary-antibodies/lamin-b1-antibody-epr22165-121-nuclear-envelope-marker-ab229025'>ab229025</a> for compatibility with both methanol and PFA." }, "Mouse": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": " Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.", "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100", "ICCIF-species-notes": "Recommended for methanol-fixed samples in ICC only. Use <a href='/en-us/products/primary-antibodies/lamin-b1-antibody-epr22165-121-nuclear-envelope-marker-ab229025'>ab229025</a> for compatibility with both methanol and PFA." }, "Rat": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": " Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.", "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100", "ICCIF-species-notes": "Recommended for methanol-fixed samples in ICC only. Use <a href='/en-us/products/primary-antibodies/lamin-b1-antibody-epr22165-121-nuclear-envelope-marker-ab229025'>ab229025</a> for compatibility with both methanol and PFA." } } }

style

left-column

Product details

Patented technology
Our RabMAb^® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb^® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

- High batch-to-batch consistency and reproducibility
- Improved sensitivity and specificity
- Long-term security of supply
- Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style

left-column

Properties and storage information

Form

Liquid

Purification technique

Affinity purification Protein A

Storage buffer

pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle|Store in the dark

style

left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

Lamin B1 also known as LMNB1 is a protein that plays an important role in the structure of the nuclear lamina a dense fibrillar network inside the nucleus of cells. This protein belongs to the lamin family and has an approximate molecular weight of 66 kDa. Lamin B1 is expressed in nearly all types of cells acting as a structural component by interacting with chromatin and anchoring the nuclear envelope. It contributes to regulating nuclear stability and mechanical support which is essential for proper cell function.

Biological function summary

Lamin B1 serves many important functions by providing structural integrity and regulating gene expression through chromatin organization. Part of the nuclear lamina complex Lamin B1 interacts with other lamin proteins such as Lamin A and Lamin C forming a mesh-like structure that supports the nuclear envelope. This protein also affects cellular processes such as DNA replication RNA transcription and cell division indicating its broad impact on various cellular activities.

Pathways

Lamin B1 plays an important role in gene expression regulation and cell cycle control. It interacts with pathways involved in chromatin remodeling influencing the access of transcription factors to DNA which affects gene expression profiles. Lamin B1 associates with related proteins such as Lamin A/C and other nuclear matrix proteins to maintain cellular architecture stability and normal cell function. This organization is vital to ensure the accuracy of cellular processes and prevent anomalies during cell division.

Mutations or altered expression of Lamin B1 have been associated with several pathological conditions. One noteworthy disorder is autosomal dominant adult-onset leukodystrophy where Lamin B1 expression levels are abnormal. This protein also connects to multiple sclerosis through its role in maintaining nuclear architecture. Additionally changes in Lamin B1 expression levels can influence pathways involving Lamin A/C and potentially lead to other laminopathies highlighting its influence in maintaining cellular health and contributing to disease development.

style

left-column

style

left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

Target data

Lamins are intermediate filament proteins that assemble into a filamentous meshwork, and which constitute the major components of the nuclear lamina, a fibrous layer on the nucleoplasmic side of the inner nuclear membrane (PubMed : 28716252, PubMed : 32910914). Lamins provide a framework for the nuclear envelope, bridging the nuclear envelope and chromatin, thereby playing an important role in nuclear assembly, chromatin organization, nuclear membrane and telomere dynamics (PubMed : 28716252, PubMed : 32910914). The structural integrity of the lamina is strictly controlled by the cell cycle, as seen by the disintegration and formation of the nuclear envelope in prophase and telophase, respectively (PubMed : 28716252, PubMed : 32910914).

See full target information LMNB1

style

left-column

Publications (6)

Recent publications for all applications. Explore the full list and refine your search

APL bioengineering 9:036104 PubMed40666708

2025

Microwave-assisted immunostaining for rapid labeling of matrix-embedded multicellular structures.

Applications

Unspecified application

Species

Unspecified reactive species

Kevin J Schilling,Katherine T Huynh,Sean Speese,Carolyn E Schutt

Cell reports 43:114852 PubMed39412986

2024

Heterogeneous force response of chromatin in isolated nuclei.

Applications

Unspecified application

Species

Unspecified reactive species

Giulia Bergamaschi,Andreas S Biebricher,Hannes Witt,Fitzroy J Byfield,Xamanie M R Seymonson,Cornelis Storm,Paul A Janmey,Gijs J L Wuite

Cell death and differentiation 30:2151-2166 PubMed37596441

2023

Hornerin mediates phosphorylation of the polo-box domain in Plk1 by Chk1 to induce death in mitosis.

Applications

Unspecified application

Species

Unspecified reactive species

Haiyu Song,Eun Ho Kim,Jihee Hong,Dasom Gwon,Jee Won Kim,Gyu-Un Bae,Chang-Young Jang

Communications biology 5:1263 PubMed36400937

2022

UnMICST: Deep learning with real augmentation for robust segmentation of highly multiplexed images of human tissues.

Applications

Unspecified application

Species

Unspecified reactive species

Clarence Yapp,Edward Novikov,Won-Dong Jang,Tuulia Vallius,Yu-An Chen,Marcelo Cicconet,Zoltan Maliga,Connor A Jacobson,Donglai Wei,Sandro Santagata,Hanspeter Pfister,Peter K Sorger

Cell reports methods 1: PubMed34485971

2021

Toward reproducible, scalable, and robust data analysis across multiplex tissue imaging platforms.

Applications

Unspecified application

Species

Unspecified reactive species

Erik A Burlingame,Jennifer Eng,Guillaume Thibault,Koei Chin,Joe W Gray,Young Hwan Chang

eLife 7: PubMed29993362

2018

Highly multiplexed immunofluorescence imaging of human tissues and tumors using t-CyCIF and conventional optical microscopes.

Applications

Unspecified application

Species

Unspecified reactive species

Jia-Ren Lin,Benjamin Izar,Shu Wang,Clarence Yapp,Shaolin Mei,Parin M Shah,Sandro Santagata,Peter K Sorger

View all publications

style

left-column

style

left-column

style

right-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.

For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
