Rabbit Recombinant Monoclonal M6PR (cation dependent) antibody - conjugated to Alexa Fluor® 488. Suitable for ICC/IF and reacts with Human samples.

Be the first to review this product! Submit a review

Images

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-M6PR (cation dependent) antibody [EPR7691] (AB316945), expandable thumbnail
  • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-M6PR (cation dependent) antibody [EPR7691] (AB316945), expandable thumbnail

Key facts

Isotype

IgG

Host species

Rabbit

Conjugation

Alexa Fluor® 488

Excitation/Emission

Ex: 495nm, Em: 519nm

Storage buffer

pH: 7.4
Preservative: 0.02% Sodium azide
Constituents: 68% PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Form

Liquid

Clonality

Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
ICC/IF
Human
Tested

Tested
Tested

Species

Human

Dilution info

1/50

Notes

-

Target data

Function

Transport of phosphorylated lysosomal enzymes from the Golgi complex and the cell surface to lysosomes. Lysosomal enzymes bearing phosphomannosyl residues bind specifically to mannose-6-phosphate receptors in the Golgi apparatus and the resulting receptor-ligand complex is transported to an acidic prelyosomal compartment where the low pH mediates the dissociation of the complex.

Alternative names

Cation-dependent mannose-6-phosphate receptor, CD Man-6-P receptor, CD-MPR, 46 kDa mannose 6-phosphate receptor, MPR 46, MPRD, MPR46, M6PR

Recommended products

Rabbit Recombinant Monoclonal M6PR (cation dependent) antibody - conjugated to Alexa Fluor® 488. Suitable for ICC/IF and reacts with Human samples.

Alternative names

Cation-dependent mannose-6-phosphate receptor, CD Man-6-P receptor, CD-MPR, 46 kDa mannose 6-phosphate receptor, MPR 46, MPRD, MPR46, M6PR

Key facts

Isotype

IgG

Conjugation

Alexa Fluor® 488

Excitation/Emission

Ex: 495nm, Em: 519nm

Form

Liquid

Clonality

Monoclonal

Immunogen
  • The exact immunogen used to generate this antibody is proprietary information.
Clone number

EPR7691

Purification technique

Affinity purification Protein A

Concentration
Loading...

Storage

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle, Store in the dark

Notes

Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.

Activity summary

M6PR or mannose-6-phosphate receptor (cation dependent) is a protein involved in the transport of lysosomal enzymes from the Golgi apparatus to the lysosome. Alternate names for M6PR include CD-MPR and MPR46 reflecting its function and molecular weight of approximately 46 kDa. M6PR is expressed in various tissues but primarily found in the Golgi apparatus where it engages with lysosomal enzymes. This receptor is an important element in the delivery system that ensures lysosomal enzymes reach their intended cellular destination.

Biological function summary

M6PR acts as a sorting receptor by binding mannose-6-phosphate-tagged enzymes in the Golgi. It is involved in a complex trafficking mechanism that involves clathrin-coated vesicles. The receptor recognizes and binds to its ligands in the Golgi directing them to endosomes and eventually fusing with lysosomes. M6PR plays a critical role in maintaining lysosome functionality by regulating enzyme availability which is essential for cellular waste degradation and resource recycling.

Pathways

The protein M6PR participates in the lysosomal enzyme targeting pathway that ensures proper enzyme sorting and delivery within cells. This pathway overlaps with the Golgi-to-endosome transport vesicle biogenesis involving proteins like clathrin and adaptin. M6PR interacts with proteins in the sorting pathway such as GGA adaptors and Hsc70 which assist in the recognition and transport processes necessary for lysosome integrity and function.

Associated diseases and disorders

The malfunction of M6PR links to disorders like I-cell disease and mucolipidosis II characterized by defective lysosomal enzyme targeting. Impaired M6PR function can lead to the accumulation of undigested substrates within the lysosome causing cellular dysfunction. The receptor's failure can also indirectly affect protein interactions in diseases like mucolipidosis where relationships with proteins such as IGF2R can get altered further influencing cellular pathways and leading to various pathological conditions.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

2 product images

  • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-M6PR (cation dependent) antibody [EPR7691] (ab316945), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-M6PR (cation dependent) antibody [EPR7691] (ab316945)

    Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized HeLa (human cervical adenocarcinoma epithelial cell) cells labelling M6PR (cation dependent) with ab316945 at 1/50 (10.0 ug/ml) dilution.

    Confocal image showing cytoplasmic staining in HeLa cell line (shown in green). The counterstain was observed in magenta. Nuclear DNA was labeled with DAPI (shown in blue). Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Alexa Fluor® 594 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker ab195889 Anti-alpha Tubulin mouse monoclonal antibody - Microtubule Marker (Alexa Fluor® 594) was used to counterstain tubulin at 1/200 2.5ug/ml dilution.

  • Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-M6PR (cation dependent) antibody [EPR7691] (ab316945), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-M6PR (cation dependent) antibody [EPR7691] (ab316945)

    Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized A549 (human lung carcinoma epithelial cell) cells labelling M6PR (cation dependent) with ab316945 at 1/50 (10.0 ug/ml) dilution.

    Confocal image showing cytoplasmic staining in A549 cell line (shown in green). The counterstain was observed in magenta. Nuclear DNA was labeled with DAPI (shown in blue). Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

    Alexa Fluor® 594 Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker ab195889 Anti-alpha Tubulin mouse monoclonal antibody - Microtubule Marker (Alexa Fluor® 594) was used to counterstain tubulin at 1/200 2.5ug/ml dilution.

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
