AB202666

Alexa Fluor® 488 Anti-PI3 Kinase p110 beta antibody [EPR5515(2)]

Be the first to review this product! Submit a review

|

(3 Publications)

Rabbit Recombinant Monoclonal PI3 Kinase p110 beta antibody - conjugated to Alexa Fluor® 488. Suitable for ICC/IF and reacts with Human samples. Cited in 3 publications.

View Alternative Names

PIK3C1, PIK3CB, PI3-kinase subunit beta, PI3K-beta, PI3Kbeta, PtdIns-3-kinase subunit beta, Serine/threonine protein kinase PIK3CB, PtdIns-3-kinase subunit p110-beta, p110beta

1 Images
Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-PI3 Kinase p110 beta antibody [EPR5515(2)] (AB202666)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 488 Anti-PI3 Kinase p110 beta antibody [EPR5515(2)] (AB202666)

ab202666 staining PI3 Kinase p110 beta in HeLa cells. The cells were fixed with 100% methanol (5min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab202666 at 1/100 dilution (shown in green) and ab195889, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 594), at 1/250 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  • Unconjugated

    Anti-PI3 Kinase p110 beta antibody [EPR5515(2)]

  • 617 Alexa Fluor® 594

    Alexa Fluor® 594 Anti-PI3 Kinase p110 beta antibody [EPR5515(2)]

  • 665 Alexa Fluor® 647

    Alexa Fluor® 647 Anti-PI3 Kinase p110 beta antibody [EPR5515(2)]

  • Carrier free

    Anti-PI3 Kinase p110 beta antibody [EPR5515(2)] - BSA and Azide free

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR5515(2)

Isotype

IgG

Conjugation

Alexa Fluor® 488

Excitation/Emission

Ex: 495nm, Em: 519nm

Carrier free

No

Reacts with

Human

Applications

ICC/IF

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100", "ICCIF-species-notes": "<p>This product gave a positive signal in HeLa cells fixed with 100% methanol (5 min).</p>" }, "Mouse": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Rat": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" } } }
style
left-column
style
left-column

Product details

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: 59% PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Stable for 12 months at -20°C|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

Phosphatidylinositol 3-kinase p110 beta (PI3 kinase p110β) also known as PI3Kβ is an enzyme that belongs to the class I PI3-kinases. It functions as a catalytic subunit in the PI3K complex. The PI3 kinase p110β has a molecular mass of approximately 122 kDa. This protein is expressed in various tissues with notable presence in heart and skeletal muscles. The enzyme is responsible for phosphorylating PIP2 to generate PIP3 an essential step in signaling pathways that regulate cell growth and survival.
Biological function summary

PI3 kinase p110β plays a role in the regulation of cellular processes such as proliferation migration and metabolism. It is a component of the PI3K complex comprised of regulatory and catalytic subunits which form functional homodimers or heterodimers. This complex is activated by various receptors including G-protein coupled receptors (GPCRs) and tyrosine kinase receptors. By converting PIP2 to PIP3 it aids in the recruitment and activation of downstream signaling proteins like AKT.

Pathways

PI3 kinase p110β is integral in the PI3K/AKT signaling pathway and also contributes to the regulation of the mTOR pathway. These pathways are critical for controlling cellular responses to growth signals and maintaining homeostasis. Association with proteins like PTEN which negatively regulates the PI3K/AKT pathway highlights its importance in maintaining cellular balance. PI3 kinase p110β also interacts with other PI3 proteins like p110α showing the intricate network of signaling it participates in.

PI3 kinase p110β has been implicated in cancer and cardiovascular diseases. Its overactivation leads to unchecked cellular proliferation contributing significantly to oncogenesis. Alterations in the PI3K/AKT/mTOR pathway are common in breast cancer highlighting its interaction with proteins such as ERBB2. In cardiovascular disorders PI3 kinase p110β influences heart development and function where it can impact the action of related proteins like PI3 kinase p110α. The study of PI3 kinase p110β in these diseases offers potential for targeted therapies and improved understanding of its pathological roles.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Phosphoinositide-3-kinase (PI3K) phosphorylates phosphatidylinositol derivatives at position 3 of the inositol ring to produce 3-phosphoinositides (PubMed : 15135396). Uses ATP and PtdIns(4,5)P2 (phosphatidylinositol 4,5-bisphosphate) to generate phosphatidylinositol 3,4,5-trisphosphate (PIP3) (PubMed : 15135396). PIP3 plays a key role by recruiting PH domain-containing proteins to the membrane, including AKT1 and PDPK1, activating signaling cascades involved in cell growth, survival, proliferation, motility and morphology. Involved in the activation of AKT1 upon stimulation by G-protein coupled receptors (GPCRs) ligands such as CXCL12, sphingosine 1-phosphate, and lysophosphatidic acid. May also act downstream receptor tyrosine kinases. Required in different signaling pathways for stable platelet adhesion and aggregation. Plays a role in platelet activation signaling triggered by GPCRs, alpha-IIb/beta-3 integrins (ITGA2B/ ITGB3) and ITAM (immunoreceptor tyrosine-based activation motif)-bearing receptors such as GP6. Regulates the strength of adhesion of ITGA2B/ ITGB3 activated receptors necessary for the cellular transmission of contractile forces. Required for platelet aggregation induced by F2 (thrombin) and thromboxane A2 (TXA2). Has a role in cell survival. May have a role in cell migration. Involved in the early stage of autophagosome formation. Modulates the intracellular level of PtdIns3P (phosphatidylinositol 3-phosphate) and activates PIK3C3 kinase activity. May act as a scaffold, independently of its lipid kinase activity to positively regulate autophagy. May have a role in insulin signaling as scaffolding protein in which the lipid kinase activity is not required. May have a kinase-independent function in regulating cell proliferation and in clathrin-mediated endocytosis. Mediator of oncogenic signal in cell lines lacking PTEN. The lipid kinase activity is necessary for its role in oncogenic transformation. Required for the growth of ERBB2 and RAS driven tumors. Has also a protein kinase activity showing autophosphorylation (PubMed : 12502714).
See full target information PIK3CB
style
left-column

Publications (3)

Recent publications for all applications. Explore the full list and refine your search

The FEBS journal 290:4562-4576 PubMed37255287

2023

PTPN22 activates the PI3K pathway via 14-3-3τ in T cells.

Applications

Unspecified application

Species

Unspecified reactive species

Bin Bai,Tao Wang,Xiaonan Zhang,Xinlei Ba,Na Zhang,Yanjiao Zhao,Xipeng Wang,Yang Yu,Bing Wang

Nature immunology 18:321-333 PubMed28135254

2017

The IgM receptor FcμR limits tonic BCR signaling by regulating expression of the IgM BCR.

Applications

Unspecified application

Species

Unspecified reactive species

Trang T T Nguyen,Kathrin Kläsener,Christa Zürn,Patricia A Castillo,Ingrid Brust-Mascher,Denise M Imai,Charles L Bevins,Colin Reardon,Michael Reth,Nicole Baumgarth

Critical reviews in immunology 36:163-177 PubMed27910766

2016

Natural IgM and the Development of B Cell-Mediated Autoimmune Diseases.

Applications

Unspecified application

Species

Unspecified reactive species

Trang T T Nguyen,Nicole Baumgarth
View all publications
style
left-column
style
left-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.
For full details, please see our Terms & Conditions
