Alexa Fluor® 555 Anti-CD3D antibody [EP4426]

2 product images

•

  Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 555 Anti-CD3D antibody [EP4426] (ab208514)

  ab208514 staining CD3 in Jurkat cells. The cells were fixed with 4% formaldehyde (10 min) and then incubated in 1%BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated overnight at +4°C with ab208514 at 1/100 dilution (pseudocolored in green) and Alexa Fluor® 647 Anti-Tubulin antibody [YOL1/34] - Microtubule Marker ab195884, Rat monoclonal to Tubulin (Alexa Fluor^® 647), at 1/250 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue).


  Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  This product also gave a positive signal under the same testing conditions in Jurkat cells fixed with 80% methanol (5 min).

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 555 Anti-CD3D antibody [EP4426] (ab208514)

  Immunohistochemistry analysis of paraffin-embedded human tonsil tissue sections labelling CD3D with ab208514 at 1/100 dilution. The section was incubated with ab208514 for 60 mins at room temperature (shown in green). Nuclear DNA was labeled with DAPI (shown in blue). Antigen retrieval was heat mediated with Tris-EDTA buffer (pH 9.0, epitope retrieval solution 2) for 40 minutes.
  Membrane staining on immune cells in human tonsil tissue. The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).
