Alexa Fluor® 555 Anti-CNPase antibody [11-5B]

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 555 Anti-CNPase antibody [11-5B] (AB317592)

Negative immunofluorescence staining of CNPase in a section of formalin-fixed paraffin-embedded mouse skeletal muscle*.

Performed on a Leica BOND™. The section was pre-treated using heat mediated antigen retrieval with EDTA (pH9.0) using retrieval settings of 110°C for 40 minutes. The section was then incubated at room temperature for 1 hour with ab317592 at 1/100 dilution. Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Dako Fluorescence Mounting Medium®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 555 Anti-CNPase antibody [11-5B] (AB317592)

ab317592 staining CNPase in primary hippocampal rat neurons/glia, (obtained from Neuromics, cat. no. PC35101), DIV14. The cells were fixed with 4% formaldehyde (10 min), permeabilised with 0.1% Tween for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab317592 at 5 μg/ml (shown in green). ab195884, Rat monoclonal to Tubulin (Alexa Fluor® 647) (shown in magenta) was used at 2 μg/ml for structural counterstaining.

Image was acquired with a confocal microscope (Leica-Microsystems TCS SP8) and a single confocal section is shown.

This product also work with 100% methanol (5 min) fixation under the same testing conditions.

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 555 Anti-CNPase antibody [11-5B] (AB317592)

Immunofluorescence staining of CNPase staining in a section of formalin-fixed paraffin-embedded mouse brain normal*.

Performed on a Leica BOND™. The section was pre-treated using heat mediated antigen retrieval with EDTA (pH9.0) using retrieval settings of 100°C for 40 minutes. The section was then incubated at room temperature for 1 hour with ab317592 at 1/100 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Dako Fluorescence Mounting Medium®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.
