AB225080

Alexa Fluor® 647 Anti-Band 3/AE 1 antibody [EPR1426]

RabMAb
Recombinant
What is this?

Be the first to review this product! Submit a review

(1 Publication)

Rabbit Recombinant Monoclonal Band 3/AE 1 antibody - conjugated to Alexa Fluor® 647. Suitable for IHC-P and reacts with Human samples. Cited in 1 publication.

View Alternative Names

CD233, AE1, DI, EPB3, SLC4A1, Band 3 anion transport protein, Anion exchange protein 1, Solute carrier family 4 member 1, AE 1, Anion exchanger 1

1 Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-Band 3/AE 1 antibody [EPR1426] (AB225080)

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-Band 3/AE 1 antibody [EPR1426] (AB225080)

IHC image of Band 3/AE 1 staining in a section of formalin-fixed paraffin-embedded normal human placenta*.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6) in a Biocare Medical NxGen pressure cooker using retrieval settings of 110^oC for 20 minutes. Non-specific protein-protein interactions were then blocked in TBS containing 0.025% (v/v) Triton X-100, 0.3M (w/v) glycine and 1% (w/v) BSA for 1h at room temperature. The section was then incubated overnight at +4°C in TBS containing 0.025% (v/v) Triton X-100 and 1% (w/v) BSA with ab225080 at 1/100 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Fluoromount^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre.

519 Alexa Fluor® 488

Alexa Fluor® 488 Anti-Band 3/AE 1 antibody [EPR1426]
Unconjugated

Anti-Band 3/AE 1 antibody [EPR1426]
Carrier free

Anti-Band 3/AE 1 antibody [EPR1426] - BSA and Azide free

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR1426

Isotype

IgG

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

Reacts with

Human

Applications

IHC-P

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": "<p></p> Perform heat-mediated antigen retrieval with citrate buffer pH 6 before commencing with IHC staining protocol." } } }

style

left-column

Product details

Patented technology
Our RabMAb^® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb^® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

- High batch-to-batch consistency and reproducibility
- Improved sensitivity and specificity
- Long-term security of supply
- Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style

left-column

Properties and storage information

Form

Liquid

Purification technique

Affinity purification Protein A

Storage buffer

pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Shipped at conditions

Blue Ice

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle|Store in the dark

style

left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

Band 3 also known as AE1 or Anion Exchanger 1 is an important protein found in red blood cells with a mass of approximately 100 kDa. It primarily facilitates the exchange of chloride (Cl-) and bicarbonate (HCO3-) ions across the cell membrane. This protein plays a significant role in maintaining the acid-base balance in the blood and in carbon dioxide transport. Besides red blood cells Band 3 is also expressed in the kidney specifically in the basolateral membrane of alpha-intercalated cells.

Biological function summary

Band 3 acts as a component of the larger protein complex responsible for the anion exchange process. It interacts with other proteins such as ankyrin and spectrin forming a structural link between the plasma membrane and the cytoskeleton. This interaction is essential in maintaining the red blood cell shape and flexibility. Band 3 also serves as a docking site for various glycolytic enzymes contributing to metabolic regulation within the cell.

Pathways

Band 3 plays a part in the bicarbonate transport pathway critical for regulating blood pH and carbon dioxide removal from tissues to the lungs. It closely interacts with carbonic anhydrase a protein that catalyzes the conversion between carbon dioxide and bicarbonate. Another pathway where Band 3 is involved is the erythrocyte cytoskeleton organization pathway in which it works with proteins like spectrin to stabilize the red blood cell membrane.

Band 3 mutations or deficiencies can lead to conditions like hereditary spherocytosis and distal renal tubular acidosis. Hereditary spherocytosis marked by hemolytic anemia involves the improper formation of red blood cells due to defective Band 3 interactions with ankyrin. Meanwhile a malfunction in Band 3's ion exchange capacity can result in distal renal tubular acidosis affecting the kidneys' ability to maintain acid-base homeostasis. Scientists study these conditions to understand better how Band 3 functions across different cell types and its interactions with related proteins.

style

left-column

style

left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

Target data

Functions both as a transporter that mediates electroneutral anion exchange across the cell membrane and as a structural protein (PubMed : 10926824, PubMed : 14734552, PubMed : 1538405, PubMed : 16227998, PubMed : 20151848, PubMed : 24121512, PubMed : 28387307, PubMed : 35835865). Component of the ankyrin-1 complex of the erythrocyte membrane; required for normal flexibility and stability of the erythrocyte membrane and for normal erythrocyte shape via the interactions of its cytoplasmic domain with cytoskeletal proteins, glycolytic enzymes, and hemoglobin (PubMed : 1538405, PubMed : 20151848, PubMed : 35835865). Functions as a transporter that mediates the 1 : 1 exchange of inorganic anions across the erythrocyte membrane. Mediates chloride-bicarbonate exchange in the kidney, and is required for normal acidification of the urine (PubMed : 10926824, PubMed : 14734552, PubMed : 16227998, PubMed : 24121512, PubMed : 28387307).. (Microbial infection) Acts as a receptor for P.falciparum (isolate 3D7) MSP9 and thus, facilitates merozoite invasion of erythrocytes (PubMed : 14630931). Acts as a receptor for P.falciparum (isolate 3D7) MSP1 and thus, facilitates merozoite invasion of erythrocytes (PubMed : 12692305).

See full target information SLC4A1

style

left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

iScience 28:112166 PubMed40201118

2025

Spatial transcriptomics delineates potential differences in intestinal phenotypes of cardiac and classical necrotizing enterocolitis.

Applications

Unspecified application

Species

Unspecified reactive species

Kathryn Y Burge,Constantin Georgescu,Hua Zhong,Adam P Wilson,Aarthi Gunasekaran,Zhongxin Yu,Addison Franca,Jeffrey V Eckert,Jonathan D Wren,Hala Chaaban

View all publications

style

left-column

style

left-column

style

right-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.

For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.

For licensing inquiries, please contact partnerships@abcam.com
