AB197499

Alexa Fluor® 647 Anti-CaMKII alpha antibody [6G9]

BOND RX™ Validated
What is this?

Be the first to review this product! Submit a review

(1 Publication)

Mouse Monoclonal KCC2A antibody - conjugated to Alexa Fluor® 647. Suitable for IHC-P and reacts with Human samples. Cited in 1 publication.

View Alternative Names

CAMKA, KIAA0968, CAMK2A, Calcium/calmodulin-dependent protein kinase type II subunit alpha, CaM kinase II subunit alpha, CaMK-II subunit alpha

2 Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-CaMKII alpha antibody [6G9] (AB197499)

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-CaMKII alpha antibody [6G9] (AB197499)

IHC image of CaMKII staining in a section of formalin-fixed paraffin-embedded normal human cerebellum.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6) in a Dako Pascal pressure cooker using the standard factory-set regime. Non-specific protein-protein interactions were then blocked in TBS containing 0.025% (v/v) Triton X-100, 0.3M (w/v) glycine and 1% (w/v) BSA for 1h at room temperature. The section was then incubated overnight at +4°C in TBS containing 0.025% (v/v) Triton X-100 and 1% (w/v) BSA with ab197499 at 1/100 (shown in red). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Fluoromount^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-CaMKII alpha antibody [6G9] (AB197499)

Immunofluorescence staining of CAMKII alpha staining in a section of formalin-fixed paraffin-embedded human cerebellum normal*.

Performed on a Leica BOND. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6.0) using retrieval settings of 100°C for 40 minutes. The section was then incubated at room temperature for 1 hour with ab197499 at 1/100 dilution (shown in magenta). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Dako Fluorescence Mounting Medium ^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre.

519 Alexa Fluor® 488

Alexa Fluor® 488 Anti-CaMKII alpha antibody [6G9]
HRP

HRP Anti-CaMKII alpha antibody [6G9]

Key facts

Host species

Mouse

Clonality

Monoclonal

Clone number

6G9

Isotype

IgG1

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

Reacts with

Rat, Human

Applications

IHC-P

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": "<p>This product gave a positive signal in human cerebellum tissue</p>", "ICCIF-species-checked": "notRecommended", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Rat": { "IHCP-species-checked": "predicted", "IHCP-species-dilution-info": "", "IHCP-species-notes": "", "ICCIF-species-checked": "notRecommended", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>" } } }

style

left-column

Product details

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style

left-column

Properties and storage information

Form

Liquid

Purification technique

Affinity purification

Storage buffer

pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle|Store in the dark

style

left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

CaMKII alpha also known as CAMK2A is an enzyme belonging to the CaMK kinase family. This protein is a calcium/calmodulin-dependent protein kinase and exhibits a molecular weight of approximately 50 to 60 kDa. CaMKII alpha is primarily expressed in the brain specifically in the hippocampus and other regions involved in synaptic activity. Due to its role as a serine/threonine kinase CaMKII alpha is significant in phosphorylating various substrates as part of cellular signaling.

Biological function summary

CaMKII alpha plays an important role in synaptic plasticity a process vital for learning and memory. The protein acts as an important component of the postsynaptic density complex where it interacts with other proteins to regulate synaptic strength. When calcium levels rise CaMKII alpha is activated through phosphorylation altering its conformation and allowing interactions with downstream substrates. This regulatory mechanism highlights its role in modulating neurotransmission synaptic potentiation and memory consolidation.

Pathways

CaMKII alpha functions within the calcium signaling pathway contributing to long-term potentiation (LTP) and long-term depression (LTD). It interacts with proteins such as NMDA receptors to facilitate changes in synaptic strength alongside other kinases. This pathway's activation leads to memory formation and synaptic plasticity in the central nervous system. Additionally CaMKII alpha connects with the MAPK signaling pathway integrating signals from various neurotransmitter systems which help coordinate neuronal response to stimuli.

Alterations in CaMKII alpha have been linked to neurological conditions such as Alzheimer's disease and schizophrenia. In Alzheimer's discourse in CaMKII alpha phosphorylation correlates with impaired memory and cognitive function. The protein also interfaces with tau another key protein related to neurofibrillary tangles in Alzheimer's. In schizophrenia abnormalities in CaMKII alpha expression and activity suggest its role in synaptic dysfunction and neurodevelopmental irregularities. Targeting CaMKII alpha may provide therapeutic opportunities for managing these and related neurological disorders.

style

left-column

style

left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

Target data

Calcium/calmodulin-dependent protein kinase that functions autonomously after Ca(2+)/calmodulin-binding and autophosphorylation, and is involved in various processes, such as synaptic plasticity, neurotransmitter release and long-term potentiation (PubMed : 14722083). Member of the NMDAR signaling complex in excitatory synapses, it regulates NMDAR-dependent potentiation of the AMPAR and therefore excitatory synaptic transmission (By similarity). Regulates dendritic spine development (PubMed : 28130356). Also regulates the migration of developing neurons (PubMed : 29100089). Phosphorylates the transcription factor FOXO3 to activate its transcriptional activity (PubMed : 23805378). Phosphorylates the transcription factor ETS1 in response to calcium signaling, thereby decreasing ETS1 affinity for DNA (By similarity). In response to interferon-gamma (IFN-gamma) stimulation, catalyzes phosphorylation of STAT1, stimulating the JAK-STAT signaling pathway (PubMed : 11972023). In response to interferon-beta (IFN-beta) stimulation, stimulates the JAK-STAT signaling pathway (PubMed : 35568036). Acts as a negative regulator of 2-arachidonoylglycerol (2-AG)-mediated synaptic signaling via modulation of DAGLA activity (By similarity).

See full target information CAMK2A

style

left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

ACS nano 18:3214-3233 PubMed38215338

2024

Nanoparticle-Conjugated Toll-Like Receptor 9 Agonists Improve the Potency, Durability, and Breadth of COVID-19 Vaccines.

Applications

Unspecified application

Species

Unspecified reactive species

Ben S Ou,Julie Baillet,Vittoria C T M Picece,Emily C Gale,Abigail E Powell,Olivia M Saouaf,Jerry Yan,Anahita Nejatfard,Hector Lopez Hernandez,Eric A Appel

View all publications

style

left-column

style

left-column

style

right-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.

For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
