AB205863

Alexa Fluor® 647 Anti-CaMKII antibody [EPR6686(2)]

Be the first to review this product! Submit a review

|

(0 Publication)

Rabbit Recombinant Monoclonal KCC2B antibody - conjugated to Alexa Fluor® 647. Suitable for ICC/IF and reacts with Human samples.

View Alternative Names

CAM2, CAMK2, CAMKB, CAMK2B, Calcium/calmodulin-dependent protein kinase type II subunit beta, CaM kinase II subunit beta, CaMK-II subunit beta

1 Images
Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-CaMKII antibody [EPR6686(2)] (AB205863)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-CaMKII antibody [EPR6686(2)] (AB205863)

ab205863 staining CaMKII in SKNSH cells. The cells were fixed with 4% formaldehyde (10 min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab205863 at a 1/1000 dilution (shown in red) and ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 488), at a 1/250 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  • Unconjugated

    Anti-CaMKII antibody [EPR6686(2)]

  • 660 APC

    APC Anti-CaMKII antibody [EPR6686(2)]

  • 519 Alexa Fluor® 488

    Alexa Fluor® 488 Anti-CaMKII antibody [EPR6686(2)]

  • Carrier free

    Anti-CaMKII antibody [EPR6686(2)] - BSA and Azide free

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR6686(2)

Isotype

IgG

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Human

Applications

ICC/IF

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/1000", "ICCIF-species-notes": "<p>This product gave a positive signal in SKNSH cells fixed with 4% formaldehyde (10 min)</p>" }, "Mouse": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Rat": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" } } }
style
left-column

You may be interested in:

AB234572

Human CAMK2B ELISA Kit

0

0 Reviews

View product

We recommend this product because it’s often used in the same experiment or related research.

We advise that you always check the datasheet to ensure it fits your experiments, or contact ourtechnical teamfor help.

style
left-column

Product details

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Stable for 12 months at -20°C|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

CaMKII also known as calcium/calmodulin-dependent protein kinase II is an enzyme functioning critically in cellular signaling. It consists of multiple isoforms including alpha beta gamma and delta with the delta isoform Delta 1829 frequently highlighted for its specific roles. The molecular weight of CaMKII is approximately 50 to 60 kDa varying slightly between isoforms. CaMKII is widely expressed in the brain but is also present in the heart skeletal muscle and other tissues. Its structure includes a catalytic domain regulatory segment and association domain which allows auto-regulation and interaction with other molecules.
Biological function summary

CaMKII plays a vital role in cellular processes such as learning memory and muscle contraction. It can form a complex structure involving multiple subunits which allows for its unique ability to signal in response to calcium influx and calmodulin binding. This causes autophosphorylation of CaMKII allowing it to remain active even when calcium levels diminish. This property makes CaMKII essential for long-term potentiation (LTP) in neuron synapses influencing cognitive functions deeply.

Pathways

CaMKII is an important component of both the calcium signaling and synaptic plasticity pathways. In the calcium signaling pathway CaMKII interacts with calmodulin and other kinases to modulate calcium entry and signaling. In synaptic plasticity CaMKII works closely with proteins like NMDA receptors which regulate synaptic strength and modulation essential for encoding learning and memory. These interactions highlight its significance as a mediator between signaling cascades and cellular responses.

Abnormal regulation or expression of CaMKII links to Alzheimer's disease and cardiac arrhythmias. In Alzheimer's the dysregulation of CaMKII affects synaptic integrity and memory formation involving interaction with beta-amyloid plaques. In cardiac arrhythmias CaMKII dysfunction leads to improper cardiac muscle contractions often linked to the protein phospholamban. These associations highlight the clinical relevance of CaMKII in addressing and understanding mechanisms underpinning these diseases.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Calcium/calmodulin-dependent protein kinase that functions autonomously after Ca(2+)/calmodulin-binding and autophosphorylation, and is involved in dendritic spine and synapse formation, neuronal plasticity and regulation of sarcoplasmic reticulum Ca(2+) transport in skeletal muscle (PubMed : 16690701). In neurons, plays an essential structural role in the reorganization of the actin cytoskeleton during plasticity by binding and bundling actin filaments in a kinase-independent manner. This structural function is required for correct targeting of CaMK2A, which acts downstream of NMDAR to promote dendritic spine and synapse formation and maintain synaptic plasticity which enables long-term potentiation (LTP) and hippocampus-dependent learning. In developing hippocampal neurons, promotes arborization of the dendritic tree and in mature neurons, promotes dendritic remodeling. Also regulates the migration of developing neurons (PubMed : 29100089). Participates in the modulation of skeletal muscle function in response to exercise (PubMed : 16690701). In slow-twitch muscles, is involved in regulation of sarcoplasmic reticulum (SR) Ca(2+) transport and in fast-twitch muscle participates in the control of Ca(2+) release from the SR through phosphorylation of triadin, a ryanodine receptor-coupling factor, and phospholamban (PLN/PLB), an endogenous inhibitor of SERCA2A/ATP2A2. In response to interferon-gamma (IFN-gamma) stimulation, catalyzes phosphorylation of STAT1, stimulating the JAK-STAT signaling pathway (By similarity). Phosphorylates reticulophagy regulator RETREG1 at 'Ser-151' under endoplasmic reticulum stress conditions which enhances RETREG1 oligomerization and its membrane scission and reticulophagy activity (PubMed : 31930741).
See full target information CAMK2B

Additional targets

CAMK2A,CAMK2G,CAMK2D
style
left-column
style
left-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.
For full details, please see our Terms & Conditions
