AB197702

Alexa Fluor® 647 Anti-CD11b antibody [M1/70]

Be the first to review this product! Submit a review

|

(3 Publications)

Rat Monoclonal CD11b antibody - conjugated to Alexa Fluor® 647. Suitable for ICC/IF and reacts with Mouse samples. Cited in 3 publications.

View Alternative Names

CD11b, Integrin alpha-M, CD11 antigen-like family member B, CR-3 alpha chain, Cell surface glycoprotein MAC-1 subunit alpha, Leukocyte adhesion receptor MO1, Itgam

1 Images
Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-CD11b antibody [M1/70] (AB197702)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-CD11b antibody [M1/70] (AB197702)

ab197702 staining CD11b in Raw264.7 cells. The cells were fixed with 4% formaldehyde (10min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab197702 at 1µg/ml (shown in red) and ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 488), at 2µg/ml (shown in green). Nuclear DNA was labelled with DAPI (shown in blue). Image was acquired with a high-content analyser (Operetta CLS, Perkin Elmer) and a maximum intensity projection of confocal sections is shown.

  • 519 Alexa Fluor® 488

    Alexa Fluor® 488 Anti-CD11b antibody [M1/70]

  • 617 Alexa Fluor® 594

    Alexa Fluor® 594 Anti-CD11b antibody [M1/70]

  • 578 PE

    PE Anti-CD11b antibody [M1/70]

  • 660 APC

    APC Anti-CD11b antibody [M1/70]

  • 450 violetFluor™ 450

    violetFluor™ 450 Anti-CD11b antibody [M1/70]

  • redFluor™ 710

    redFluor™ 710 Anti-CD11b antibody [M1/70]

  • 785 APC/Cy7®

    APC/Cy7® Anti-CD11b antibody [M1/70]

  • Biotin

    Biotin Anti-CD11b antibody [M1/70]

  • 578 PE

    PE Anti-CD11b antibody [M1/70]

  • 519 FITC

    FITC Anti-CD11b antibody [M1/70]

  • 667 PE/Cy5®

    PE/Cy5® Anti-CD11b antibody [M1/70]

  • 695 PerCP/Cy5.5®

    PerCP/Cy5.5® Anti-CD11b antibody [M1/70]

  • 778 PE/Cy7®

    PE/Cy7® Anti-CD11b antibody [M1/70]

  • Unconjugated

    Anti-CD11b antibody [M1/70]

  • Carrier free

    Anti-CD11b antibody [M1/70] - BSA and Azide free

Key facts

Host species

Rat

Clonality

Monoclonal

Clone number

M1/70

Isotype

IgG2b

Light chain type

unknown

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Mouse

Applications

ICC/IF

applications

style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Mouse": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/500", "ICCIF-species-notes": "<p></p>" }, "Rabbit": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" } } }
style
left-column

Product details

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.
style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein G
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

CD11b also known as Integrin alpha M is a protein with a molecular weight of approximately 170 kDa. This protein functions mechanically as an important adhesion molecule. It forms a complex with CD18 to become part of leukocyte-specific beta2 integrins specifically the Mac-1 (CR3) receptor. CD11b is largely expressed on the surface of various myeloid cells including monocytes macrophages granulocytes and a subset of natural killer cells. Researchers often utilize anti-CD11b antibodies and other markers such as APC or CD11b IHC to study its expression in different contexts.
Biological function summary

CD11b plays a critical role in various immune responses by mediating phagocytosis chemotaxis and cell migration. It is essential for proper leukocyte adherence to endothelial cells and for the engulfment of pathogens or apoptotic cells. CD11b as part of the Mac-1 complex contributes to the immune surveillance and inflammatory processes. This complex interacts with diverse ligands like ICAM-1 fibrinogen and complement component iC3b facilitating an immunological response.

Pathways

CD11b is instrumental within the integrin signaling pathway and the Leukocyte Transendothelial Migration pathway. Its interaction with ICAM-1 is central to the leukocyte adhesion cascade influencing the movement of immune cells across endothelial barriers. CD11b also associates with proteins such as Src family kinases and PI3K which activate downstream signaling responsible for the reorganization of the cytoskeleton and cell movement during immune responses.

CD11b is linked to inflammatory conditions like rheumatoid arthritis and systemic lupus erythematosus. Aberrant expression or function of CD11b can result in improper immune regulation contributing to the pathogenesis of these diseases. Its interaction with complement receptor iC3b plays a part in inflammation and tissue damage observed in these conditions. Consequently CD11b represents a potential target for therapeutic intervention in diseases where dysregulated immune activity is a feature.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Integrin ITGAM/ITGB2 is implicated in various adhesive interactions of monocytes, macrophages and granulocytes as well as in mediating the uptake of complement-coated particles and pathogens (By similarity). It is identical with CR-3, the receptor for the iC3b fragment of the third complement component. It probably recognizes the R-G-D peptide in C3b. Integrin ITGAM/ITGB2 is also a receptor for fibrinogen, factor X and ICAM1. It recognizes P1 and P2 peptides of fibrinogen gamma chain. Regulates neutrophil migration. In association with beta subunit ITGB2/CD18, required for CD177-PRTN3-mediated activation of TNF primed neutrophils (By similarity). May regulate phagocytosis-induced apoptosis in extravasated neutrophils (By similarity). May play a role in mast cell development (By similarity). Required with TYROBP/DAP12 in microglia to control production of microglial superoxide ions which promote the neuronal apoptosis that occurs during brain development (PubMed : 18685038).
See full target information Itgam
style
left-column

Publications (3)

Recent publications for all applications. Explore the full list and refine your search

Nutrients 16: PubMed39408267

2024

The Influence of Strain and Sex on High Fat Diet-Associated Alterations of Dopamine Neurochemistry in Mice.

Applications

Unspecified application

Species

Unspecified reactive species

Kristen A Hagarty-Waite,Heather A Emmons,Steve C Fordahl,Keith M Erikson

The American journal of pathology 194:2194-2211 PubMed39159867

2024

Immunoregulatory Properties of Immune Cells that Associate with the Lens Capsule Surface during Acute and Resolution Phases of Experimental Autoimmune Uveitis.

Applications

Unspecified application

Species

Unspecified reactive species

Phuong M Le,Mary J Mattapallil,Rachel R Caspi,Mary Ann Stepp,A Sue Menko

Journal of immunology (Baltimore, Md. : 1950) 196:3780-93 PubMed27036913

2016

Identification of Immune Effectors Essential to the Control of Primary and Secondary Intranasal Infection with Brucella melitensis in Mice.

Applications

Unspecified application

Species

Unspecified reactive species

Delphine Hanot Mambres,Arnaud Machelart,Georges Potemberg,Carl De Trez,Bernhard Ryffel,Jean-Jacques Letesson,Eric Muraille
View all publications
