AB200430

Alexa Fluor® 647 Anti-Collagen VI antibody [EPR17072]

Be the first to review this product! Submit a review

|

(1 Publication)

Rabbit Recombinant Monoclonal COL6A1 antibody - conjugated to Alexa Fluor® 647. Suitable for IHC-P, ICC/IF and reacts with Human, Mouse, Rat samples. Cited in 1 publication.

View Alternative Names

Collagen alpha-1(VI) chain, COL6A1

1 Images
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-Collagen VI antibody [EPR17072] (AB200430)
  • IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-Collagen VI antibody [EPR17072] (AB200430)

IHC image of Collagen VI staining in a section of formalin-fixed paraffin-embedded normal human kidney*.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6) in a Dako Pascal pressure cooker using the standard factory-set regime. Non-specific protein-protein interactions were then blocked in TBS containing 0.025% (v/v) Triton X-100, 0.3M (w/v) glycine and 1% (w/v) BSA for 1h at room temperature. The section was then incubated overnight at +4°C in TBS containing 0.025% (v/v) Triton X-100 and 1% (w/v) BSA with ab200430 at 1/100 (shown in red) and counterstained using ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 488), at 1/250 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Fluoromount®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

  • HRP

    HRP Anti-Collagen VI antibody [EPR17072]

  • 519 Alexa Fluor® 488

    Alexa Fluor® 488 Anti-Collagen VI antibody [EPR17072]

  • Unconjugated

    Anti-Collagen VI antibody [EPR17072]

  • Carrier free

    Anti-Collagen VI antibody [EPR17072] - Low endotoxin, Azide free

  • Carrier free

    Anti-Collagen VI antibody [EPR17072] - BSA and Azide free

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR17072

Isotype

IgG

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Human, Human, Mouse, Rat

Applications

IHC-P, ICC/IF

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Alternative Products

Primary Antibodies

AB6588

Anti-Collagen VI antibody

Western blot - Anti-Collagen VI antibody (AB6588)

  • 5
  • 21
Primary Antibodies

AB199720

Anti-Collagen VI antibody [EPR17077] - C-terminal

RabMAb|Recombinant|KO Validated|Trial Size

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Collagen VI antibody [EPR17077] - C-terminal (AB199720)

  • 3
  • 4
Primary Antibodies

AB172606

Anti-Collagen VI antibody [EPR7888(N)]

RabMAb|Recombinant

Western blot - Anti-Collagen VI antibody [EPR7888(N)] (AB172606)

  • 0
  • 0
Primary Antibodies

AB240350

Anti-Collagen VI antibody [EPR17077] - BSA and Azide free

RabMAb|Recombinant|KO Validated

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Collagen VI antibody [EPR17077] - BSA and Azide free (AB240350)

  • 0
  • 0

Complementary Products

Assay Kits

AB222942

Total Collagen Assay Kit (Perchlorate-Free)

Functional Studies - Total Collagen Assay Kit (Perchlorate-Free) (AB222942)

  • 4
  • 1
Reagents, Controls & Accessories

AB246832

Picro-Sirius Red Solution

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Picro-Sirius Red Solution (AB246832)

  • 0
  • 0
Primary Antibodies

AB280968

Alexa Fluor® 647 Anti-Collagen I antibody [EPR7785]

RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-Collagen I antibody [EPR7785] (AB280968)

  • 1
  • 1
Primary Antibodies

AB180855

Anti-Collagen VI alpha 2 antibody [EPR7889(N)]

BOND RX™ Validated|RabMAb|Recombinant|Trial Size

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Collagen VI alpha 2 antibody [EPR7889(N)] (AB180855)

  • 4
  • 1
Secondary Antibodies

AB150077

Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488)

Immunocytochemistry/ Immunofluorescence - Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) (AB150077)

  • 5
  • 20
Primary Antibodies

AB198934

Alexa Fluor® 647 Anti-Fibronectin antibody [F1]

RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-Fibronectin antibody [F1] (AB198934)

  • 0
  • 0
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/100", "IHCP-species-notes": "<p></p> Perform heat-mediated antigen retrieval with citrate buffer pH 6 before commencing with IHC staining protocol.", "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>" }, "Mouse": { "IHCP-species-checked": "guaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>", "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>" }, "Rat": { "IHCP-species-checked": "guaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>", "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>" } } }
style
left-column

Product details

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Stable for 12 months at -20°C|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

Collagen VI also known as Collagen 6 is a type of collagen that plays an important role in the extracellular matrix. It consists of three different chains: α1(VI) α2(VI) and α3(VI) with a combined mass of approximately 140 kDa. This collagen type strongly associates with several tissues notably in skeletal muscle skin and the walls of blood vessels. Scientists often study collagen VI with specific collagen antibodies to understand its unique structural properties and its end which binds to other matrix components.
Biological function summary

Collagen VI contributes to structural integrity and cellular scaffolding within tissues. This protein is integral to the formation of microfibrillar networks part of a larger complex that connects the extracellular matrix to cells and other matrix components. Its protective role helps cells resist mechanical stress and the network provided by collagen VI powder stabilizes the tissue architecture. Additionally low endotoxin collagen is often preferable in research to minimize inflammatory responses during experimentation providing more accurate results.

Pathways

Collagen VI participates in extracellular matrix organization and mechanotransduction pathways. It functions alongside other proteins like collagen I and IV. In particular collagen VI interacts with cell surface receptors which influences cellular communication and signaling pathways. This interaction plays a role in transmitting mechanical signals that affect cellular behavior and function proving important for tissue maintenance and repair processes.

Mutations or malfunctions involving collagen VI can lead to significant clinical outcomes. It is prominently linked with disorders such as Ullrich congenital muscular dystrophy and Bethlem myopathy both affecting muscle and connective tissue. These conditions often involve disruptions in the assembly or function of the collagen VI network. Additionally related proteins like collagen I and integrin proteins can influence the progression and severity of these disorders illustrating the interconnected nature of these extracellular elements.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Collagen VI acts as a cell-binding protein.
See full target information COL6A1
style
left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

Communications biology 5:1263 PubMed36400937

2022

UnMICST: Deep learning with real augmentation for robust segmentation of highly multiplexed images of human tissues.

Applications

Unspecified application

Species

Unspecified reactive species

Clarence Yapp,Edward Novikov,Won-Dong Jang,Tuulia Vallius,Yu-An Chen,Marcelo Cicconet,Zoltan Maliga,Connor A Jacobson,Donglai Wei,Sandro Santagata,Hanspeter Pfister,Peter K Sorger
View all publications
style
left-column
style
left-column
style
right-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.
For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.

For licensing inquiries, please contact partnerships@abcam.com
