AB197491

Alexa Fluor® 647 Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker

Be the first to review this product! Submit a review

|

(2 Publications)

Mouse Monoclonal COX IV antibody - conjugated to Alexa Fluor® 647. Mitochondrion marker. Suitable for ICC/IF and reacts with Human samples. Cited in 2 publications.

View Alternative Names

COX4, COX4I1, Cytochrome c oxidase polypeptide IV, Cytochrome c oxidase subunit IV isoform 1, COX IV-1

2 Images
Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker (AB197491)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker (AB197491)

ab197491 staining COX IV in HeLa cells. The cells were fixed with 100% methanol (5min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab197491 at 1/1000 dilution (shown in red) and ab6046 (Rabbit polyclonal to beta Tubulin) at 1μg/ml. This was followed by an incubation at room temperature for 1h with ab150081, Goat polyclonal Secondary Antibody to Rabbit IgG - H&L (Alexa Fluor® 488), pre-adsorbed, at 1μg/ml (shown in green). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker (AB197491)
  • ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker (AB197491)

Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% Triton X-100 permeabilized MCF7 (human breast adenocarcinoma epithelial cell) cells labelling BCAT2 with ab307833 at 1/500 dilution (1.1 ug/ml) followed by ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed antibody at 1/1000 dilution (2 ug/ml) (Green). Confocal image showing mitochondrial staining in MCF7 cell line. Image was taken with a confocal microscope(Leica-Microsystems, TCS SP8). ab197491 Anti-COX IV Mouse monoclonal antibody (Alexa Fluor® 647) - Mitochondrial Marker was used to counterstain tubulin at 1/200 dilution (2.5 ug/ml)(Red). The nuclear counterstain was DAPI (Blue). Secondary antibody only control : Secondary antibody is ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 dilution (2 ug/ml).

  • HRP

    HRP Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker

  • Unconjugated

    Anti-COX IV antibody [mAbcam33985] - Mitochondrial Marker

Key facts

Host species

Mouse

Clonality

Monoclonal

Clone number

mAbcam33985

Isotype

IgG1

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Human

Applications

ICC/IF

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Alternative Products

Primary Antibodies

AB210180

Alexa Fluor® 405 Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Marker

RabMAb|Recombinant

Flow Cytometry (Intracellular) - Alexa Fluor® 405 Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Marker (AB210180)

  • 4
  • 2
Primary Antibodies

AB210674

Alexa Fluor® 594 Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Marker

RabMAb|Recombinant

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 594 Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Marker (AB210674)

  • 0
  • 0
Primary Antibodies

AB209958

HRP Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Marker

BOND RX™ Validated|RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - HRP Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Marker (AB209958)

  • 0
  • 0
Primary Antibodies

AB202554

Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Loading Control

RabMAb|Recombinant|Lab Essentials|Advanced Validation|20ul selling size

Multiplex immunohistochemistry - Anti-COX IV antibody [EPR9442(ABC)] - Mitochondrial Loading Control (AB202554)

  • 5
  • 2
Primary Antibodies

AB231168

Anti-COX IV antibody [EPR9442(ABC)] - BSA and Azide free - Mitochondrial Marker

RabMAb|Recombinant|Advanced Validation

Immunocytochemistry/ Immunofluorescence - Anti-COX IV antibody [EPR9442(ABC)] - BSA and Azide free - Mitochondrial Marker (AB231168)

  • 0
  • 0

Complementary Products

Assay Kits

AB239711

Cytochrome C Oxidase Assay Kit

Functional Studies - Cytochrome C Oxidase Assay Kit (AB239711)

  • 0
  • 0
Primary Antibodies

AB14705

Anti-MTCO1 antibody [1D6E1A8]

BOND RX™ Validated|Recombinant

Western blot - Anti-MTCO1 antibody [1D6E1A8] (AB14705)

  • 5
  • 44
Secondary Antibodies

AB150077

Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488)

Immunocytochemistry/ Immunofluorescence - Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) (AB150077)

  • 5
  • 20
Primary Antibodies

AB14734

Anti-VDAC1/Porin + VDAC3 antibody [20B12AF2] - Mitochondrial Loading Control

Recombinant|Lab Essentials

Western blot - Anti-VDAC1/Porin + VDAC3 antibody [20B12AF2] - Mitochondrial Loading Control (AB14734)

  • 5
  • 52
Primary Antibodies

AB40742

HRP Anti-alpha Tubulin antibody [DM1A] - Loading Control

BOND RX™ Validated

Western blot - HRP Anti-alpha Tubulin antibody [DM1A] - Loading Control (AB40742)

  • 5
  • 5
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/1000", "ICCIF-species-notes": "<p></p>" } } }
style
left-column

Product details

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.
style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

Cytochrome c oxidase subunit IV commonly known as COX IV is a component of the enzyme complex located in the inner mitochondrial membrane. COX IV has a molecular weight of approximately 17 kDa and serves as a subunit of the larger cytochrome c oxidase complex which is essential in cellular respiration. As a mitochondrial marker COX IV is expressed in various tissues where it acts as an important player in the electron transport chain. The presence and function of COX IV are critical in facilitating the last step of the mitochondrial respiratory chain.
Biological function summary

COX IV acts as a significant part of the cytochrome c oxidase complex helping catalyze the reduction of oxygen to water. This process is an important step in the overall mechanism of oxidative phosphorylation. COX IV's role in this complex enables the proton gradient generation across the inner mitochondrial membrane which is necessary for ATP synthesis. Its activity regulates the efficiency of cellular respiration impacting energy production and metabolic activities within cells.

Pathways

COX IV functionally interacts within the oxidative phosphorylation and electron transport chain pathways. Its coordination with other proteins like COX I and COX II in the cytochrome c oxidase complex ensures proper electron transfer to oxygen. Additionally COX IV is implicated in the regulation of reactive oxygen species maintaining cellular homeostasis. These pathways interconnect with broader cellular mechanisms that involve energy metabolism and apoptosis.

COX IV has been linked to mitochondrial disorders where defects in the oxidative phosphorylation processes can lead to conditions such as mitochondrial encephalomyopathy. Abnormalities in COX IV function and expression can also contribute to neurodegenerative diseases including Parkinson's disease. Here interactions with proteins like superoxide dismutase (SOD) highlight how oxidative stress and mitochondrial dysfunction relate closely to disease progression. These associations underline the importance of COX IV in maintaining cellular and organismal health.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Component of the cytochrome c oxidase, the last enzyme in the mitochondrial electron transport chain which drives oxidative phosphorylation. The respiratory chain contains 3 multisubunit complexes succinate dehydrogenase (complex II, CII), ubiquinol-cytochrome c oxidoreductase (cytochrome b-c1 complex, complex III, CIII) and cytochrome c oxidase (complex IV, CIV), that cooperate to transfer electrons derived from NADH and succinate to molecular oxygen, creating an electrochemical gradient over the inner membrane that drives transmembrane transport and the ATP synthase. Cytochrome c oxidase is the component of the respiratory chain that catalyzes the reduction of oxygen to water. Electrons originating from reduced cytochrome c in the intermembrane space (IMS) are transferred via the dinuclear copper A center (CU(A)) of subunit 2 and heme A of subunit 1 to the active site in subunit 1, a binuclear center (BNC) formed by heme A3 and copper B (CU(B)). The BNC reduces molecular oxygen to 2 water molecules using 4 electrons from cytochrome c in the IMS and 4 protons from the mitochondrial matrix.
See full target information COX4I1
style
left-column

Publications (2)

Recent publications for all applications. Explore the full list and refine your search

Nature communications 16:4373 PubMed40355410

2025

Spatial mapping of the brain metabolome lipidome and glycome.

Applications

Unspecified application

Species

Unspecified reactive species

Harrison A Clarke,Xin Ma,Cameron J Shedlock,Terrymar Medina,Tara R Hawkinson,Lei Wu,Roberto A Ribas,Shannon Keohane,Sakthivel Ravi,Jennifer L Bizon,Sara N Burke,Jose Francisco Abisambra,Matthew E Merritt,Boone M Prentice,Craig W Vander Kooi,Matthew S Gentry,Li Chen,Ramon C Sun

Blood advances 7:6035-6047 PubMed37276076

2023

Uptake of long-chain fatty acids from the bone marrow suppresses CD8+ T-cell metabolism and function in multiple myeloma.

Applications

Unspecified application

Species

Unspecified reactive species

Nancy Gudgeon,Hannah Giles,Emma L Bishop,Taylor Fulton-Ward,Cristina Escribano-Gonzalez,Haydn Munford,Anna James-Bott,Kane Foster,Farheen Karim,Dedunu Jayawardana,Ansar Mahmood,Adam P Cribbs,Daniel A Tennant,Supratik Basu,Guy Pratt,Sarah Dimeloe
