AB307470

Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166]

Be the first to review this product! Submit a review

|

(4 Publications)

Anti-F4/80 antibody [EPR26545-166] - Alexa Fluor® 647 conjugated (ab307470) is a rabbit recombinant monoclonal antibody detecting F4/80 in IHC-P, IHC-Fr. Suitable for Mouse, Rat.

- Biophysical QC for unrivalled batch-batch consistency

View Alternative Names

Emr1, Gpf480, Adgre1, Adhesion G protein-coupled receptor E1, Cell surface glycoprotein F4/80, EGF-like module receptor 1, EGF-like module-containing mucin-like hormone receptor-like 1, EMR1 hormone receptor

5 Images
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)

Immunohistochemical analysis of paraffin-embedded Mouse cardiac muscle tissue labeling F4/80 with ab307470 at 1/50 (10.0 μg/ml) dilution. Negative control : no staining on mouse cardiac muscle. The section was incubated with ab307470 for 60 mins at room temperature (shown in red). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 40 mins.

Immunohistochemistry (Frozen sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)
  • IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)

Immunohistochemistry (Frozen sections) analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized mouse spleen (fresh) tissue labeling F4/80 with ab307470 at 1/50 (10 μg/ml). Positive staining on mouse spleen. The nuclear counterstain was DAPI (Blue).

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)

Immunohistochemical analysis of paraffin-embedded Rat liver tissue labeling F4/80 with ab307470 at 1/50 (10.0 μg/ml) dilution. Positive staining on Kupffer cells of rat liver. The section was incubated with ab307470 for 60 mins at room temperature (shown in red). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 40 mins.

Immunohistochemistry (Frozen sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)
  • IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)

Immunohistochemistry (Frozen sections) analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized mouse cardiac muscle (fresh) tissue labeling F4/80 with ab307470 at 1/50 (10 μg/ml). Negative control : no staining on mouse cardiac muscle. The nuclear counterstain was DAPI (Blue).

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (AB307470)

Immunohistochemical analysis of paraffin-embedded Mouse liver tissue labeling F4/80 with ab307470 at 1/50 (10.0 μg/ml) dilution. Positive staining on Kupffer cells of mouse liver. The section was incubated with ab307470 for 60 mins at room temperature (shown in red). Nuclear DNA was labeled with DAPI (shown in blue). The section was then mounted using Fluoromount®. The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8). Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 40 mins.

  • Unconjugated

    Anti-F4/80 antibody [EPR26545-166]

  • Carrier free

    Anti-F4/80 antibody [EPR26545-166] – Chicken IgY (Chimeric) – BSA and Azide Free

  • Carrier free

    Anti-F4/80 antibody [EPR26545-166] (BSA and Azide free)

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR26545-166

Isotype

IgG

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Rat, Mouse, Mouse, Rat

Applications

IHC-Fr, IHC-P, ICC/IF

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Complementary Products

Primary Antibodies

AB307523

Alexa Fluor® 647 Anti-CD11b antibody [EPR1344]

BOND RX™ Validated|RabMAb|Recombinant

Immunohistochemistry - Alexa Fluor® 647 Anti-CD11b antibody [EPR1344] (AB307523)

  • 0
  • 0
Primary Antibodies

AB283492

Alexa Fluor® 555 Anti-Arg2 antibody [EPR22626-38]

BOND RX™ Validated|RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 555 Anti-Arg2 antibody [EPR22626-38] (AB283492)

  • 0
  • 0
Primary Antibodies

AB277275

Alexa Fluor® 488 Anti-CD4 antibody [EPR19514]

BOND RX™ Validated|RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Alexa Fluor® 488 Anti-CD4 antibody [EPR19514] (AB277275)

  • 1
  • 1
Secondary Antibodies

AB150077

Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488)

Immunocytochemistry/ Immunofluorescence - Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) (AB150077)

  • 5
  • 20
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "IHCFr" : {"fullname" : "Immunohistochemistry (Frozen sections)", "shortname":"IHC-Fr"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Mouse": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/50", "IHCP-species-notes": "<p></p>", "IHCFr-species-checked": "testedAndGuaranteed", "IHCFr-species-dilution-info": "1/50", "IHCFr-species-notes": "<p></p>", "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>" }, "Rat": { "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "1/50", "IHCP-species-notes": "<p></p>", "IHCFr-species-checked": "guaranteed", "IHCFr-species-dilution-info": "", "IHCFr-species-notes": "", "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>" } } }
style
left-column

Product details

What is this antibody validated in?
Alexa Fluor® 647 Anti-F4/80 antibody [EPR26545-166] (ab307470) is a rabbit recombinant monoclonal antibody and is validated for use in Immunohistochemistry (IHC-P), Immunohistochemistry (IHC-Fr) in Mouse, Rat samples.

Trial sizes available!
Test your antibody or perform pre-screening before committing to a larger quantity. Sold in 10µl. Discover our selection of trial-size antibodies.

Related products
Antibody clone EPR26545-166 is also available pre-conjugated to a variety of labels for your convenience – Anti-F4/80 Alexa Fluor® 647 [EPR26545-166] (ab307470).

Other related products
We have a range of other formats of antibody clone [EPR26545-166] also available for your convenience: ab300421, Carrier free - ab300422, Alexa Fluor® 647 - ab307470, ab320060, Carrier free - ab320061

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

F4/80 also known as Emr1 (Epidermal growth factor module-containing mucin-like hormone receptor 1) is a well-characterized surface protein with a mass of approximately 160 kDa. This protein is recognized as a marker for murine macrophages. F4/80 is heavily expressed on cells of the monocyte and macrophage lineage particularly in tissue-resident macrophages found in organs like the liver spleen and lung. Its expression is vital for identifying macrophages in various types of immunological studies including F4/80 staining and macrophage marker analysis.
Biological function summary

F4/80 plays a role in modulating the immune response by interacting with other cell surface molecules. While not part of a larger protein complex F4/80 influences macrophage functions such as phagocytosis and cytokine production. Its expression contributes to the regulation of tissue homeostasis and inflammation. The protein is critical in maintaining the macrophage population required for reliable immune surveillance and response to pathogens.

Pathways

F4/80 is an integral part of the immunological and inflammatory signaling pathways. It interacts with TLRs (Toll-like receptors) and other cell surface molecules that sense microbial components therefore helping in the initiation of innate immune responses. F4/80 is connected to proteins like cytokine receptors which play roles in mediating and resolving inflammatory signals important for maintaining balanced immune activity.

F4/80 is associated with conditions like chronic inflammation and autoimmune disorders. Its expression levels can often correlate with disease state impacting diseases such as rheumatoid arthritis and liver fibrosis. In these conditions F4/80 interacts with proteins like TNF-alpha and IL-1beta which are involved in inflammatory processes. Understanding F4/80's role can help uncover therapeutic targets aimed at modulating macrophage functions to treat these disorders effectively.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Orphan receptor involved in cell adhesion and probably in cell-cell interactions specifically involving cells of the immune system. May play a role in regulatory T-cells (Treg) development.
See full target information Adgre1
style
left-column

Publications (4)

Recent publications for all applications. Explore the full list and refine your search

Molecular medicine (Cambridge, Mass.) 31:281 PubMed40849639

2025

CAF-derived exosomes drive the FGF4/SHH feedback loop by encapsulating GREM1 in non-small cell lung cancer.

Applications

Unspecified application

Species

Unspecified reactive species

Xianqiao Wu,Wei Chen,Tianzheng Fang,Ziyuan Chen,Shuai Fang,Chengwei Zhou

Bone reports 26:101865 PubMed40822620

2025

Long-term tissue engineered periosteum-mediated allograft healing is hindered due to persistent fibrosis and limited allograft remodeling.

Applications

Unspecified application

Species

Unspecified reactive species

Alyson March,Sandra H Castillo Aguirre,Roman Eliseev,Regine Choe,Danielle S W Benoit

FASEB bioAdvances 7:e70008 PubMed40330429

2025

Ogerin induced activation of Gpr68 alters tendon healing.

Applications

Unspecified application

Species

Unspecified reactive species

Andrew Rodenhouse,Gilbert Smolyak,Emmanuela Adjei-Sowah,Neeta Adhikari,Samantha Muscat,Takuma Okutani,Constantinos Ketonis,Anne E C Nichols,Robert M Kottmann,Alayna E Loiselle

Biomedicines 13: PubMed40299436

2025

TGF-β1 Improves Nerve Regeneration and Functional Recovery After Sciatic Nerve Injury by Alleviating Inflammation.

Applications

Unspecified application

Species

Unspecified reactive species

Maorong Jiang,Zihan Ding,Yuxiao Huang,Taoran Jiang,Yiming Xia,Dandan Gu,Xi Gu,Huiyuan Bai,Dengbing Yao
View all publications
style
left-column
style
left-column
style
right-column

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.
For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.

For licensing inquiries, please contact partnerships@abcam.com
