AB205813

Alexa Fluor® 647 Anti-M6PR (cation independent) antibody [2G11] - Lysosome Membrane Marker

Name: Anti-M6PR (cation independent) Alexa Fluor® 647 antibody [2G11] (ab205813) | Abcam
Brand: Abcam Limited
SKU: AB205813
Price: 585 USD
Availability: InStock

Be the first to review this product! Submit a review

(1 Publication)

Mouse Monoclonal M6PR (cation independent) antibody - conjugated to Alexa Fluor® 647. Suitable for ICC/IF and reacts with Human samples. Cited in 1 publication.

View Alternative Names

CD222, MPRI, IGF2R, Cation-independent mannose-6-phosphate receptor, CI Man-6-P receptor, CI-MPR, M6PR, 300 kDa mannose 6-phosphate receptor, Insulin-like growth factor 2 receptor, Insulin-like growth factor II receptor, M6P/IGF2 receptor, MPR 300, IGF-II receptor, M6P/IGF2R

1 Images

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-M6PR (cation independent) antibody [2G11] - Lysosome Membrane Marker (AB205813)

ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-M6PR (cation independent) antibody [2G11] - Lysosome Membrane Marker (AB205813)

ab205813 staining M6PR (cation independent) in HeLa cells. The cells were fixed with 4% formaldehyde (10 min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab205813 at 1/50 dilution (shown in red) and ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor^® 488), at 1/250 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

This product also gave a positive signal under the same testing conditions in HeLa cells fixed with 100% methanol (5min).

519 Alexa Fluor® 488

Alexa Fluor® 488 Anti-M6PR (cation independent) antibody [2G11] - Lysosome Membrane Marker
578 PE

PE Anti-MHC Class II antibody [2G11]
519 FITC

FITC Anti-MHC Class II antibody [2G11]
Unconjugated

Anti-M6PR (cation independent) antibody [2G11]

Key facts

Host species

Mouse

Clonality

Monoclonal

Clone number

2G11

Isotype

IgG2a

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

Reacts with

Human

Applications

ICC/IF

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style

left-column

style

left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/50", "ICCIF-species-notes": "<p>This product gave a positive signal in HeLa cells fixed with 4% formaldehyde (10 min) and 100% methanol (5 min)</p>" }, "Mouse": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Rat": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "African green monkey": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Cow": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" }, "Primates": { "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "" } } }

style

left-column

Product details

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style

left-column

Properties and storage information

Form

Liquid

Purity

IgG fraction

Storage buffer

pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle|Store in the dark

style

left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

The cation-independent mannose 6-phosphate receptor (M6PR) is an important player in cellular transport mechanisms. Also known as the insulin-like growth factor 2 receptor (IGF2R) this protein weighs approximately 300 kDa. M6PR is present on the membrane of lysosomes and works as a lysosome membrane marker. It functions as a sorting receptor in the Golgi apparatus and endosomes facilitating the transport of lysosomal enzymes from the Golgi to lysosomes and back for function and degradation.

Biological function summary

The M6PR enables essential cellular processes by mediating the trafficking of enzymes important to lysosomal function. This receptor takes part in recognizing and binding proteins tagged with mannose 6-phosphate signals allowing their transport to lysosomes. IGF2R engages in forming transient complexes with these enzymes within the cellular trafficking circuitry therefore ensuring the proper delivery of enzyme cargo to its target destination.

Pathways

M6PR fits importantly within lysosomal enzyme transport and the insulin-like growth factor (IGF) pathway. It partially regulates the homeostasis of IGF2 by facilitating its degradation modulating cell proliferation growth and development. Steric interactions with IGF2 and other proteins like mannose receptor homologs and IGF-binding proteins outline its influence within these pathways highlighting its multifunctionality.

M6PR connects to certain cancers and lysosomal storage disorders. Dysfunctional pathway interactions or mutations within IGF2R often relate with types of cancer such as breast and liver cancers due to its influence on IGF2 regulation and cell proliferation. Additionally it associates with lysosomal storage diseases as lysosome-related pathologies emerge from impaired enzyme transport reflecting the M6PR's intricate role in cellular homeostasis.

style

left-column

style

left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:

Visit the General protocols
Visit the Troubleshooting

style

left-column

Target data

Mediates the transport of phosphorylated lysosomal enzymes from the Golgi complex and the cell surface to lysosomes (PubMed : 18817523, PubMed : 2963003). Lysosomal enzymes bearing phosphomannosyl residues bind specifically to mannose-6-phosphate receptors in the Golgi apparatus and the resulting receptor-ligand complex is transported to an acidic prelysosomal compartment where the low pH mediates the dissociation of the complex (PubMed : 18817523, PubMed : 2963003). The receptor is then recycled back to the Golgi for another round of trafficking through its binding to the retromer (PubMed : 18817523). This receptor also binds IGF2 (PubMed : 18046459). Acts as a positive regulator of T-cell coactivation by binding DPP4 (PubMed : 10900005).

See full target information IGF2R

style

left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

Scientific reports 9:8006 PubMed31142756

2019

HIV Infection Induces Extracellular Cathepsin B Uptake and Damage to Neurons.

Applications

Unspecified application

Species

Unspecified reactive species

Yisel M Cantres-Rosario,Sarah C Ortiz-Rodríguez,Aemil G Santos-Figueroa,Marines Plaud,Karla Negron,Bianca Cotto,Dianne Langford,Loyda M Melendez

View all publications
