AB198106

Alexa Fluor® 647 Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker

Be the first to review this product! Submit a review

|

(1 Publication)

Mouse Monoclonal mtTFA antibody - conjugated to Alexa Fluor® 647. Suitable for ICC/IF and reacts with Human samples. Cited in 1 publication.

View Alternative Names

TCF6, TCF6L2, TFAM, mtTFA, Mitochondrial transcription factor 1, Transcription factor 6, Transcription factor 6-like 2, MtTF1, TCF-6

2 Images
Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker (AB198106)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker (AB198106)

ab198106 staining mtTFA in MCF7 cells. The cells were fixed with 4% PFA (10min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab198106 at 1/1000 dilution (shown in red) and ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 488), at 2μg/ml (shown in green). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker (AB198106)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker (AB198106)

ab198106 staining mtTFA in WI38 cells. The cells were fixed with 100% methanol (5min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab198106 at 1/100 dilution (shown in red) and ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 488), at 2μg/ml (shown in green). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  • 519 Alexa Fluor® 488

    Alexa Fluor® 488 Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker

  • Unconjugated

    Anti-mtTFA antibody [18G102B2E11] - Mitochondrial Marker

Key facts

Host species

Mouse

Clonality

Monoclonal

Clone number

18G102B2E11

Isotype

IgG2b

Light chain type

kappa

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Human

Applications

ICC/IF

applications

style
left-column

Alternative Products

Primary Antibodies

AB47517

Anti-mtTFA antibody - Mitochondrial Marker

Lab Essentials

Immunocytochemistry/ Immunofluorescence - Anti-mtTFA antibody - Mitochondrial Marker (AB47517)

  • 5
  • 5
Primary Antibodies

AB209022

HRP Anti-mtTFA antibody [EPR12285] - Mitochondrial Marker

RabMAb|Recombinant|Lab Essentials

Western blot - HRP Anti-mtTFA antibody [EPR12285] - Mitochondrial Marker (AB209022)

  • 0
  • 0
Primary Antibodies

AB171951

Anti-mtTFA antibody [EPR12286] - Mitochondrial Marker

RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-mtTFA antibody [EPR12286] - Mitochondrial Marker (AB171951)

  • 5
  • 1
Primary Antibodies

AB176558

Anti-mtTFA antibody [EPR12285] - Mitochondrial Marker

RabMAb|Recombinant|Lab Essentials

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-mtTFA antibody [EPR12285] - Mitochondrial Marker (AB176558)

  • 5
  • 1
Primary Antibodies

AB240958

Anti-mtTFA antibody [EPR12285] - BSA and Azide free

RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-mtTFA antibody [EPR12285] - BSA and Azide free (AB240958)

  • 0
  • 0

Complementary Products

Assay Kits

AB109721

Complex I Enzyme Activity Microplate Assay Kit (Colorimetric)

Functional Studies - Complex I Enzyme Activity Microplate Assay Kit (Colorimetric) (AB109721)

  • 5
  • 4
Primary Antibodies

AB16056

Anti-COX IV antibody - Mitochondrial Loading Control

BOND RX™ Validated|Lab Essentials

Immunocytochemistry/ Immunofluorescence - Anti-COX IV antibody - Mitochondrial Loading Control (AB16056)

  • 5
  • 33
Primary Antibodies

AB196019

Anti-NDUFB10 antibody [EPR16230-47]

RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-NDUFB10 antibody [EPR16230-47] (AB196019)

  • 5
  • 1
Primary Antibodies

AB14715

Anti-SDHA antibody [2E3GC12FB2AE2]

KO Validated

Western blot - Anti-SDHA antibody [2E3GC12FB2AE2] (AB14715)

  • 5
  • 25
Primary Antibodies

AB14734

Anti-VDAC1/Porin + VDAC3 antibody [20B12AF2] - Mitochondrial Loading Control

Recombinant|Lab Essentials|KO Validated

Western blot - Anti-VDAC1/Porin + VDAC3 antibody [20B12AF2] - Mitochondrial Loading Control (AB14734)

  • 5
  • 52
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/200", "ICCIF-species-notes": "<p></p>" } } }
style
left-column

Product details

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.
style
left-column

Properties and storage information

Form
Liquid
Purification technique
Precipitation Ammonium Sulphate
Purification notes
Purity is near homogeneity as judged by SDS-PAGE. ab198106 was produced in vitro using hybridomas grown in serum-free medium, and then concentrated by ammonium sulfate precipitation.
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

MtTFA also known as mitochondrial transcription factor A or TFAM is an important element in mitochondrial DNA regulation. It plays a pivotal role in maintaining mitochondrial genome integrity and ensuring proper mitochondrial function. This protein weighing approximately 25 kDa is expressed within the mitochondria. It binds to the mitochondrial DNA facilitating the transcription and replication processes ensuring the correct functioning of cellular energy metabolism.
Biological function summary

MtTFA is essential for mitochondrial DNA packaging and transcriptional activation. It acts as a binding factor that organizes the mtDNA into a nucleoid-like structure providing protection and stability. MtTFA functions as part of a larger multi-protein complex that includes mitochondrial RNA polymerase ensuring proper transcription of mitochondrial genes. These activities are critical for normal energy production and mitochondrial biogenesis.

Pathways

The mtTFA protein is integral to the oxidative phosphorylation and mitochondrial biogenesis pathways. It orchestrates the expression of genes critical for these pathways alongside related proteins like NRF2 and PGC-1α. MtTFA ensures effective mitochondrial function by modulating the transcription of key mitochondrial-encoded components necessary for electron transport and ATP synthesis thereby sustaining cellular energy balance.

MtTFA dysregulation is associated with mitochondrial diseases and neurodegenerative disorders. Abnormal mtTFA activity disrupts mitochondrial DNA maintenance potentially leading to conditions like mitochondrial myopathy. It is also linked with proteins such as POLG which are involved in mitochondrial DNA replication. Understanding mtTFA's role in these pathologies highlights its importance as a target in therapeutic strategies aimed at restoring mitochondrial function and preventing disease progression.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Binds to the mitochondrial light strand promoter and functions in mitochondrial transcription regulation (PubMed : 29445193, PubMed : 32183942). Component of the mitochondrial transcription initiation complex, composed at least of TFB2M, TFAM and POLRMT that is required for basal transcription of mitochondrial DNA (PubMed : 29149603). In this complex, TFAM recruits POLRMT to a specific promoter whereas TFB2M induces structural changes in POLRMT to enable promoter opening and trapping of the DNA non-template strand (PubMed : 20410300). Required for accurate and efficient promoter recognition by the mitochondrial RNA polymerase (PubMed : 22037172). Promotes transcription initiation from the HSP1 and the light strand promoter by binding immediately upstream of transcriptional start sites (PubMed : 22037172). Is able to unwind DNA (PubMed : 22037172). Bends the mitochondrial light strand promoter DNA into a U-turn shape via its HMG boxes (PubMed : 1737790). Required for maintenance of normal levels of mitochondrial DNA (PubMed : 19304746, PubMed : 22841477). May play a role in organizing and compacting mitochondrial DNA (PubMed : 22037171).
See full target information TFAM
style
left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

Scientific reports 13:5788 PubMed37031254

2023

Possible frequent multiple mitochondrial DNA copies in a single nucleoid in HeLa cells.

Applications

Unspecified application

Species

Unspecified reactive species

Vojtěch Pavluch,Tomáš Špaček,Hana Engstová,Andrea Dlasková,Petr Ježek
