AB225223

Alexa Fluor® 647 Anti-XPD antibody [EPR9675]

Be the first to review this product! Submit a review

|

(1 Publication)

Rabbit Recombinant Monoclonal XPD antibody - conjugated to Alexa Fluor® 647. Suitable for ICC/IF, IHC-P and reacts with Human samples. Cited in 1 publication.

View Alternative Names

XPD, XPDC, ERCC2, General transcription and DNA repair factor IIH helicase subunit XPD, TFIIH subunit XPD, Basic transcription factor 2 80 kDa subunit, CXPD, DNA 5'-3' helicase XPD, DNA excision repair protein ERCC-2, DNA repair protein complementing XP-D cells, TFIIH basal transcription factor complex 80 kDa subunit, Xeroderma pigmentosum group D-complementing protein, BTF2 p80, TFIIH 80 kDa subunit, TFIIH p80

1 Images
Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-XPD antibody [EPR9675] (AB225223)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Alexa Fluor® 647 Anti-XPD antibody [EPR9675] (AB225223)

ab225223 staining XPD in HeLa (Human epithelial cell line from cervix adenocarcinoma) cells.

The cells were fixed with 4% formaldehyde (10 minutes), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1 hour. The cells were then incubated overnight at +4°C with ab225223 at 1/100 dilution (shown in red) and ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor® 488), at 1/250 dilution (shown in green). Nuclear DNA was labeled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR9675

Isotype

IgG

Conjugation

Alexa Fluor® 647

Excitation/Emission

Ex: 650nm, Em: 665nm

Carrier free

No

Reacts with

Human, Human

Applications

ICC/IF, IHC-P

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Alternative Products

Primary Antibodies

AB111596

Anti-XPD antibody

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-XPD antibody (AB111596)

  • 5
  • 1
Primary Antibodies

AB102682

Anti-XPD antibody

Immunocytochemistry/ Immunofluorescence - Anti-XPD antibody (AB102682)

  • 0
  • 0
Primary Antibodies

AB54676

Anti-XPD antibody [4G2-2A6]

Flow Cytometry - Anti-XPD antibody [4G2-2A6] (AB54676)

  • 4
  • 1
Primary Antibodies

AB150362

Anti-XPD antibody [EPR9674]

RabMAb|Recombinant

Western blot - Anti-XPD antibody [EPR9674] (AB150362)

  • 0
  • 0

Complementary Products

Primary Antibodies

AB78316

Anti-p53 (acetyl K120) antibody [10E5]

Lab Essentials

Immunocytochemistry/ Immunofluorescence - Anti-p53 (acetyl K120) antibody [10E5] (AB78316)

  • 4
  • 4
Secondary Antibodies

AB150077

Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488)

Immunocytochemistry/ Immunofluorescence - Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) (AB150077)

  • 5
  • 20
Proteins & Peptides

AB115508

Recombinant Human HSF1 (phospho ) protein

Western blot - Recombinant Human HSF1 (phospho ) protein (AB115508)

  • 0
  • 0
Primary Antibodies

AB109012

Anti-SQSTM1 / p62 antibody [EPR4844] - Autophagosome Marker

KO Validated|RabMAb|Recombinant|Lab Essentials

Western blot - Anti-SQSTM1 / p62 antibody [EPR4844] - Autophagosome Marker (AB109012)

  • 5
  • 15
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100", "ICCIF-species-notes": "<p>This product gave a positive signal in HeLa cells fixed with 4% formaldehyde (10 min)</p>", "IHCP-species-checked": "guaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>" } } }
style
left-column

Product details

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Alexa Fluor® is a registered trademark of Molecular Probes, Inc, a Thermo Fisher Scientific Company. The Alexa Fluor® dye included in this product is provided under an intellectual property license from Life Technologies Corporation. As this product contains the Alexa Fluor® dye, the purchase of this product conveys to the buyer the non-transferable right to use the purchased product and components of the product only in research conducted by the buyer (whether the buyer is an academic or for-profit entity). As this product contains the Alexa Fluor® dye the sale of this product is expressly conditioned on the buyer not using the product or its components, or any materials made using the product or its components, in any activity to generate revenue, which may include, but is not limited to use of the product or its components: in manufacturing; (ii) to provide a service, information, or data in return for payment (iii) for therapeutic, diagnostic or prophylactic purposes; or (iv) for resale, regardless of whether they are sold for use in research. For information on purchasing a license to this product for purposes other than research, contact Life Technologies Corporation, 5781 Van Allen Way, Carlsbad, CA 92008 USA or outlicensing@thermofisher.com.

style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.4 Preservative: 0.02% Sodium azide Constituents: PBS, 30% Glycerol (glycerin, glycerine), 1% BSA
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle|Stable for 12 months at -20°C|Store in the dark
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

XPD also known as ERCC2 is an essential helicase enzyme belonging to the family of ATP-dependent DNA helicases. It consists of approximately 761 amino acids and has a mass of around 87 kDa. XPD functions mechanically by unwinding double-stranded DNA which is important for various DNA repair processes. This protein is expressed ubiquitously in human tissues highlighting its critical role in maintaining genomic integrity.
Biological function summary

XPD catalyzes the unwinding of DNA within the transcription factor IIH (TFIIH) complex. This complex facilitates DNA repair and transcription initiation. XPD participates in the nucleotide excision repair (NER) pathway where it contributes to repairing damaged DNA by excising damaged nucleotides. Its role in transcription-coupled repair and general transcription initiation underlines its importance in cellular homeostasis.

Pathways

DNA repair and general transcription processes are significantly affected by XPD. It plays an integral role in nucleotide excision repair (NER) and transcription. Within these pathways XPD works closely with other proteins such as XPA which assists in damage verification and incision near DNA lesions. XPD's unwinding function is essential for the correct orientation of DNA during transcription and repair events ensuring accurate gene expression and stability.

XPD mutations link to xeroderma pigmentosum (XP) and trichothiodystrophy (TTD). These conditions often result in increased sensitivity to ultraviolet (UV) radiation and various developmental abnormalities. XPD mutations impair the repair of UV-induced DNA damage causing symptoms in both XP and TTD. XPD also connects with ERCC1 a protein important for repair synthesis and DNA incision highlighting its broad impact on human health when its function is compromised.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

ATP-dependent 5'-3' DNA helicase (PubMed : 31253769, PubMed : 8413672, PubMed : 9771713). Component of the general transcription and DNA repair factor IIH (TFIIH) core complex, not absolutely essential for minimal transcription in vitro (PubMed : 10024882, PubMed : 17466626, PubMed : 9771713). Required for transcription-coupled nucleotide excision repair (NER) of damaged DNA; recognizes damaged bases (PubMed : 17466626, PubMed : 23352696, PubMed : 9771713). Sequestered in chromatin on UV-damaged DNA (PubMed : 23352696). When complexed to CDK-activating kinase (CAK), involved in transcription by RNA polymerase II. In NER, TFIIH acts by opening DNA around the lesion to allow the excision of the damaged oligonucleotide and its replacement by a new DNA fragment. The ATP-dependent helicase activity of XPD/ERCC2 is required for DNA opening. Involved in DNA lesion verification (PubMed : 31253769). In transcription, TFIIH has an essential role in transcription initiation. When the pre-initiation complex (PIC) has been established, TFIIH is required for promoter opening and promoter escape. Phosphorylation of the C-terminal tail (CTD) of the largest subunit of RNA polymerase II by the kinase module CAK controls the initiation of transcription. XPD/ERCC2 acts by forming a bridge between CAK and the core-TFIIH complex. The structure of the TFIIH transcription complex differs from the NER-TFIIH complex; large movements by XPD/ERCC2 and XPB/ERCC3 are stabilized by XPA which allow this subunit to contact ssDNA (PubMed : 31253769, PubMed : 33902107). Involved in the regulation of vitamin-D receptor activity. As part of the mitotic spindle-associated MMXD complex it plays a role in chromosome segregation. Might have a role in aging process and could play a causative role in the generation of skin cancers.
See full target information ERCC2
style
left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

Nature immunology 23:1256-1272 PubMed35902638

2022

Partial RAG deficiency in humans induces dysregulated peripheral lymphocyte development and humoral tolerance defect with accumulation of T-bet B cells.

Applications

Unspecified application

Species

Unspecified reactive species

Krisztian Csomos,Boglarka Ujhazi,Peter Blazso,Jose L Herrera,Christopher M Tipton,Tomoki Kawai,Sumai Gordon,Maryssa Ellison,Kevin Wu,Matthew Stowell,Lauren Haynes,Rachel Cruz,Bence Zakota,Johnny Nguyen,Michelle Altrich,Christoph B Geier,Svetlana Sharapova,Joseph F Dasso,Jennifer W Leiding,Grace Smith,Waleed Al-Herz,Mayra de Barros Dorna,Olajumoke Fadugba,Eva Fronkova,Veronika Kanderova,Michael Svaton,Sarah E Henrickson,Joseph D Hernandez,Taco Kuijpers,Snezhina Mihailova Kandilarova,Elizaveta Naumova,Tomas Milota,Anna Sediva,Despina Moshous,Benedicte Neven,Tara Saco,Ravishankar Sargur,Sinisa Savic,John Sleasman,Gauri Sunkersett,Brant R Ward,Masanobu Komatsu,Stefania Pittaluga,Attila Kumanovics,Manish J Butte,Michael P Cancro,Shiv Pillai,Eric Meffre,Luigi D Notarangelo,Jolan E Walter
