Anti-alpha Actinin/ACTN1 antibody [AT6/172] - Cytoskeleton Marker

• ICC

Lab

Immunocytochemistry - Anti-alpha Actinin/ACTN1 antibody [AT6/172] - Cytoskeleton Marker (AB18061)

Immunofluorescence staining of Actinin/ACTN1 using ab18061 in ab277612, which were differentiated for 10 days post induction.

The cells were fixed with 100% MeOH (5 min) and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab18061 at 5 µg/mL and ab6046, rabbit polyclonal to beta Tubulin, at 1/1000 dilution. Cells were then incubated with ab150117, Goat Anti-Mouse IgG H&L (Alexa Fluor^® 488) preadsorbed at 1/1000 dilution (shown in green) and ab150088, Goat Anti-Rabbit IgG H&L (Alexa Fluor^® 594) preadsorbed at 1/1000 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue).

Image was acquired with a high-content analyser (Operetta CLS, Perkin Elmer) and a maximum intensity projection of confocal sections is shown. Gamma is adjusted to 1.5 in all channels.

• ICC

Unknown

Immunocytochemistry - Anti-alpha Actinin/ACTN1 antibody [AT6/172] - Cytoskeleton Marker (AB18061)

ICC/IF image of ab18061 stained HeLa (Human epithelial cell line from cervix adenocarcinoma) cells. The cells were fixed in 4% formaldehyde for 10 minutes and then incubated in 1% BSA / 10% normal goat serum / 0.3 M glycine in 0.1% PBS-Tween for 1 hour to permeabilize the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab18061, 1 μg/ml) overnight at +4°C. The secondary antibody (green) was Alexa Fluor^® 488 goat anti-mouse IgG (H+L) used at a 1/1000 dilution for 1 hour. Alexa Fluor^® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1 hour. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43 μM.
