AB243945

Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free

Be the first to review this product! Submit a review

|

(1 Publication)

Rabbit Recombinant Monoclonal ATP6V1B1 antibody. Carrier free. Suitable for ICC/IF, IHC-P, WB and reacts with Human, Mouse, Rat samples. Cited in 1 publication.

View Alternative Names

ATP6B1, VATB, VPP3, ATP6V1B1, V-ATPase subunit B 1, Endomembrane proton pump 58 kDa subunit, Vacuolar proton pump subunit B 1, ATP6B2, VPP3, ATP6V1B2, V-ATPase subunit B 2, Endomembrane proton pump 58 kDa subunit, HO57, Vacuolar proton pump subunit B 2

6 Images
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)

Immunohistochemical analysis of paraffin-embedded Human cardiac muscle tissue labeling ATP6V1B1 + ATP6V1B2 with ab200839 at 1/5000 dilution, followed by Goat Anti-Rabbit IgG H&L (HRP) (ab97051) secondary antibody at 1/500 dilution. Human cardiac muscle tissue represents a negative control for ATP6V1B1 + ATP6V1B2. Counter stained with Hematoxylin.

Secondary antibody only control : Used PBS instead of primary antibody, secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab200839)

Perform heat mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Immunocytochemistry/ Immunofluorescence - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)

Immunofluorescent analysis of 100% methanol-fixed, 0.1% Triton X-100 permeabilized HEK293 (Human embryonic kidney) cells labeling ATP6V1B1 + ATP6V1B2 with ab200839 at 1/250 dilution, followed by Goat anti-rabbit IgG (Alexa Fluor® 488) (ab150077) secondary antibody at 1/500 dilution (green). Cytoplasmic staining on HEK293 cell line was observed. The nuclear counter stain is DAPI (blue). Tubulin is detected with ab7291 (anti-Tubulin mouse mAb) at 1/1000 dilution and ab150120 (AlexaFluor®594 Goat anti-Mouse secondary) at 1/500 dilution (red).

The negative controls are as follows :
-ve control 1 : ab200839 at 1/250 dilution followed by ab150120 (AlexaFluor®594 Goat anti-Mouse secondary) at 1/500 dilution.
-ve control 2 : ab7291 (anti-Tubulin mouse mAb) at 1/1000 dilution followed by ab150077 (Alexa Fluor®488 Goat Anti-Rabbit IgG H&L) at 1/500 dilution.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab200839)

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)

Immunohistochemical analysis of paraffin-embedded Human kidney tissue labeling ATP6V1B1 + ATP6V1B2 with ab200839 at 1/5000 dilution, followed by Goat Anti-Rabbit IgG H&L (HRP) (ab97051) secondary antibody at 1/500 dilution. Cytoplasmic staining on Human kidney tissue is observed. Counter stained with Hematoxylin.

Secondary antibody only control : Used PBS instead of primary antibody, secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab200839)

Perform heat mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Immunocytochemistry/ Immunofluorescence - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)
  • ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)

Immunofluorescent analysis of 100% methanol-fixed, 0.1% Triton X-100 permeabilized JAR (Human placenta choriocarcinoma cell line) cells labeling ATP6V1B1 + ATP6V1B2 with ab200839 at 1/250 dilution, followed by Goat anti-rabbit IgG (Alexa Fluor® 488) (ab150077) secondary antibody at 1/500 dilution (green). Cytoplasmic staining on JAR cell line was observed. The nuclear counter stain is DAPI (blue). Tubulin is detected with ab7291 (anti-Tubulin mouse mAb) at 1/1000 dilution and ab150120 (AlexaFluor®594 Goat anti-Mouse secondary) at 1/500 dilution (red).

The negative controls are as follows :
-ve control 1 : ab200839 at 1/250 dilution followed by ab150120 (AlexaFluor®594 Goat anti-Mouse secondary) at 1/500 dilution.
-ve control 2 : ab7291 (anti-Tubulin mouse mAb) at 1/1000 dilution followed by ab150077 (Alexa Fluor®488 Goat Anti-Rabbit IgG H&L) at 1/500 dilution.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab200839)

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)

Immunohistochemical analysis of paraffin-embedded Mouse kidney tissue labeling ATP6V1B1 + ATP6V1B2 with ab200839 at 1/5000 dilution, followed by Goat Anti-Rabbit IgG H&L (HRP) (ab97051) secondary antibody at 1/500 dilution. Cytoplasmic staining on mouse kidney tissue is observed. Counter stained with Hematoxylin.

Secondary antibody only control : Used PBS instead of primary antibody, secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab200839)

Perform heat mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)
  • IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B1 + ATP6V1B2 antibody [EPR16401] - BSA and Azide free (AB243945)

Immunohistochemical analysis of paraffin-embedded Rat kidney tissue labeling ATP6V1B1 + ATP6V1B2 with ab200839 at 1/5000 dilution, followed by Goat Anti-Rabbit IgG H&L (HRP) (ab97051) secondary antibody at 1/500 dilution. Cytoplasmic staining on rat kidney tissue is observed. Counter stained with Hematoxylin.

Secondary antibody only control : Used PBS instead of primary antibody, secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab200839)

Perform heat mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EPR16401

Isotype

IgG

Carrier free

Yes

Reacts with

Mouse, Rat, Human

Applications

IHC-P, ICC/IF, WB

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

style
left-column

Complementary Products

Primary Antibodies

AB73404

Anti-ATP6V1B2 antibody

BOND RX™ Validated

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-ATP6V1B2 antibody (AB73404)

  • 5
  • 1
Secondary Antibodies

AB150077

Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488)

Immunocytochemistry/ Immunofluorescence - Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) (AB150077)

  • 5
  • 20
Primary Antibodies

AB20454

Anti-FOXI1 antibody

Western blot - Anti-FOXI1 antibody (AB20454)

  • 5
  • 1
Primary Antibodies

AB199326

Anti-ATP6V1A antibody [EPR19270]

RabMAb|Recombinant|20ul selling size

Immunocytochemistry/ Immunofluorescence - Anti-ATP6V1A antibody [EPR19270] (AB199326)

  • 4
  • 2
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"}, "WB" : {"fullname" : "Western blot", "shortname":"WB"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>", "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>", "WB-species-checked": "testedAndGuaranteed", "WB-species-dilution-info": "", "WB-species-notes": "<p></p>" }, "Mouse": { "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "", "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>", "WB-species-checked": "testedAndGuaranteed", "WB-species-dilution-info": "", "WB-species-notes": "<p></p>" }, "Rat": { "ICCIF-species-checked": "guaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "", "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>", "WB-species-checked": "testedAndGuaranteed", "WB-species-dilution-info": "", "WB-species-notes": "<p></p>" } } }
style
left-column

Product details

ab243945 is the carrier-free version of ab200839.

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Conjugation ready
Our carrier-free antibodies are typically supplied in a PBS-only formulation, purified and free of BSA, sodium azide and glycerol. This conjugation-ready format is designed for use with fluorochromes, metal isotopes, oligonucleotides, and enzymes, which makes them ideal for antibody labelling, functional and cell-based assays, flow-based assays (e.g. mass cytometry) and Multiplex Imaging applications.

Use our conjugation kits for antibody conjugates that are ready-to-use in as little as 20 minutes with 1 minute hands-on-time and 100% antibody recovery: available for fluorescent dyes, HRP, biotin and gold.

Compatibility
This product is compatible with the Maxpar® Antibody Labeling Kit from Fluidigm, without the need for antibody preparation. Maxpar® is a trademark of Fluidigm Canada Inc.

style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.2 - 7.4 Constituents: PBS
Shipped at conditions
Blue Ice
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
+4°C
Storage information
Do Not Freeze
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

ATP6V1B1 and ATP6V1B2 are subunits of the V-type proton ATPase (vacuolar ATPase V-ATPase) important for proton translocation across intracellular membranes. Known also as ATP synthase subunits B1 and B2 these proteins together with other subunits form part of the cytoplasmic V1 domain of the enzyme. ATP6V1B1 has a molecular mass of approximately 56 kDa while ATP6V1B2 is slightly larger at around 57 kDa. Both subunits are widely expressed in various tissues but are specifically abundant in the kidney and inner ear.
Biological function summary

ATP6V1B1 and ATP6V1B2 participate in acidification of intracellular environments a fundamental process for cellular homeostasis and function. They are integral components of the V-ATPase complex which actively transports protons into lysosomes endosomes and other vesicles generating acidic conditions essential for protein degradation vesicular trafficking and hormone activation. This acidification is also important for maintaining the optimal pH necessary for various enzymatic activities within organelles.

Pathways

These subunits play an important role in the regulation of the mTOR signaling pathway and endocytosis pathway both critical for cell growth proliferation and nutrient sensing. The activity of V-ATPase influences these pathways by affecting pH-dependent processes required for receptor-mediated endocytosis and nutrient availability. ATP6V1B1 and ATP6V1B2 interact with other V-ATPase subunits such as ATP6V1A and ATP6V1C to modulate their function in these pathways.

Mutations and dysfunctions in ATP6V1B1 and ATP6V1B2 are linked to distal renal tubular acidosis (dRTA) and sensorineural hearing loss. These conditions result from altered proton transport and subsequent disruptions in acid-base balance. The relationship with dRTA involves the defective acidification of urine a process dependent on V-ATPase activity. Additionally altered function of these subunits has implications for their interaction with other proton pumps and transport proteins such as the carbonic anhydrase II which work together in maintaining pH equilibrium in the kidney and inner ear.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Non-catalytic subunit of the V1 complex of vacuolar(H+)-ATPase (V-ATPase), a multisubunit enzyme composed of a peripheral complex (V1) that hydrolyzes ATP and a membrane integral complex (V0) that translocates protons (PubMed : 16769747). V-ATPase is responsible for acidifying and maintaining the pH of intracellular compartments and in some cell types, is targeted to the plasma membrane, where it is responsible for acidifying the extracellular environment (PubMed : 32001091). Essential for the proper assembly and activity of V-ATPase (PubMed : 16769747). In renal intercalated cells, mediates secretion of protons (H+) into the urine thereby ensuring correct urinary acidification (PubMed : 16769747). Required for optimal olfactory function by mediating the acidification of the nasal olfactory epithelium (By similarity).
See full target information ATP6V1B1

Additional targets

ATP6V1B2
style
left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

Journal of hematology & oncology 12:106 PubMed31640756

2019

MAGE-A1 in lung adenocarcinoma as a promising target of chimeric antigen receptor T cells.

Applications

Unspecified application

Species

Unspecified reactive species

Yuan Mao,Weifei Fan,Hao Hu,Louqian Zhang,Jerod Michel,Yaqin Wu,Jun Wang,Lizhou Jia,Xiaojun Tang,Li Xu,Yan Chen,Jin Zhu,Zhenqing Feng,Lin Xu,Rong Yin,Qi Tang
