Anti-beta Actin antibody [EPR21242] - Loading Control

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-beta Actin antibody [EPR21242] - Loading Control (AB241153)

ab213243 staining beta-Actin in HeLa cells. The cells were fixed with 100% methanol (5 min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab241153 at 0.01ugml then detected with an Alexa Fluor^® 488 goat anti-rabbit secondary antibody (ab150081) at a 1/1000 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue), and ab195889, Mouse monoclonal to alpha Tubulin (Alexa Fluor^® 594), at a 1/250 dilution (shown in red).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-beta Actin antibody [EPR21242] - Loading Control (AB241153)

ab213243 staining beta-Actin in NIH3T3 cells. The cells were fixed with 100% methanol (5 min), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at +4°C with ab241153 at 0.5ugml then detected with an Alexa Fluor^® 488 goat anti-rabbit secondary antibody (ab150081) at a 1/1000 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue), and ab195889, Mouse monoclonal to alpha Tubulin (Alexa Fluor^® 594), at a 1/250 dilution (shown in red).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

• WB

Lab

Western blot - Anti-beta Actin antibody [EPR21242] - Loading Control (AB241153)

ab241153 was shown to react with ACTNB (beta actin) when tested against HAP1 wild-type and HAP1 ACTNB (beta actin) knockout cells. ACTNB wild-type and knockout samples were subjected to SDS-PAGE and incubated with ab231153. Incomplete reduction of signal was seen in the ACTNB (beta actin) knockout samples at beta actin's expected molecular weight. SDS-PAGE of gamma actin recombinant protein and incubation with ab241153 showed cross-reactivity to gamma actin.

ab241153 and ab8245 (Mouse anti-GAPDH loading control) were incubated overnight at 4°C at a 1ug/ml and 1/10000 dilution respectively. Blots were developed with Goat anti-Rabbit IgG H&L (IRDye® 800CW) preadsorbed (ab216773) and Goat anti-Mouse IgG H&L (IRDye® 680RD) preadsorbed (ab216776) secondary antibodies at 1/20000 dilution for 1 hour at room temperature before imaging.

All lanes:

Western blot - Anti-beta Actin antibody [EPR21242] - Loading Control (ab241153) at 1 µg/mL

Lane 1:

HAP1 whole cell lysate at 20 µg

Lane 2:

HAP1 ACTNB whole cell lysate at 20 µg

Lane 3:

NIH3T3 whole cell lysate at 20 µg

Lane 4:

MEF whole cell lysate at 20 µg

Lane 5:

Western blot - Recombinant Human gamma Actin protein (GST tag N-Terminus) (<a href='/en-us/products/proteins-peptides/recombinant-human-gamma-actin-protein-ab157841'>ab157841</a>)

Predicted band size: 41 kDa
