Anti-BLBP antibody

8 product images

•

  Immunocytochemistry/ Immunofluorescence - Anti-BLBP antibody (ab32423)

  ab32423 staining BLBP in primary hippocampal rat neurons/glia, (obtained from Neuromics, cat. no. PC35101), DIV14. cells. The cells were fixed with 4% paraformaldehyde (10 min), permeabilized with 0.1% PBS-Tween for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at 4°C with ab32423 at 5µg/ml and Anti-alpha Tubulin antibody [DM1A] - Loading Control ab7291, Mouse monoclonal [DM1A] to alpha Tubulin - Loading Control. Cells were then incubated with Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081, Goat polyclonal Secondary Antibody to Rabbit IgG - H&L (Alexa Fluor^® 488), pre-adsorbed at 1/1000 dilution (shown in green) and Goat Anti-Rabbit IgG H&L (Alexa Fluor® 594) ab150080, Goat polyclonal Secondary Antibody to Rabbit IgG - H&L (Alexa Fluor^® 594) at 1/1000 dilution (shown in pseudocolour red). Nuclear DNA was labelled with DAPI (shown in blue).

  Image was acquired with a high-content analyser (Operetta CLS, Perkin Elmer) and a maximum intensity projection of confocal sections is shown.

•

  This image is courtesy of Carl Hobbs, King's College London, United Kingdom

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-BLBP antibody (ab32423)

  BLBP detected on rat embryo day 16 spinal cord T/S on 5 micron thick formalin-fixed paraffin wax embedded sections using Rabbit polyclonal to BLBP (ab32423; incubated at 1/200 for 16h at RT). 1% BSA (10 mins at RT) used as blocking agent. Secondary Antibody was biotin labeled anti-rabbit IgG (1/300). Immunoreactivity was visualised by standard streptAvidin-biotin-complex using peroxidase as a reporter and DAB as chromogen following citric acid (pH 6) heat mediated antigen retrieval. Expected specific staining observed with ab32423 with low signal to noise ratio.

•

  Western blot - Anti-BLBP antibody (ab32423)

  All lanes: Western blot - Anti-BLBP antibody (ab32423) at 1/250 dilution

  All lanes: Western blot - Mouse brain tissue lysate - total protein (0 days) (Mouse brain tissue lysate - total protein (0 days) ab7188) at 10 µg

  Secondary

  All lanes: IRDye 680 Conjugated Goat Anti-Rabbit IgG (H+L) at 1/10000 dilution

  Performed under reducing conditions.

  Predicted band size: 14 kDa

  Observed band size: 15 kDa

•

  This image is courtesy of Carl Hobbs, King's College London, United Kingdom

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-BLBP antibody (ab32423)

  BLBP detected on mouse embryo day 16 spinal cord T/S on 5 micron thick formalin-fixed paraffin wax embedded sections using Rabbit polyclonal to BLBP (ab32423; incubated at 1/300 for 16h at RT). 1% BSA (10 mins at RT) used as blocking agent. Secondary Antibody was biotin labeled anti-rabbit IgG (1/300). Immunoreactivity was visualised by standard streptAvidin-biotin-complex using peroxidase as a reporter and DAB as chromogen following citric acid (pH 6) heat mediated antigen retrieval. Expected specific staining observed with ab32423.

•

  This image is courtesy of Carl Hobbs, King's College London, United Kingdom

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-BLBP antibody (ab32423)

  Immunohistochemistical staining (Formaldehyde/PFA-fixed paraffin-embedded sections) for BLBP antibody (ab32423) on Zebrafish Tissue sections (young adult whole body T/S). Antigen retrieval step: Heat mediated Blocking step: 1% BSA for 10 mins at RT.


  Primary Antibody: ab32423 incubated at 1/500 for 2 hours at RT.
  Secondary Antibody: Biotin labelled goat anti rabbit IgG (1/300).

•

  This image is courtesy of Carl Hobbs, King's College London, United Kingdom

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-BLBP antibody (ab32423)

  Immunohistochemistical detection (on Formaldehyde /PFA-fixed paraffin-embedded sections) of BLBP protein using BLBP antibody (ab32423) on Quail Tissue sections (developing spinal cord). Antigen retrieval step: Heat mediated. Blocking step: 1% BSA for 10 mins at RT.


  Primary Antibody: ab32423 incubated at 1/500 for 2 hours at RT.
  Secondary Antibody: Biotin labelled goat anti rabbit IgG (1/300).

•

  Immunohistochemistry paraffin embedded sections - Anti-BLBP antibody (ab32423)

  Immunohistochemistry image of BLBP staining in a section of formalin-fixed paraffin-embedded normal e15 rat foetus performed on a Leica Biosystems BOND^® RX instrument using the standard protocol. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20mins. The section was then incubated with ab32423, 0.5 µg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX. The inset secondary-only control image is taken from an identical assay without primary antibody.

  For other Immunohistochemitry staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-BLBP antibody (ab32423)

  IHC image of BLBP staining in a section of formalin-fixed paraffin-embedded normal e16 foetal rat brain performed on a Leica Biosystems BOND^® RX instrument. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20mins. The section was then incubated with ab32423, 0.1ug/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX. The inset secondary-only control image is taken from an identical assay without primary antibody.
  For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.
