Anti-CCL4/MIP-1 beta + CCL4L1 antibody [EPR494] - BSA and Azide free

• ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Anti-CCL4/MIP-1 beta + CCL4L1 antibody [EPR494] - BSA and Azide free (AB232158)

Immunocytochemistry/Immunofluorescence analysis of THP-1 (Human monocytic leukemia cell line) labeling CCL4/MIP-1 beta + CCL4L with ab40857 at 1/100. Cells were fixed with 4% paraformaldehyde and permeabilized with 0.1% Triton X-100. ab150077, Alexa Fluor^® 488-conjugated goat anti-rabbit IgG (1/1000) was used as the secondary antibody. Cells were counter-stained with ab195889, Anti-alpha Tubulin antibody [DM1A] - Microtubule Marker (Alexa Fluor^® 594) at 1/200. Nuclei were counterstained with DAPI (blue).

The expression increased after treatment with Lipopolysaccharides (LPS), 100 ng/mL for 4 hours, followed by addition of Brefeldin A (1 μg/mL) for 3 hours.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab40857).

• IP

Unknown

Immunoprecipitation - Anti-CCL4/MIP-1 beta + CCL4L1 antibody [EPR494] - BSA and Azide free (AB232158)

ab40857 at 1/50 immunoprecipitating CCL4/MIP-1 beta + CCL4L in THP-1 (Human monocytic leukemia cell line) whole cell lysate observed at 12 KDa (lanes 1 and 2).

Lane 1 (input) : THP-1 treated with 100 nM PMA overnight, then treated with 100 ng/mL LPS for 7 hours and 1 μg/mL Brefeldin A was added for the last 3 hours whole cell lysate, 10μg

Lane 2 (+) : ab40857 + THP-1 treated with 100 nM PMA overnight, then treated with 100 ng/mL LPS for 7 hours and 1μg/mL Brefeldin A was added for the last 3 hours whole cell lysate

Lane 3 (-) : Rabbit monoclonal IgG (ab172730) instead of ab40857 in THP-1 treated with 100 nM PMA overnight, then treated with 100 ng/mL LPS for 7 hours and 1 μg/mL Brefeldin A was added for the last 3 hours whole cell lysate

For western blotting : ab40857 at 1/1000 followed by VeriBlot for IP Detection Reagent (HRP) (ab131366), was used for detection at 1/1000 dilution.

Blocking buffer and concentration : 5% NFDM/TBST.
Diluting buffer and concentration : 5% NFDM /TBST.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab40857).

All lanes:

Immunoprecipitation - Anti-CCL4/MIP-1 beta + CCL4L1 antibody [EPR494] (<a href='/en-us/products/primary-antibodies/ccl4-mip-1-beta-ccl4l1-antibody-epr494-ab40857'>ab40857</a>)

false

Exposure time: 10s
