Mouse Monoclonal CD31 antibody. Suitable for ICC, Flow Cyt, WB, IHC-P and reacts with Human samples. Cited in 14 publications. Immunogen corresponding to Recombinant Full Length Protein corresponding to Human CD31.


Images

Flow Cytometry - Anti-CD31 antibody [C31.3] (AB187377), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD31 antibody [C31.3] (AB187377), expandable thumbnail
  • Western blot - Anti-CD31 antibody [C31.3] (AB187377), expandable thumbnail
  • Immunocytochemistry - Anti-CD31 antibody [C31.3] (AB187377), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD31 antibody [C31.3] (AB187377), expandable thumbnail

Publications

Key facts

Isotype

IgG1

Host species

Mouse

Storage buffer

pH: 7.2 - 7.4
Preservative: 0.05% Sodium azide
Constituents: 99% PBS, 0.05% BSA

Form

Liquid

Clonality

Monoclonal

Immunogen

  • Recombinant Full Length Protein corresponding to Human CD31. Database link P16284

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
ICCFlow CytWBIHC-P
Human
Tested
Tested
Tested
Tested

Tested
Tested

Species

Human

Dilution info

1.00000-2.00000 µg/mL

Notes

Use 0.3M glycine to quench autofluorescence caused by aldehydes.

Positive Control: HUVEC cells

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Tested
Tested

Species

Human

Dilution info

1.00000-2.00000 µg for 106 Cells

Notes

ab170190 - Mouse monoclonal IgG1, is suitable for use as an isotype control with this antibody.

Tested
Tested

Species

Human

Dilution info

1.00000-2.00000 µg/mL

Notes

Treat samples with PNGase F or phosphatase to confirm the specificity of bands if necessary.

The observed band size of CD31 may not the same as predicted MWs in WB due to the different forms and modifications of CD31.

Hu Isoform 1-6: 79-83 kDa (predicted)

Observed band size is around 130 kDa

Positive Control: HUVEC and Jurkat cell lysates (ab7899); Human spleen and kidney tissue lysate.

Negative Control: NIH/3T3 whole cell lysate (ab7179).

Tested
Tested

Species

Human

Dilution info

1.00000-2.00000 µg/mL

Notes

The ideal fixation time will depend on the size of the tissue block and the type of tissue, but fixation between 18–24h is suitable for most samples.

Positive Control: Hu tonsil tissue

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Associated Products

Select an associated product type

2 products for Alternative Version

8 products for Alternative Product

Target data

Function

Cell adhesion molecule which is required for leukocyte transendothelial migration (TEM) under most inflammatory conditions (PubMed:19342684, PubMed:17580308). Tyr-690 plays a critical role in TEM and is required for efficient trafficking of PECAM1 to and from the lateral border recycling compartment (LBRC) and is also essential for the LBRC membrane to be targeted around migrating leukocytes (PubMed:19342684). Trans-homophilic interaction may play a role in endothelial cell-cell adhesion via cell junctions (PubMed:27958302). Heterophilic interaction with CD177 plays a role in transendothelial migration of neutrophils (PubMed:17580308). Homophilic ligation of PECAM1 prevents macrophage-mediated phagocytosis of neighboring viable leukocytes by transmitting a detachment signal (PubMed:12110892). Promotes macrophage-mediated phagocytosis of apoptotic leukocytes by tethering them to the phagocytic cells; PECAM1-mediated detachment signal appears to be disabled in apoptotic leukocytes (PubMed:12110892). Modulates bradykinin receptor BDKRB2 activation (PubMed:18672896). Regulates bradykinin- and hyperosmotic shock-induced ERK1/2 activation in endothelial cells (PubMed:18672896). Induces susceptibility to atherosclerosis (By similarity).Isoform Delta15Does not protect against apoptosis.

Alternative names

Platelet endothelial cell adhesion molecule, PECAM-1, EndoCAM, GPIIA', PECA1, PECAM1

Recommended products

Mouse Monoclonal CD31 antibody. Suitable for ICC, Flow Cyt, WB, IHC-P and reacts with Human samples. Cited in 14 publications. Immunogen corresponding to Recombinant Full Length Protein corresponding to Human CD31.

Key facts

Isotype

IgG1

Form

Liquid

Clonality

Monoclonal

Immunogen
  • Recombinant Full Length Protein corresponding to Human CD31. Database link P16284
Clone number

C31.3

Purification technique

Affinity purification Protein G

Light chain type

kappa

Concentration
Loading...

Storage

Shipped at conditions

Blue Ice

Appropriate short-term storage duration

1-2 weeks

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

-20°C

Aliquoting information

Upon delivery aliquot

Storage information

Avoid freeze / thaw cycle

Notes

Abcam is leading the way to address reproducibility in scientific research with our highly validated recombinant monoclonal and recombinant multiclonal antibodies. Search & select one of Abcam's thousands of recombinant alternatives to eliminate batch-variability and unnecessary animal use.

If you do not find a host species to meet your needs, our catalogue and custom Chimeric range provides scientists the specificity of Abcam's RabMAbs in the species backbone of your choice. Remember to also review our range of edited cell lines, proteins and biochemicals relevant to your target that may help you further your research goals.

Abcam antibodies are extensively validated in a wide range of species and applications, so please check the reagent specifications meet your scientific needs before purchasing. If you have any questions or bespoke requirements, simply visit the Contact Us page to send us an inquiry or contact our Support Team ahead of purchase.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

5 product images

  • Flow Cytometry - Anti-CD31 antibody [C31.3] (ab187377), expandable thumbnail

    Flow Cytometry - Anti-CD31 antibody [C31.3] (ab187377)

    Flow Cytometry analysis of Jurkat cells labeling CD31 with ab187377 (Green).

    Black: Cells alone;

    Grey: Isotype Control.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD31 antibody [C31.3] (ab187377), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD31 antibody [C31.3] (ab187377)

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of human tonsil tissue labelling CD31 with ab187377.

  • Western blot - Anti-CD31 antibody [C31.3] (ab187377), expandable thumbnail

    Western blot - Anti-CD31 antibody [C31.3] (ab187377)

    All lanes: Western blot - Anti-CD31 antibody [C31.3] (ab187377) at 1 µg/mL

    All lanes: Jurkat (Human T cell leukemia cell line from peripheral blood) whole cell lysate

    Predicted band size: 82 kDa

  • Immunocytochemistry - Anti-CD31 antibody [C31.3] (ab187377), expandable thumbnail

    Immunocytochemistry - Anti-CD31 antibody [C31.3] (ab187377)

    Immunocytochemistry analysis of PFA-fixed Jurkat cells labeling CD31 with ab187377 followed by Goat anti-Mouse IgG-CF488 (Green). The nuclear counterstain is Nucspot (Red).

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD31 antibody [C31.3] (ab187377), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD31 antibody [C31.3] (ab187377)

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of human angiosarcoma tissue labelling CD31 with ab187377.

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
