Anti-CD63 antibody [EPR5702] - Late Endosome Marker is a rabbit recombinant monoclonal antibody that is used to detect CD63 in IHC-P, Western blot. Suitable for Human samples.

- Using biophysical QC, antibody identity is confirmed at a molecular level for unrivaled batch-batch consistency
- Specificity confirmed with CD63 knockout cell line validation
- Specificity and sensitivity confirmed in IHC with multi-tissue microarray (TMA) validation
- Antibody clone EPR5702 is cited in >540 publications


Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (AB134045), expandable thumbnail
  • Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (AB134045), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (AB134045), expandable thumbnail
  • Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (AB134045), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (AB134045), expandable thumbnail

Publications

Key facts

Isotype
IgG
Host species
Rabbit
Storage buffer

pH: 7.2 - 7.4
Preservative: 0.01% Sodium azide
Constituents: 59% PBS, 40% Glycerol (glycerin, glycerine), 0.05% BSA

Form
Liquid
Clonality
Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Abcam Recommends

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-PWB
Human
Tested
Tested

Tested
Tested

Species
Human
Dilution info
1/2000
Notes

For unpurified use at 1/250 - 1/500.

Perform heat-mediated antigen retrieval before commencing with IHC staining protocol.

Tested
Tested

Species
Human
Dilution info
1/1000 - 1/10000
Notes

-

Associated Products

Select an associated product type

15 products for Alternative Product

Target data

Function

Functions as a cell surface receptor for TIMP1 and plays a role in the activation of cellular signaling cascades. Plays a role in the activation of ITGB1 and integrin signaling, leading to the activation of AKT, FAK/PTK2 and MAP kinases. Promotes cell survival, reorganization of the actin cytoskeleton, cell adhesion, spreading and migration, via its role in the activation of AKT and FAK/PTK2. Plays a role in VEGFA signaling via its role in regulating the internalization of KDR/VEGFR2. Plays a role in intracellular vesicular transport processes, and is required for normal trafficking of the PMEL luminal domain that is essential for the development and maturation of melanocytes. Plays a role in the adhesion of leukocytes onto endothelial cells via its role in the regulation of SELP trafficking. May play a role in mast cell degranulation in response to Ms4a2/FceRI stimulation, but not in mast cell degranulation in response to other stimuli.

Alternative names

CD63, MLA1, TSPAN30, CD63 antigen, Granulophysin, Lysosomal-associated membrane protein 3, Lysosome integral membrane protein 1, Melanoma-associated antigen ME491, OMA81H, Ocular melanoma-associated antigen, Tetraspanin-30, LAMP-3, Limp1, Tspan-30

Recommended products

Anti-CD63 antibody [EPR5702] - Late Endosome Marker is a rabbit recombinant monoclonal antibody that is used to detect CD63 in IHC-P, Western blot. Suitable for Human samples.

- Using biophysical QC, antibody identity is confirmed at a molecular level for unrivaled batch-batch consistency
- Specificity confirmed with CD63 knockout cell line validation
- Specificity and sensitivity confirmed in IHC with multi-tissue microarray (TMA) validation
- Antibody clone EPR5702 is cited in >540 publications

Key facts

Isotype
IgG
Form
Liquid
Clonality
Monoclonal
Immunogen
  • The exact immunogen used to generate this antibody is proprietary information.
Clone number
EPR5702
Purification technique
Affinity purification Protein A
Concentration
Loading...

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Stable for 12 months at -20°C

Notes

Product Specifications

Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) was developed by Abcam using patented rabbit monoclonal antibody technology and is validated for use in IHC-P, WB in human samples.
Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) specifically detects CD63 (UniProt ID: P08962; Molecular weight: 26kDa) and is sold in 100 µL and 1 mL selling sizes.

Quality and Validation

Abcam's high quality manufacturing and validation processes ensure Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) has high sensitivity and specificity alongside high lot-to-lot consistency and reproducibility.
The specificity of Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) has been confirmed by testing in knockout samples.
Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) has been cited over 379 times in peer reviewed journals and is trusted by the scientific community.
Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) has 5 independent reviews from customers.
Related Products
Conjugation-ready, carrier free format available for antibody clone EPR5702 - Anti-CD63 antibody [EPR5702] - BSA and Azide free ab215821.
Antibody clone EPR5702 is also available pre-conjugated to a variety of labels for your convenience - Alexa Fluor® 647 (Alexa Fluor® 647 Anti-CD63 - Late Endosome Marker antibody [EPR5702] ab309976, Biotin Anti-CD63 antibody [EPR5702] - Late Endosome Marker ab316180).
Target Information
CD63, also known as LAMP3 or Granulophysin, is a member of the tetraspanin family and is widely expressed on the surface of various cells, including macrophages and lymphocytes. It plays a crucial role in the formation and release of exosomes. CD63 (Granulophysin) is highly expressed in various tumor cells and also impacts the tumor microenvironment (TME) by regulating cell communication. Additionally, CD63 facilitates the degradation of the extracellular matrix, aiding in tumor cell invasion and metastasis.

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Species reactivity
Rat: We have preliminary internal testing data to indicate this antibody may not react with this species.
Please contact us for more information.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.
Activity summary

CD63 is a protein commonly known as LAMP-3 a member of the tetraspanin family with a molecular weight of approximately 25-65 kDa depending on post-translational modifications such as glycosylation. It resides mainly on the membrane of intracellular vesicles such as lysosomes and platelets. CD63 also appears on the surface of activated cells particularly in immune cells. Researchers often use CD63 as a marker in assays including CD63 western blot techniques due to its distinct expression patterns.

Biological function summary

CD63 participates in various cellular processes including membrane trafficking cell adhesion and signal transduction. It associates with integrins and other tetraspanins forming complexes that influence cellular adhesion and migration. Through its role in exosome formation CD63 contributes significantly to intercellular communication by facilitating the transfer of proteins lipids and RNA between cells.

Pathways

CD63 plays a role in pathways linked to cell proliferation and migration and immune response regulation. Within the integrin-mediated signaling pathway CD63 interacts with proteins such as integrins to promote cell adhesion and migration. CD63 also links to vesicle trafficking pathways collaborating with proteins involved in exocytosis and endocytosis which affect cell membrane restructuring and intracellular transport.

Associated diseases and disorders

CD63 shows connections with cancer and immune system disorders. Its role in promoting cell adhesion and migration links it with cancer metastasis including melanoma and breast cancer where CD63 expression levels often rise. Additionally CD63 associates with allergic reactions due to its involvement in histamine release where it impacts immune proteins like FcεRI which participate in allergy pathogenesis.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

8 product images

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of human melanoma tissue labelling CD63 with unpurified ab134045 at a dilution of 1/250.

    Perform heat mediated antigen retrieval before commencing with IHC staining protocol.

  • Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Lanes 1 - 6: Merged signal (red and green). Green - ab134045 observed at 26 kDa. Red - loading control, Anti-GAPDH antibody [mAbcam 9484] - Loading Control ab9484, observed at 37 kDa.

    ab134045 was shown to specifically react with CD63 in wild-type HAP1 Brefeldin A treated cells as signal was lost in HAP1 Brefeldin A treated CD63 knockout cells. Wild-type and CD63 knockout samples were subjected to SDS-PAGE. ab134045 and Anti-GAPDH antibody [mAbcam 9484] - Loading Control ab9484 (Mouse anti-GAPDH loading control) were incubated overnight at 4°C at 1/1000 dilution and 1/20000 dilution respectively. Blots were developed with Goat anti-Rabbit IgG H&L (IRDye® 800CW) preabsorbed Goat anti-Rabbit IgG H&L (IRDye® 800CW) preadsorbed ab216773 and Goat anti-Mouse IgG H&L (IRDye® 680RD) preabsorbed Goat anti-Mouse IgG H&L (IRDye® 680RD) preadsorbed ab216776 secondary antibodies at 1/20000 dilution for 1 hour at room temperature before imaging.

    All lanes: Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) at 1/1000 dilution

    Lane 1: Wild-type HAP1 whole cell lysate at 20 µg

    Lane 2: Brefeldin A treated wild-type HAP1 whole cell lysate at 20 µg

    Lane 3: CD63 knockout HAP1 whole cell lysate at 20 µg

    Lane 4: Brefeldin A treated CD63 knockout HAP1 whole cell lysate at 20 µg

    Lane 5: HL60 whole cell lysate at 20 µg

    Lane 6: Human platelets whole cell lysate at 20 µg

    Predicted band size: 26 kDa

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of human tonsil tissue labelling CD63 with purified ab134045 at 1/2000. Heat mediated antigen retrieval was performed using Tris/EDTA buffer pH 9. Goat Anti-Rabbit IgG H&L (HRP) ab97051, a HRP-conjugated goat anti-rabbit IgG (H+L) was used as the secondary antibody (1/500). Negative control using PBS instead of primary antibody. Counterstained with hematoxylin.

  • Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Blocking and dilution buffer: 5% NFDM/TBST.

    All lanes: Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) at 1/5000 dilution

    Lane 1: A375 whole cell lysate at 20 µg

    Lane 2: HL-60 whole cell lysate at 20 µg

    Lane 3: Human melanoma tissue lysate at 20 µg

    Secondary

    All lanes: HRP-conjugated anti-rabbit IgG, specific to the non-reduced form of IgG at 1/1000 dilution

    Predicted band size: 26 kDa

    Observed band size: 30-65 kDa

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of human skeletal muscle tissue (negative control) labelling CD63 with purified ab134045 at 1/2000. Heat mediated antigen retrieval was performed using Tris/EDTA buffer pH 9. Goat Anti-Rabbit IgG H&L (HRP) ab97051, a HRP-conjugated goat anti-rabbit IgG (H+L) was used as the secondary antibody (1/500). Negative control using PBS instead of primary antibody. Counterstained with hematoxylin.

  • Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    All lanes: Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) at 1/1000 dilution

    Lane 1: Human platelet lysate at 10 µg

    Lane 2: Human melanoma lysate at 10 µg

    Lane 3: HL-60 lysate at 10 µg

    Lane 4: A375 lysate at 10 µg

    Secondary

    All lanes: HRP-conjugated goat anti-rabbit IgG at 1/2000 dilution

    Predicted band size: 26 kDa

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Immunohistochemical analysis of formalin fixed paraffin embedded human tonsil staining CD63 with ab134045 at a concentration of 0.1 µg/ml. The immunostaining was performed on a Ventana DISCOVERY ULTRA (Roche Tissue Diagnostics) instrument with a OptiView DAB IHC Detection Kit. Heat mediated antigen retrieval was performed with DISCOVERY cell conditioning solution (CC1) 100°C, pH8.5 for 32mins.

    ab134045 anti-CD63 [EPR5702] was incubated for 16mins at 37°C. Sections were counterstained with Hematoxylin II. Image inset shows absence of staining in secondary antibody only control.

    Customers are encouraged to optimise antigen retrieval conditions, antibody concentration, incubation times and temperature for best results in their own IHC assay workflow (automated and manual)

  • Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045), expandable thumbnail

    Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045)

    Anti-CD63 antibody [EPR5702] (ab134045) staining at 1/1000 dilution, shown in green; Mouse anti-Alpha Tubulin [DM1A] (Anti-alpha Tubulin antibody [DM1A] - Loading Control ab7291) loading control staining at 1/20000 dilution, shown in red. In Western blot, ab134045 was shown to bind specifically to CD63. A band was observed at 30 kDa in wild-type HepG2 cell lysates with no signal observed at this size in CD63 knockout cell line Human CD63 knockout Hep G2 cell line ab280796 (knockout cell lysate ab283828). To generate this image, wild-type and CD63 knockout HepG2 cell lysates were analysed. First, samples were run on an SDS-PAGE gel then transferred onto a nitrocellulose membrane. Membranes were blocked in 3 % milk in TBS-0.1 % Tween® 20 (TBS-T) before incubation with primary antibodies overnight at 4 °C. Blots were washed four times in TBS-T, incubated with secondary antibodies for 1 h at room temperature, washed again four times then imaged. Secondary antibodies used were Goat anti-Rabbit IgG H&L 800CW and Goat anti-Mouse IgG H&L 680RD at 1/20000 dilution.

    All lanes: Western blot - Anti-CD63 antibody [EPR5702] - Late Endosome Marker (ab134045) at 1/1000 dilution

    Lanes 1 - 4: Western blot at 20 µg

    Lanes 3 - 4: Western blot - Human CD63 knockout Hep G2 cell lysate (ab283828)

    Lanes 3 - 4: Western blot - Human CD63 knockout Hep G2 cell line (Human CD63 knockout Hep G2 cell line ab280796)

    Secondary

    All lanes: Goat anti-Rabbit IgG H&L 800CW and Goat anti-Mouse IgG H&L 680RD at 1/20000 dilution

    Performed under reducing conditions.

    Predicted band size: 26 kDa

    Observed band size: 30 kDa

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
