Rabbit Polyclonal CD94 antibody. Suitable for IHC-P and reacts with Human samples. Immunogen corresponding to Synthetic Peptide within Mouse Klrd1 aa 1-100 conjugated to Keyhole Limpet Haemocyanin.


Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody (AB217362), expandable thumbnail

Key facts

Isotype
IgG
Host species
Rabbit
Storage buffer

pH: 7.4
Preservative: 0.02% Proclin 300
Constituents: 50% Glycerol (glycerin, glycerine), 48.98% TBS, 1X, 1% BSA

Form
Liquid
Clonality
Polyclonal

Immunogen

  • Synthetic Peptide within Mouse Klrd1 aa 1-100 conjugated to Keyhole Limpet Haemocyanin. The exact immunogen used to generate this antibody is proprietary information. Database link O54707

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-P
Human
Tested
Mouse
Predicted
Rat
Predicted

Tested
Tested

Species
Human
Dilution info
1/100.00000 - 1/500.00000
Notes

Perform heat-mediated antigen retrieval with citrate buffer pH 6 before commencing with IHC staining protocol.

Predicted
Predicted

Species
Mouse, Rat
Dilution info
-
Notes

-

Associated Products

Select an associated product type

2 products for Alternative Product

Target data

Function

Immune receptor involved in self-nonself discrimination. In complex with KLRC1 or KLRC2 on cytotoxic and regulatory lymphocyte subsets, recognizes non-classical major histocompatibility (MHC) class Ib molecule HLA-E loaded with self-peptides derived from the signal sequence of classical MHC class Ia and non-classical MHC class Ib molecules (PubMed:10023772, PubMed:18064301, PubMed:18083576, PubMed:37264229, PubMed:9486650, PubMed:9754572). Enables cytotoxic cells to monitor the expression of MHC class I molecules in healthy cells and to tolerate self (PubMed:12387742, PubMed:18064301, PubMed:9430220). Primarily functions as a ligand binding subunit as it lacks the capacity to signal. KLRD1-KLRC1 acts as an immune inhibitory receptor. Key inhibitory receptor on natural killer (NK) cells that regulates their activation and effector functions (PubMed:30860984, PubMed:9430220, PubMed:9485206, PubMed:9486650). Dominantly counteracts T cell receptor signaling on a subset of memory/effector CD8-positive T cells as part of an antigen-driven response to avoid autoimmunity (PubMed:12387742). On intraepithelial CD8-positive gamma-delta regulatory T cells triggers TGFB1 secretion, which in turn limits the cytotoxic programming of intraepithelial CD8-positive alpha-beta T cells, distinguishing harmless from pathogenic antigens (PubMed:18064301). In HLA-E-rich tumor microenvironment, acts as an immune inhibitory checkpoint and may contribute to progressive loss of effector functions of NK cells and tumor-specific T cells, a state known as cell exhaustion (PubMed:30503213, PubMed:30860984). Upon HLA-E-peptide binding, transmits intracellular signals through KLRC1 immunoreceptor tyrosine-based inhibition motifs (ITIMs) by recruiting INPP5D/SHIP-1 and INPPL1/SHIP-2 tyrosine phosphatases to ITIMs, and ultimately opposing signals transmitted by activating receptors through dephosphorylation of proximal signaling molecules (PubMed:12165520, PubMed:9485206). KLRD1-KLRC2 acts as an immune activating receptor (PubMed:15940674, PubMed:9655483). On cytotoxic lymphocyte subsets recognizes HLA-E loaded with signal sequence-derived peptides from non-classical MHC class Ib HLA-G molecules, likely playing a role in the generation and effector functions of adaptive NK cells and in maternal-fetal tolerance during pregnancy (PubMed:30134159, PubMed:9754572). Regulates the effector functions of terminally differentiated cytotoxic lymphocyte subsets, and in particular may play a role in adaptive NK cell response to viral infection (PubMed:20952657, PubMed:21825173). Upon HLA-E-peptide binding, transmits intracellular signals via the adapter protein TYROBP/DAP12, triggering the phosphorylation of proximal signaling molecules and cell activation (PubMed:15940674, PubMed:9655483). (Microbial infection) Viruses like human cytomegalovirus have evolved an escape mechanism whereby virus-induced down-regulation of host MHC class I molecules is coupled to the binding of viral peptides to HLA-E, restoring HLA-E expression and inducing HLA-E-dependent NK cell immune tolerance to infected cells. Recognizes HLA-E in complex with human cytomegalovirus UL40-derived peptide (VMAPRTLIL) and inhibits NK cell cytotoxicity. (Microbial infection) May recognize HLA-E in complex with HIV-1 gag/Capsid protein p24-derived peptide (AISPRTLNA) on infected cells and may inhibit NK cell cytotoxicity, a mechanism that allows HIV-1 to escape immune recognition. (Microbial infection) Upon SARS-CoV-2 infection, may contribute to functional exhaustion of cytotoxic NK cells and CD8-positive T cells (PubMed:32859121). On NK cells, may recognize HLA-E in complex with SARS-CoV-2 S/Spike protein S1-derived peptide (LQPRTFLL) expressed on the surface of lung epithelial cells, inducing NK cell exhaustion and dampening antiviral immune surveillance (PubMed:32859121).

Alternative names

Recommended products

Rabbit Polyclonal CD94 antibody. Suitable for IHC-P and reacts with Human samples. Immunogen corresponding to Synthetic Peptide within Mouse Klrd1 aa 1-100 conjugated to Keyhole Limpet Haemocyanin.

Key facts

Isotype
IgG
Form
Liquid
Clonality
Polyclonal
Immunogen
  • Synthetic Peptide within Mouse Klrd1 aa 1-100 conjugated to Keyhole Limpet Haemocyanin. The exact immunogen used to generate this antibody is proprietary information. Database link O54707
Purification technique
Affinity purification Protein A
Concentration
Loading...

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle

Notes

Abcam is leading the way to address reproducibility in scientific research with our highly validated recombinant monoclonal and recombinant multiclonal antibodies. Search & select one of Abcam's thousands of recombinant alternatives to eliminate batch-variability and unnecessary animal use.

If you do not find a host species to meet your needs, our catalogue and custom Chimeric range provides scientists the specificity of Abcam's RabMAbs in the species backbone of your choice. Remember to also review our range of edited cell lines, proteins and biochemicals relevant to your target that may help you further your research goals.

Abcam antibodies are extensively validated in a wide range of species and applications, so please check the reagent specifications meet your scientific needs before purchasing. If you have any questions or bespoke requirements, simply visit the Contact Us page to send us an inquiry or contact our Support Team ahead of purchase.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.
Activity summary

CD94 also known as killer cell lectin-like receptor subfamily D member 1 (KLRD1) plays a significant mechanical role in the immune system. This protein forms part of a receptor family involved in natural killer (NK) cell function. CD94 typically assembles on the cell surface as a heterodimer often pairing with NKG2 proteins. Weighing approximately 30 kDa CD94 mainly exhibits expression on NK cells and a subset of T cells where it contributes to immune regulation.

Biological function summary

CD94 is essential in recognizing and binding to non-classical MHC class I molecules when it pairs with NKG2 molecules such as NKG2A or NKG2C. This dimer forms a complex receptor which plays an important role in modulating NK cell activity. Through this receptor complex CD94 influences the immune response by either inhibiting or activating NK cells depending on its NKG2 partner. This regulation helps maintain a balanced immune response preventing excessive activation and autoimmunity.

Pathways

CD94 interacts with the signaling pathways related to the immune response. In particular it is involved in the natural killer cell lectin-like receptor signaling pathway. This pathway manages the activation and inhibition of NK cells integrating signals received through various receptors including CD94/NKG2 dimers. Associated proteins like DAP12 may amplify these signals which ultimately influence cytotoxic activities and cytokine production.

Associated diseases and disorders

CD94 has notable connections with conditions such as cancer and viral infections. For example certain tumors manipulate CD94 expression on NK cells to evade immune surveillance. Additionally alterations in CD94 and its partner molecules like NKG2A have been observed in viral infections possibly affecting how the immune system responds. Understanding CD94's relationship with these diseases can offer insights into potential therapeutic strategies targeting immune regulation.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

1 product image

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody (ab217362), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody (ab217362)

    Immunohistochemical analysis of paraformaldehyde-fixed and paraffin-embedded Human lung cancer tissue labeling CD94 with ab217362 at 1/500 dilution, followed by conjugation to the secondary antibody and DAB staining.
