Rabbit Recombinant Monoclonal CD94 antibody. Suitable for IHC-P, mIHC and reacts with Transfected cell line - Mouse, Mouse samples.

Be the first to review this product! Submit a review

Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (AB322460), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (AB322460), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (AB322460), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (AB322460), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (AB322460), expandable thumbnail

Key facts

Isotype
IgG
Host species
Rabbit
Storage buffer

pH: 7.2 - 7.4
Preservative: 0.01% Sodium azide
Constituents: PBS, 40% Glycerol (glycerin, glycerine), 0.05% BSA

Form
Liquid
Clonality
Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IHC-PmIHCICC/IFWB
Mouse
Tested
Tested
Not recommended
Not recommended
Transfected cell line - Mouse
Tested
Not recommended
Not recommended
Not recommended

Tested
Tested

Species
Transfected cell line - Mouse
Dilution info
1/2000
Notes

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Species
Mouse
Dilution info
1/100
Notes

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Tested
Tested

Species
Mouse
Dilution info
1/100
Notes

Perform heat-mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Not recommended
Not recommended

Species
Transfected cell line - Mouse
Dilution info
-
Notes

-

Not recommended
Not recommended

Species
Mouse, Transfected cell line - Mouse
Dilution info
-
Notes

-

Not recommended
Not recommended

Species
Mouse, Transfected cell line - Mouse
Dilution info
-
Notes

-

Target data

Function

Immune receptor involved in self-nonself discrimination. In complex with KLRC1 or KLRC2 on cytotoxic and regulatory lymphocyte subsets, recognizes non-classical major histocompatibility (MHC) class Ib molecule MHC-E loaded with self-peptides derived from the signal sequence of classical MHC class Ia and non-classical MHC class Ib molecules. Enables cytotoxic cells to monitor the expression of MHC class I molecules in healthy cells and to tolerate self. Primarily functions as a ligand binding subunit as it lacks the capacity to signal. KLRD1-KLRC1 acts as an immune inhibitory receptor. Key inhibitory receptor on natural killer (NK) cells that regulates their activation and effector functions. Dominantly counteracts T cell receptor signaling on a subset of memory/effector CD8-positive T cells as part of an antigen-driven response to avoid autoimmunity. On intraepithelial CD8-positive gamma-delta regulatory T cells triggers TGFB1 secretion, which in turn limits the cytotoxic programming of intraepithelial CD8-positive alpha-beta T cells, distinguishing harmless from pathogenic antigens. In MHC-E-rich tumor microenvironment, acts as an immune inhibitory checkpoint and may contribute to progressive loss of effector functions of NK cells and tumor-specific T cells, a state known as cell exhaustion. Upon MHC-E-peptide binding, transmits intracellular signals through KLRC1 immunoreceptor tyrosine-based inhibition motifs (ITIMs) by recruiting INPP5D/SHIP-1 and INPPL1/SHIP-2 tyrosine phosphatases to ITIMs, and ultimately opposing signals transmitted by activating receptors through dephosphorylation of proximal signaling molecules. KLRD1-KLRC2 acts as an immune activating receptor. On cytotoxic lymphocyte subsets recognizes MHC-E loaded with signal sequence-derived peptides from non-classical MHC class Ib MHC-G molecules, likely playing a role in the generation and effector functions of adaptive NK cells and in maternal-fetal tolerance during pregnancy. Regulates the effector functions of terminally differentiated cytotoxic lymphocyte subsets, and in particular may play a role in adaptive NK cell response to viral infection. Upon MHC-E-peptide binding, transmits intracellular signals via the adapter protein TYROBP/DAP12, triggering the phosphorylation of proximal signaling molecules and cell activation.

Alternative names

CD94, Cd94, Klrd1, Natural killer cells antigen CD94, Killer cell lectin-like receptor subfamily D member 1

Rabbit Recombinant Monoclonal CD94 antibody. Suitable for IHC-P, mIHC and reacts with Transfected cell line - Mouse, Mouse samples.

Key facts

Isotype
IgG
Form
Liquid
Clonality
Monoclonal
Immunogen
  • The exact immunogen used to generate this antibody is proprietary information.
Clone number
EPR26343-41
Purification technique
Affinity purification Protein A
Concentration
Loading...

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle

Notes

Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

7 product images

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Immunohistochemical analysis of paraffin-embedded Mouse spleen tissue labeling CD94 with ab322460 at 1/100 (5.07 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Positive staining in scattered cells of mouse spleen.

    The section was incubated with ab322460 for 30 mins at room temperature.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument

    Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Immunohistochemical analysis of paraffin-embedded Mouse T-cell lymphoma tissue labeling CD94 with ab322460 at 1/100 (5.07 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Positive staining in mouse T-cell lymphoma.

    The section was incubated with ab322460 for 30 mins at room temperature.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument

    Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Immunohistochemical analysis of paraffin-embedded (A) NK cells (C57BL/6 mouse spleen) pellets; (B) WEHI-231 (mouse B cell lymphoma B lymphocyte) cell pellets. tissue labeling CD94 with ab322460 at 1/100 (5.07 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Positive staining in A: NK cells (C57BL/6 mouse spleen) pellets and no staining in B: WEHI-231 cell pellets.

    The section was incubated with ab322460 for 30 mins at room temperature.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument

    Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Immunohistochemical analysis of paraffin-embedded (A) HEK-293T (human embryonic kidney epithelial cell) transfected with a mouse KLRD1 expression vector containing a his tag; (B) HEK-293T transfected with empty vector containing a his tag. tissue labeling CD94 with ab322460 at 1/2000 (0.254 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Positive staining in (A) HEK-293T (human embryonic kidney epithelial cell) transfected with a mouse KLRD1 expression vector containing a his tag, and no staining in (B) HEK-293T transfected with empty vector containing a his tag.

    The section was incubated with ab322460 for 30 mins at room temperature.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument

    Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Immunohistochemical analysis of paraffin-embedded Mouse cerebrum tissue labeling CD94 with ab322460 at 1/100 (5.07 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Negative control: No staining in mouse cerebrum.

    The section was incubated with ab322460 for 30 mins at room temperature.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument

    Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Immunohistochemical analysis of paraffin-embedded Mouse liver tissue labeling CD94 with ab322460 at 1/100 (5.07 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Negative control: No staining in mouse liver.

    The section was incubated with ab322460 for 30 mins at room temperature.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument

    Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

    Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

  • Multiplex immunohistochemistry - Anti-CD94 antibody[EPR26343-41] (ab322460), expandable thumbnail

    Multiplex immunohistochemistry - Anti-CD94 antibody[EPR26343-41] (ab322460)

    Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded mouse spleen tissue staining CD94 with ab322460 at a 1:100 (5.07 ug/ml) dilution, Anti-NCR1 antibody [EPR23097-35] ab233558 anti-NCR1 used at 1:500 (1.114 ug/ml) dilution.

    Panel A: merged staining of anti-CD94 (green; Opal™520), anti-NCR1 (magenta; Opal™570) on mouse spleen.

    Panel B: anti-CD94 staining natural killer (NK) cells in mouse spleen.

    Panel C: anti-NCR11 staining natural killer (NK) cells in mouse spleen.

    Panel D: Nuclear DNA was labeled with DAPI (shown in blue).

    The section was incubated in three rounds of staining: in the order of ab322460 and Anti-NCR1 antibody [EPR23097-35] ab233558 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument with an Opal™ 4-color kit. Image acquisition was performed with Leica SP8 confocal microscope.

    Nuclear counter stain with DAPI.

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.
