Anti-Chitinase 3 like protein 3 antibody [EPR21248]

2 product images

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Chitinase 3 like protein 3 antibody [EPR21248] (ab230610)

  IHC image of Chitinase 3 like protein 3 staining in mouse lung formalin fixed paraffin embedded tissue section, performed on a Leica BOND^TM system using the standard protocol F (with no post primary). The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab230610, 0.01μg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.


  For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Chitinase 3 like protein 3 antibody [EPR21248] (ab230610)

  IHC image of Chitinase 3 like protein 3 staining in mouse spleen formalin fixed paraffin embedded tissue section, performed on a Leica BOND^TM system using the standard protocol B. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab230610, 0.01μg/ml, for 15 mins at room temperature. A goat anti-rabbit biotinylated secondary antibody was used to detect the primary, and visualized using an HRP conjugated ABC system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.


  For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.
