Anti-CPS1 antibody [2E4AE11]

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CPS1 antibody [2E4AE11] (AB110303)

IHC image of ab110303 staining in human duodenum formalin fixed paraffin embedded tissue section, performed on a Leica Bond^TM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab110303, 10µg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

• Flow Cyt

Unknown

Flow Cytometry - Anti-CPS1 antibody [2E4AE11] (AB110303)

Flow cytometric analysis using ab110303 at 1µg/ml staining CPS1 in HeLa cells (blue). Isotype control antibody (red).

• ICC

Unknown

Immunocytochemistry - Anti-CPS1 antibody [2E4AE11] (AB110303)

Immunocytochemistry analysis using ab110303 at 10μg/ml staining CPS1 in HDFn cells (paraformaldehyde fixed and Triton X-100 permeabilized). The secondary antibody was (red) Alexa Fluor® 594 goat anti-mouse IgG (H+L) used at a 1/1000 dilution for 1h. 10% Goat serum was used as the blocking agent for all blocking steps. DAPI was used to stain the cell nuclei (blue). Target protein locates mainly in mitochondria.

• IP

Unknown

Immunoprecipitation - Anti-CPS1 antibody [2E4AE11] (AB110303)

Detection of ab110303 by immunoprecipitation staining of 164kDa CPS1, a liver mitochondrial marker in human liver mitochondrial lysate.

All lanes:

Immunoprecipitation - Anti-CPS1 antibody [2E4AE11] (ab110303)

Predicted band size: 165 kDa
