Anti-EGFR antibody [EGFR1] - BSA and Azide free

• IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Anti-EGFR antibody [EGFR1] - BSA and Azide free (AB264523)

IHC image of EGFR staining in a section of frozen normal human placenta, fixed in 10% paraformaldehyde (10 min). Staining was performed on a Leica BOND^TM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20mins. The section was then incubated with ab30, 10ug/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX. The inset secondary-only control image is taken from an identical assay without primary antibody.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

This data was developed using the same antibody clone in a different buffer formulation containing PBS and sodium azide (ab30).

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-EGFR antibody [EGFR1] - BSA and Azide free (AB264523)

This data was developed using the same antibody clone in a different buffer formulation without PBS and sodium azide (ab30)

ab30 staining EGFR in A431 cells. The cells were fixed with 100% methanol (5 min), permeabilized with 0.1% PBS-Tween for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1h. The cells were then incubated overnight at 4°C with ab30 at 1µg/ml and ab6046, Rabbit polyclonal to beta Tubulin - Loading Control. Cells were then incubated with ab150117, Goat polyclonal Secondary Antibody to Mouse IgG H&L (Alexa Fluor^® 488) preadsorbed at 1/1000 dilution (shown in green) and ab150080, Goat polyclonal Secondary Antibody to Rabbit IgG - H&L (Alexa Fluor^® 594) at 1/1000 dilution (shown in pseudocolour red). Nuclear DNA was labelled with DAPI (shown in blue).

Image was acquired with a high-content analyser (Operetta CLS, Perkin Elmer) and a maximum intensity projection of confocal sections is shown.

• Flow Cyt

Lab

Flow Cytometry - Anti-EGFR antibody [EGFR1] - BSA and Azide free (AB264523)

Overlay histograms showing left positive A431 cells and right negative Jurkat cells stained with ab30 (red line). The cells were incubated in 1x PBS / 10% normal goat serum to block non-specific protein-protein interactions followed by the antibody (ab30, 1x10⁶ cells in 100ul at 1ug/ml) for 30 min on ice. The secondary antibody used was Alexa Fluor^® 488 goat anti-mouse IgG (H&L) preabsorbed (ab150117) at 1/2000 dilution for 30 min on ice.

Isotype control antibody (black line) was mouse IgG2bκ (ab170192) used at the same concentration and conditions as the primary antibody. Unlabelled sample (blue line) was also used as a control.

Acquisition of >5,000 events were collected using a 50 mW Blue laser (488nm) and 530/30 bandpass filter.

This data was developed using the same antibody clone in a different buffer formulation containing PBS and sodium azide (ab30).
