Anti-F4/80 antibody [SP115]

6 product images

•

  Lean, Q.Y. et al PLoS One. 2015 Jul 28;10(7):e0134259. doi: 10.1371/journal.pone.0134259. eCollection 2015 Reproduced under the Creative Commons license http://creativecommons.org/licenses/by/4.0/

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-F4/80 antibody [SP115] (ab111101)

  Representative immunostaining of F4/80-positive macrophages in the distal colon from healthy and colitic mice treated with and without enoxaparin.


  For immunohistochemical staining, antigen retrieval was performed by incubating the sections for 10 minutes at 97°C in 1 mM EDTA buffer, pH 8 or 10 mM citrate buffer, pH 6. Activity of endogenous peroxidase was blocked by incubating sections with 3% v/v hydrogen for 20 minutes. Sections were then washed with 0.05 M Tris-buffered saline containing 0.5% v/v Tween 20 (TBST), pH 7.6. Subsequently, sections were incubated with serum-free protein block for 10 minutes. Colon sections were then incubated with primary antibody ab111101 at 1/100 dilution overnight at 4°C or room temperature for 1 hour. Sections were then washed 3 x 5 minutes and allowed to react with secondary antibody: anti-rabbit immunoglobulin C conjugated to horseradish peroxidase (HRP) (Goat Anti-Rabbit IgG H&L (HRP) preadsorbed ab7090) at 1/300 dilution at room temperature for 1 hour.

  Scale bar = 100 μm for 400 x magnification. Control, C; untreated colitis, DSS; oral enoxaparin, OE; intraperitoneal injection of enoxaparin, IPE.

•

  Lean, Q.Y. et al PLoS One. 2015 Jul 28;10(7):e0134259. doi: 10.1371/journal.pone.0134259. eCollection 2015 Reproduced under the Creative Commons license http://creativecommons.org/licenses/by/4.0/

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-F4/80 antibody [SP115] (ab111101)

  Representative images of (A) M1 macrophages (F4/80⁺ and iNOS⁺) and (B) M2 macrophages (F4/80⁺ and CD206⁺) using colon tissue from n = 3–5 mice. F4/80 positive cells were visualized using Alexa Fluor 594-conjugated goat anti-rat IgG (red). Nuclei were stained with 4',6-diamidino-2-phenylindole (DAPI, blue).


  Scale bar = 50 μm for 400 × magnification. Control, C; untreated colitis, DSS; colitis with oral enoxaparin, DSS+OE.

  For immunofluorescence staining, sections were dewaxed and rehydrated before antigen retrieval using 10 mM citrate buffer, pH 6 for 15 minutes at 97°C. Sections were incubated with serum-free protein block and permeabilized with 0.4% v/v Triton-X at room temperature for 30 minutes. Sections were incubated with primary antibodies anti-F4/80 (Anti-F4/80 antibody [BM8] ab16911) at 1/25 dilution overnight at 4°C or at room temperature for 1 hour. Sections were washed with TBST 3 × 10 minutes and incubated with species-specific secondary antibodies: anti-rat IgG H&L AlexaFluor 594 (Goat Anti-Rat IgG H&L (Alexa Fluor® 594) ab150160, Abcam, 1:1000) and anti-rabbit IgG H&L AlexaFluor 488 (A11070{"type":"entrez-nucleotide","attrs":{"text":"A11070","term_id":"490922","term_text":"A11070"}}, Thermo Fisher Scientific, Melbourne, Australia, 1:1000) at room temperature for 2 hours. Sections were rinsed with TBST 3 × 10 minutes, followed by a quick wash with distilled water before mounting using Glycerol Mounting Medium (Abcam) that contained 4',6-diamidino-2-phenylindole (DAPI) and 1,4-diazobicyclo-2,2,2-octane (DABCO). Labelled tissues were visualized using a Leica DM LB2 microscope. Fluorescence images (400 × magnification) were captured using NIS-Elements 4.13 (Nikon) software.

  For full image see PMID: 26218284.

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-F4/80 antibody [SP115] (ab111101)

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) analysis of Mouse liver tissue sections labeling F4/80 with ab111101 at 1/250 dilution (0.48 μg/ml). Heat mediated antigen retrieval using Antigen Retrieval Buffer (100X Tris-EDTA Buffer, pH 9.0) ab93684 (Tris/EDTA buffer, pH 9.0). Goat Anti-Rabbit IgG H&L (HRP) was used as the secondary antibody. Hematoxylin was used as a counterstain. Positive staining on macrophages in the mouse liver.

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-F4/80 antibody [SP115] (ab111101)

  ab111101 at 1/100 dilution staining F4/80 in Formalin-fixed, paraffin-embedded Mouse liver tissue.

•

  This image is of an Abreciew submitted by Francois Daubeuf.

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-F4/80 antibody [SP115] (ab111101)



  Immunohistochemistry analysis of Formalin fixed paraffin-embedded mouse lung tissue sections labeling F4/80 with ab111101 at 1/200 for 16 hours at 4°C. Biotin conjugated Goat anti-rabbit polyclonal antibody at 1/500 was used as the secondary. Antigen retrieval was heat mediated using citrate buffer pH 6.0.



•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-F4/80 antibody [SP115] (ab111101)

  Immunohistochemical analysis staining for macrophages in (A) mouse uterus and (B) mouse spleen using ab111101 at a dilution of 1:200. HRP Anti-Rabbit IgG (Peroxidase) Polymer D antibody was used as a secondary.
