Anti-Fibronectin antibody [F1] - Low endotoxin, Azide free

• ICC/IF

Unknown

Immunocytochemistry/ Immunofluorescence - Anti-Fibronectin antibody [F1] - Low endotoxin, Azide free (AB219366)

ICC/IF image of unpurified ab32419 stained HepG2 (Human liver hepatocellular carcinoma cell line) cells. The cells were fixed in 4% formaldehyde (10 minutes) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1 hour to permeabilize the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody ab32419 at 1/100 dilution overnight at +4°C. The secondary antibody (green) was DyLight^® 488 goat anti- rabbit (ab96899) IgG (H+L) used at a 1/1000 dilution for 1 hour. Alexa Fluor^® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1 hour. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43 μM.

This data was developed using the same antibody clone in a different buffer formulation containing PBS BSA glycerol and sodium azide (ab32419).

• ICC/IF

AbReview31625****

Immunocytochemistry/ Immunofluorescence - Anti-Fibronectin antibody [F1] - Low endotoxin, Azide free (AB219366)

ICC/IF image of unpurified ab32419 stained human mesenchymal stem cells. The cells were fixed in paraformaldehyde and then incubated in 0.1%BSA / 1% goat serum for 30 minutes, to block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab32419, 1/100 dilution) for 2 hours at 22°C. The secondary antibody (green) was Alexa Fluor^® 488 goat anti-rabbit IgG. DAPI was used to stain the cell nuclei (blue).

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab32419).

This image is courtesy of an anonymous Abreview.

• Flow Cyt (Intra)

Unknown

Flow Cytometry (Intracellular) - Anti-Fibronectin antibody [F1] - Low endotoxin, Azide free (AB219366)

Intracellular Flow Cytometry analysis of HepG2 (Human liver hepatocellular carcinoma cell line) cells labeling Fibronectin with purified ab32419 at 1/20 dilution (10 μg/mL) (red). Cells were fixed with 4% paraformaldehyde and permeabilized with 90% methanol. A Goat anti rabbit IgG (Alexa Fluor^®488) at 1/2000 dilution was used as the secondary antibody. Rabbit monoclonal IgG (Black) was used as the isotype control, cells without incubation with primary antibody and secondary antibody (Blue) was used as the unlabeled control.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab32419).

• ICC/IF

Lab

Immunocytochemistry/ Immunofluorescence - Anti-Fibronectin antibody [F1] - Low endotoxin, Azide free (AB219366)

Clone F1 (ab219366) has been successfully conjugated by Abcam. This image was generated using Anti-Fibronectin antibody [F1] (Alexa Fluor® 488). Please refer to ab198933 for protocol details.

ab198933 staining Fibronectin in A431 (Human epidermoid carcinoma cell line) cells. The cells were fixed with 4% formaldehyde (10 minutes), permeabilized with 0.1% Triton X-100 for 5 minutes and then blocked with 1% BSA/10% normal goat serum/0.3M glycine in 0.1% PBS-Tween for 1 hour. The cells were then incubated overnight at +4°C with ab198933 at a 1/100 dilution (shown in green) and ab195889, Mouse monoclonal to alpha Tubulin (Alexa Fluor^® 594), at a 1/250 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue).

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Fibronectin antibody [F1] - Low endotoxin, Azide free (AB219366)

Immunohistochemical staining of paraffin embedded human breast carcinoma with purified ab32419 at a dilution of 1/250. The secondary antibody used is ab97051 a HRP-conjugated goat anti-rabbit IgG (H+L) at a dilution of 1/500. The sample is counter-stained with hematoxylin. Antigen retrieval was perfomed using Tris-EDTA buffer pH 9.0. PBS was used instead of the primary antibody as the negative control and is shown in the inset.

This data was developed using the same antibody clone in a different buffer formulation containing PBS BSA glycerol and sodium azide (ab32419).
