Anti-FOXP3 antibody [mAbcam 450] - Mouse IgG3

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-FOXP3 antibody [mAbcam 450] - Mouse IgG3 (AB450)

IHC image of FOXP3 staining in a section of formalin-fixed paraffin-embedded normal human tonsil* performed on a Leica BOND^TM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20mins. The section was then incubated with ab450, 1ug/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

• IHC-Fr

Lab

Immunohistochemistry (Frozen sections) - Anti-FOXP3 antibody [mAbcam 450] - Mouse IgG3 (AB450)

IHC image of FOXP3 staining in a section of formalin-fixed frozen normal human tonsil* performed on a Leica BOND^TM system using the standard protocol F. The section was then incubated with ab450, 5ug/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

• WB

Unknown

Western blot - Anti-FOXP3 antibody [mAbcam 450] - Mouse IgG3 (AB450)

All lanes:

Western blot - Anti-FOXP3 antibody [mAbcam 450] - Mouse IgG3 (ab450) at 1 µg/mL

Lane 1:

HEK293 cells overexpressing human FOXP3 at 20 µg

Lane 2:

HEK293 cells overexpressing human FOXP3 at 20 µg with Human FOXP3 peptide (<a href='/en-us/products/unavailable/human-foxp3-peptide-ab16809'>ab16809</a>)

Secondary

All lanes:

Western blot - Rabbit Anti-Mouse IgG H&L (HRP) (<a href='/en-us/products/secondary-antibodies/rabbit-mouse-igg-h-l-hrp-ab6728'>ab6728</a>) at 1/5000 dilution

Predicted band size: 47 kDa

Observed band size: 50 kDa

false

Exposure time: 45s
