Anti-GAA antibody [EPR30339-80]

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunohistochemical analysis of formalin fixed paraffin embedded human kidney labelling GAA with ab325193 at a concentration of 0.01µg/ml. The immunostaining was performed on a Ventana DISCOVERY ULTRA (Roche Tissue Diagnostics) instrument with a OptiView DAB IHC Detection Kit. Heat mediated antigen retrieval was performed with DISCOVERY cell conditioning solution (CC1) 100°C, pH8.5 for 32mins.

ab325193 Anti-GAA antibody [EPR30339-80] was incubated for 16mins at 37°C. Sections were counterstained with Hematoxylin II. Image inset shows absence of staining in secondary antibody only control.

Customers are encouraged to optimise antigen retrieval conditions, antibody concentration, incubation times and temperature for best results in their own IHC assay workflow (automated and manual)

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunohistochemical analysis of formalin fixed paraffin embedded human placenta labelling GAA with ab325193 at a concentration of 0.01µg/ml. The immunostaining was performed on a Ventana DISCOVERY ULTRA (Roche Tissue Diagnostics) instrument with a OptiView DAB IHC Detection Kit. Heat mediated antigen retrieval was performed with DISCOVERY cell conditioning solution (CC1) 100°C, pH8.5 for 32mins.

ab325193 Anti-GAA antibody [EPR30339-80] was incubated for 16mins at 37°C. Sections were counterstained with Hematoxylin II. Image inset shows absence of staining in secondary antibody only control.

Customers are encouraged to optimise antigen retrieval conditions, antibody concentration, incubation times and temperature for best results in their own IHC assay workflow (automated and manual)

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunohistochemical analysis of paraffin-embedded Human normal skeletal muscle tissue labeling GAA with ab325193 at 1/10000 (0.05 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Negative control : No staining human skeletal muscle.
The section was incubated with ab325193 for 15 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument.

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Heat mediated antigen retrieval was performed with Citrate buffer (pH 6.0, Epitope Retrieval Solution 1) for 20 mins.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunohistochemical analysis of paraffin-embedded Human normal kidney tissue labeling GAA with ab325193 at 1/10000 (0.05ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Positive staining in human kidney.
The section was incubated with ab325193 for 15 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument.

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Heat mediated antigen retrieval was performed with Citrate buffer (pH 6.0, Epitope Retrieval Solution 1) for 20 mins.

• ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunofluorescent analysis of 100% methanol-fixed, 0.1% Tween-20 permeabilized Hek293T WT cells labelling GAA with ab325193 at 1/500 (1.0 ug/ml) dilution, followed by ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed antibody at 2 ug/ml dilution (Green).

Confocal image showing Lysosomal alpha-glucosidase staining in Hek293T wildtype and Hek293T-GAA knockout cell lines (shown in green). The counterstain was observed in magenta. Nuclear DNA was labelled with DAPI (shown in blue). Image was acquired with a high-content analyser (Revvity, Operetta CLS) and a maximum intensity projection of confocal sections is shown.

ab7291 Anti-alpha Tubulin mouse monoclonal antibody was used to counterstain tubulin at 1 ug/ml dilution, followed by ab150120 Goat Anti-Mouse IgG H&L (Alexa Fluor® 594) at 2 ug/ml dilution (Magenta).

• ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunofluorescent analysis of 100% methanol-fixed, 0.1% Tween-20 permeabilized A549 and U2OS cells labelling GAA with ab325193 at 1/500 (1.0 ug/ml) dilution, followed by ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed antibody at 2 ug/ml dilution (Green).

Confocal image showing Lysosomal alpha-glucosidase staining in A549 and U2OS cell lines (shown in green). The counterstain was observed in magenta. Nuclear DNA was labelled with DAPI (shown in blue). Image was acquired with a high-content analyser (Revvity, Operetta CLS) and a maximum intensity projection of confocal sections is shown.

ab7291 Anti-alpha Tubulin mouse monoclonal antibody was used to counterstain tubulin at 1 ug/ml dilution, followed by ab150120 Goat Anti-Mouse IgG H&L (Alexa Fluor® 594) at 2 ug/ml dilution (Magenta).

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunohistochemical analysis of paraffin-embedded Human normal prostate tissue labeling GAA with ab325193 at 1/10000 (0.05ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Positive staining in human prostate.
The section was incubated with ab325193 for 15 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument.

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Heat mediated antigen retrieval was performed with Citrate buffer (pH 6.0, Epitope Retrieval Solution 1) for 20 mins.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GAA antibody [EPR30339-80] (AB325193)

Immunohistochemical analysis of paraffin-embedded Human normal placenta tissue labeling GAA with ab325193 at 1/10000 (0.05ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Positive staining in human placenta.
The section was incubated with ab325193 for 15 mins at room temperature.
The immunostaining was performed on a Leica Biosystems BOND® RX instrument.

Counterstained with Hematoxylin.

Secondary antibody only control : Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

Heat mediated antigen retrieval was performed with Citrate buffer (pH 6.0, Epitope Retrieval Solution 1) for 20 mins.
