Anti-GABRA4 antibody [EPR28365-209]

14 product images

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Human cerebrum using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Human cerebrum tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Positive staining on human cerebrum.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Human thalamus using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Human thalamus tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Positive staining on human thalamus.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Mouse brain using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Mouse brain tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Positive staining on mouse brain (PMID: 17005728).

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Mouse cerebrum using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Mouse cerebrum tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Positive staining on mouse cerebrum (PMID: 17005728).

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Rat brain using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Rat brain tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Positive staining on rat brain.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Frozen sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Frozen sections) staining of Mouse hippocampus (perfused fixed) using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse hippocampus (perfused fixed) tissue labeling GABRA4 with ab323502 at 1/50 (10.24 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbed at 1/1000 2 ug/mL dilution (Green).

  Panel A: merged staining of anti-GABRA4 (ab323502, green), anti-NeuN (Alexa Fluor® 647 Anti-NeuN antibody [EPR12763] - Neuronal Marker ab190565, grey) and anti-GFAP (Alexa Fluor® 594 Anti-GFAP antibody [EPR1034Y] - Astrocyte Marker ab201732, magenta) on mouse hippocampus.

  Panel B: anti-GABRA4 stained on mouse hippocampus.

  Panel C: anti-NeuN stained in neurons of mouse hippocampus.

  Panel D: anti-GFAP stained in astrocytes of mouse hippocampus.

  The section was incubated in two rounds of staining: in the order of ab323502 and Alexa Fluor® 647 Anti-NeuN antibody [EPR12763] - Neuronal Marker ab190565, Alexa Fluor® 594 Anti-GFAP antibody [EPR1034Y] - Astrocyte Marker ab201732 for 1 hr at room temperature. The nuclear counterstain was DAPI (Blue). The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbedat 1/1000 2 ug/mL dilution.

  Heat mediated antigen retrieval using sodium citrate buffer (10mM citrate pH 6.0 + 0.05% Tween-20)

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Rat cerebrum using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Rat cerebrum tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Positive staining on rat cerebrum.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Human lung using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Human lung tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Negative control: No staining on human lung.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded (A) HEK-293T (human embryonic kidney epithelial cell) transfected with a human GABRA4 expression vector containing a myc-His-tag. (B) HEK-293T cells transfected with a human GABRA1 expression vector containing a myc-His-tag. (C) HEK-293T cells transfected with a human GBRA2 expression vector containing a myc-His-tag. (D) HEK-293T cells transfected with a human GBRA3 expression vector containing a myc-His-tag. (E) HEK-293T cells transfected with a human GABRA5 expression vector containing a myc-His-tag. (F) HEK-293T cells transfected with a human GABRA6 expression vector containing a myc-His-tag. (G) HEK-293T cells transfected with empty vector containing a myc-His-tag. tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  This antibody cross-react with GABRA 5 and 6, and weakly cross-react with GABRA 1, 2 and 3. Positive staining on (A) HEK-293T transfected with a human GABRA4 expression vector, (E) HEK-293T cells transfected with a human GABRA5 expression vector and (F) HEK-293T cells transfected with a human GBRA6 expression vector, weak staining on (B) HEK-293T cells transfected with a human GBRA1 expression vector, (C) HEK-293T cells transfected with a human GABRA2 expression vector and (D) HEK-293T cells transfected with a human GABRA3 expression vector, no staining on (G) HEK-293T transfected with empty vector.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Frozen sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Frozen sections) staining of Rat lung (perfused fixed) using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Rat lung (perfused fixed) tissue labeling GABRA4 with ab323502 at 1/50 (10.24 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbed at 1/1000 2 ug/mL dilution (Green).

  Negative control: confocal image showing no staining on rat lung. The nuclear counterstain was DAPI (Blue). The section was incubated with ab323502 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbedat 1/1000 2 ug/mL dilution.

  Heat mediated antigen retrieval using sodium citrate buffer (10mM citrate pH 6.0 + 0.05% Tween-20)

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Mouse lung using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Mouse lung tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Negative control: No staining on mouse lung.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Frozen sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Frozen sections) staining of Mouse lung (perfused fixed) using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse lung (perfused fixed) tissue labeling GABRA4 with ab323502 at 1/50 (10.24 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbed at 1/1000 2 ug/mL dilution (Green).

  Negative control: confocal image showing no staining on mouse lung. The nuclear counterstain was DAPI (Blue). The section was incubated with ab323502 for 60 mins at room temperature. The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbedat 1/1000 2 ug/mL dilution.

  Heat mediated antigen retrieval using sodium citrate buffer (10mM citrate pH 6.0 + 0.05% Tween-20)

•

  Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) staining of Rat lung using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of paraffin-embedded Rat lung tissue labeling GABRA4 with ab323502 at 1/2000 (0.256 ug/ml) dilution, followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Negative control: No staining on rat lung.

  The section was incubated with ab323502 for 30 mins at room temperature.

  The immunostaining was performed on a Leica Biosystems BOND® RX instrument

  Counterstained with Hematoxylin.

  Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection).

  Heat mediated antigen retrieval was performed with Tris-EDTA buffer (pH 9.0, Epitope Retrieval Solution2) for 20 mins

•

  Immunohistochemistry (Frozen sections) - Anti-GABRA4 antibody [EPR28365-209] (ab323502)

  GABRA4 Immunohistochemistry (Frozen sections) staining of Rat hippocampus (perfused fixed) using rabbit Anti-GABRA4 antibody

  Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Rat hippocampus (perfused fixed) tissue labeling GABRA4 with ab323502 at 1/50 (10.24 ug/ml) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbed at 1/1000 2 ug/mL dilution (Green).

  Panel A: merged staining of anti-GABRA4 (ab323502, green), anti-NeuN (Alexa Fluor® 647 Anti-NeuN antibody [EPR12763] - Neuronal Marker ab190565, grey) and anti-GFAP (Alexa Fluor® 594 Anti-GFAP antibody [EPR1034Y] - Astrocyte Marker ab201732, magenta) on rat hippocampus.

  Panel B: anti-GABRA4 stained on rat hippocampus.

  Panel C: anti-NeuN stained in neurons of rat hippocampus.

  Panel D: anti-GFAP stained in astrocytes of rat hippocampus.

  The section was incubated in two rounds of staining: in the order of ab323502 and Alexa Fluor® 647 Anti-NeuN antibody [EPR12763] - Neuronal Marker ab190565, Alexa Fluor® 594 Anti-GFAP antibody [EPR1034Y] - Astrocyte Marker ab201732 for 1 hr at room temperature. The nuclear counterstain was DAPI (Blue). The section was then mounted using Fluoromount®.The immunostaining was performed on a Leica Biosystems BOND® RX instrument. Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

  Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (AlexaFluor® 488) preadsorbedat 1/1000 2 ug/mL dilution.

  Heat mediated antigen retrieval using sodium citrate buffer (10mM citrate pH 6.0 + 0.05% Tween-20)
