Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free
- KO Validated
- RabMAb
- Recombinant
- What is this?
Be the first to review this product! Submit a review
|
(2 Publications )
- ICC/IF
Supplier Data
Immunocytochemistry/ Immunofluorescence - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (AB222222)
Immunofluorescent analysis of 100% methanol-fixed 0.1% Triton X-100 permeabilized A549 (Human lung carcinoma) cells labeling Integrin alpha V with ab179475 at 1/500 dilution followed by Goat anti-rabbit Alexa Fluor® 488 (IgG) (ab150077) secondary antibody at 1/400 dilution (green). Confocal image showing membrane and cytoplasm staining on A549 cell line. The nuclear counterstain is DAPI (blue). Tubulin is detected with ab7291 (anti-Tubulin mouse mAb) at 1/500 dilution and ab150120 (goat anti-mouse AlexaFluor®594 secondary antibody) at 1/500 dilution (red).
The negative controls are as follows :
-ve control 1 : ab179475 at 1/500 dilution followed by ab150120 (AlexaFluor®594 Goat anti-Mouse secondary) at 1/500 dilution.
-ve control 2 : ab7291 (anti-Tubulin mouse mAb) at 1/500 dilution followed by ab150077 (Alexa Fluor®488 Goat Anti-Rabbit IgG H&L) at 1/400 dilution.
This data was developed using the same antibody clone in a different buffer formulation containing PBS BSA glycerol and sodium azide (ab179475).
- IHC-P
Supplier Data
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (AB222222)
Immunohistochemical analysis of paraffin-embedded human transitional cell carcinoma of bladder tissue labeling Integrin alpha V with ab179475 at 1/500 dilution followed by Goat Anti-Rabbit HRP (IgG H&L) (ab97051) secondary antibody at 1/500 dilution. Membrane and weak cytoplasm staining on human transitional cell carcinoma of bladder is observed. Counter stained with Hematoxylin.
Negative control : Using PBS instead of primary antibody secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.
This data was developed using the same antibody clone in a different buffer formulation containing PBS BSA glycerol and sodium azide (ab179475).
Heat mediated antigen retrieval was performed with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.
- IHC-P
Supplier Data
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (AB222222)
Immunohistochemical analysis of paraffin-embedded human kidney tissue labeling Integrin alpha V with ab179475 at 1/500 dilution followed by Goat Anti-Rabbit HRP (IgG H&L) (ab97051) secondary antibody at 1/500 dilution. Membrane and cytoplasm staining on human kidney tubules is observed. Counter stained with Hematoxylin.
Negative control : Using PBS instead of primary antibody secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.
This data was developed using the same antibody clone in a different buffer formulation containing PBS BSA glycerol and sodium azide (ab179475).
Heat mediated antigen retrieval was performed with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.
- IP
Supplier Data
Immunoprecipitation - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (AB222222)
Integrin alpha V was immunoprecipitated from 1 mg of A549 (Human lung carcinoma) whole cell extract with ab179475 at 1/40 dilution. Western blot analysis was performed from the immunoprecipitate using ab179475 at 1/1000 dilution. Anti-Rabbit IgG (HRP), specific to the non-reduced form of IgG, was used as secondary antibody at 1/1500 dilution.
Lane 1 : A549 whole cell extract.
Lane 2 : PBS instead of A549 whole cell extract.
Blocking/Dilution buffer and concentration : 5% NFDM/TBST.
ab179475 can recognize 135kDa full length Integrin alpha V and 125kDa heavy chain. The 125 kDa band is Integrin alpha V heavy chain.
This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab179475).
All lanes:
Immunoprecipitation - Anti-Integrin alpha V antibody [EPR16800] (<a href='/en-us/products/primary-antibodies/integrin-alpha-v-antibody-epr16800-ab179475'>ab179475</a>)
Predicted band size: 116 kDa
Observed band size: 125 kDa
false
- IHC-P
Supplier Data
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (AB222222)
Immunohistochemical analysis of paraffin-embedded mouse kidney tissue labeling Integrin alpha V with ab179475 at 1/500 dilution followed by Goat Anti-Rabbit HRP (IgG H&L) (ab97051) secondary at 1/500 dilution. Membrane and cytoplasm staining on mouse kidney tubule and glomerulus is observed. Counter stained with Hematoxylin.
Negative control : Using PBS instead of primary antibody secondary antibody is Goat Anti-Rabbit IgG H&L (HRP) (ab97051) at 1/500 dilution.
This data was developed using the same antibody clone in a different buffer formulation containing PBS BSA glycerol and sodium azide (ab179475).
Heat mediated antigen retrieval was performed with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.
- WB
Lab
Western blot - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (AB222222)
This data was developed using ab179475, the same antibody clone in a different buffer formulation.
Western blot : Anti-Integrin alpha V antibody [EPR16800] ab179475 staining at 1/5000 dilution, shown in green; Mouse anti alpha Tubulin ab7291 loading control staining at 1/20000 dilution, shown in magenta. A band was observed at 116 kDa in Wild-type HCT 116 cell lysates with no signal observed at this size in ITGAV knockout HCT 116 cell line. To generate this image, samples were run on an SDS-PAGE gel then transferred onto a nitrocellulose membrane. Membranes were blocked in 100pc LICOR in TBS-0.1 % Tween 20 (TBS-T) before incubation with primary antibodies overnight at 4 C. Blots were washed four times in TBS-T, incubated with secondary antibodies for 1 h at room temperature, washed again four times then imaged. Secondary antibodies used were Goat anti-Rabbit 800CW and Goat anti-Mouse 680RD at 1/20,000 dilution.
Lanes 1 - 4:
Western blot - Anti-Integrin alpha V antibody [EPR16800] (<a href='/en-us/products/primary-antibodies/integrin-alpha-v-antibody-epr16800-ab179475'>ab179475</a>) at 1/5000 dilution
Lanes 1 - 4:
Western blot - Anti-Integrin alpha V antibody [EPR16800] - Low endotoxin, Azide free (ab222222) at 1/5000 dilution
Lanes 1 - 4:
Western blot - Anti-Integrin alpha V antibody [EPR16800] - BSA and Azide free (Detector) (<a href='/en-us/products/primary-antibodies/integrin-alpha-v-antibody-epr16800-bsa-and-azide-free-detector-ab245051'>ab245051</a>) at 1/5000 dilution
Lane 1:
Wild-type HCT 116 at 20 µg
Lane 2:
Western blot - Human ITGAV knockout HCT116 cell line (<a href='/en-us/products/cell-lines/human-itgav-knockout-hct116-cell-line-ab286702'>ab286702</a>) at 20 µg
Lane 3:
A549 at 20 µg
Lane 4:
Daudi at 20 µg
Secondary
All lanes:
Goat anti-Rabbit 800CW & Goat anti-Mouse 680RD at 1/20000 dilution
Predicted band size: 116 kDa
Observed band size: 116 kDa
false
Related conjugates and formulations (7)
-
Anti-Integrin alpha V antibody [EPR16800]
-
Anti-Integrin alpha V antibody [EPR16800] - BSA and Azide free (Detector)
-
Anti-Integrin alpha V antibody [EPR16800] - BSA and Azide free
-
519 Alexa Fluor® 488
Alexa Fluor® 488 Anti-Integrin alpha V antibody [EPR16800]
-
565 Alexa Fluor® 555
Alexa Fluor® 555 Anti-Integrin alpha V antibody [EPR16800]
-
665 Alexa Fluor® 647
Alexa Fluor® 647 Anti-Integrin alpha V antibody [EPR16800]
-
578 PE
PE Anti-Integrin alpha V antibody [EPR16800]
Reactivity data
Product details
ab222222 is the carrier-free version of ab179475.
Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.
What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:
- - High batch-to-batch consistency and reproducibility
- - Improved sensitivity and specificity
- - Long-term security of supply
- - Animal-free batch production
For more information, read more on recombinant antibodies.
Conjugation ready
Our carrier-free antibodies are typically supplied in a PBS-only formulation, purified and free of BSA, sodium azide and glycerol. This conjugation-ready format is designed for use with fluorochromes, metal isotopes, oligonucleotides, and enzymes, which makes them ideal for antibody labelling, functional and cell-based assays, flow-based assays (e.g. mass cytometry) and Multiplex Imaging applications.
Use our conjugation kits for antibody conjugates that are ready-to-use in as little as 20 minutes with 1 minute hands-on-time and 100% antibody recovery: available for fluorescent dyes, HRP, biotin and gold.
Compatibility
This product is compatible with the Maxpar® Antibody Labeling Kit from Fluidigm, without the need for antibody preparation. Maxpar® is a trademark of Fluidigm Canada Inc.
What does low endotoxin mean?
Our low endotoxin, azide-free formats have low endotoxin level (1 EU/mg, determined by the TAL assay) and are free from azide, to achieve consistent experimental results in functional assays.
Properties and storage information
Form
Purification technique
Storage buffer
Shipped at conditions
Appropriate short-term storage conditions
Appropriate long-term storage conditions
Storage information
Supplementary information
This supplementary information is collated from multiple sources and compiled automatically.
Biological function summary
Integrin alpha V plays a pivotal role in cellular processes such as migration proliferation and survival. It participates in the formation of multi-molecular complexes within cellular structures. The integrin av integrins particularly in conjunction with its CD51/CD61 form contribute to the regulation of angiogenesis immune response and wound healing. These functions arise from the integrin’s ability to act as a receptor for numerous ligands including fibrinogen fibronectin and vitronectin.
Pathways
Integrin alpha V is a critical component of the integrin signaling and focal adhesion pathways. These pathways involve a network of interactions that include proteins like focal adhesion kinase (FAK) and Src family kinases. Integrin alpha V’s interaction within these pathways assists in transmitting mechanical signals from the extracellular environment to the intracellular signaling cascades affecting cytoskeleton dynamics and gene expression. The pathway interactions with integrin av also coordinate complex signaling with other receptors and matrix proteins like laminins enhancing cellular communication and response to environmental changes.
