AB216132

Anti-IRAKM antibody [5C3D6] - C-terminal

Be the first to review this product! Submit a review

|

(1 Publication)

Mouse Monoclonal IRAKM antibody. C-terminal. Suitable for WB, ICC/IF and reacts with Human samples. Cited in 1 publication. Immunogen corresponding to Recombinant Fragment Protein within Human IRAK3 aa 450-600.

View Alternative Names

Interleukin-1 receptor-associated kinase 3, IRAK-3, IL-1 receptor-associated kinase M, Inactive IL-1 receptor-associated kinase 3, IRAK-M, IRAK3

3 Images
Immunocytochemistry/ Immunofluorescence - Anti-IRAKM antibody [5C3D6] - C-terminal (AB216132)
  • ICC/IF

Supplier Data

Immunocytochemistry/ Immunofluorescence - Anti-IRAKM antibody [5C3D6] - C-terminal (AB216132)

Immunofluorescent analaysis of A549 cells labeling IRAKM with ab216132 at 1/100 dilution (green). Blue : DRAQ5 fluorescent DNA dye. Red : Actin filaments have been labeled with Alexa Fluor- 555 phalloidin.

Western blot - Anti-IRAKM antibody [5C3D6] - C-terminal (AB216132)
  • WB

Supplier Data

Western blot - Anti-IRAKM antibody [5C3D6] - C-terminal (AB216132)

All lanes:

Western blot - Anti-IRAKM antibody [5C3D6] - C-terminal (ab216132) at 1/500 dilution

Lane 1:

non-transfected HEK293 cell lysate

Lane 2:

Human IRAKM (aa: 454-596)-hIgGFc transfected HEK293 cell lysate

Predicted band size: 68 kDa

false

Western blot - Anti-IRAKM antibody [5C3D6] - C-terminal (AB216132)
  • WB

Supplier Data

Western blot - Anti-IRAKM antibody [5C3D6] - C-terminal (AB216132)

All lanes:

Western blot - Anti-IRAKM antibody [5C3D6] - C-terminal (ab216132) at 1/500 dilution

All lanes:

Human IRAKM (aa: 454-596) recombinant protein

Predicted band size: 68 kDa

false

Key facts

Host species

Mouse

Clonality

Monoclonal

Clone number

5C3D6

Isotype

IgG1

Carrier free

No

Reacts with

Human

Applications

WB, ICC/IF

applications

Immunogen

Recombinant Fragment Protein within Human IRAK3 aa 450-600. The exact immunogen used to generate this antibody is proprietary information.

Q9Y616

style
left-column

Alternative Products

Primary Antibodies

AB97518

Anti-IRAKM antibody

Immunocytochemistry/ Immunofluorescence - Anti-IRAKM antibody (AB97518)

  • 0
  • 0
Primary Antibodies

AB8116

Anti-IRAKM antibody

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-IRAKM antibody (AB8116)

  • 4
  • 3
Primary Antibodies

AB228417

Anti-IRAKM antibody [Y278] - BSA and Azide free

RabMAb|Recombinant|KO Validated

Western blot - Anti-IRAKM antibody [Y278] - BSA and Azide free (AB228417)

  • 0
  • 0
Primary Antibodies

AB32394

Anti-IRAKM antibody [Y278]

RabMAb|Recombinant|KO Validated|Trial Size

Western blot - Anti-IRAKM antibody [Y278] (AB32394)

  • 0
  • 0

Complementary Products

Primary Antibodies

AB238

Anti-IRAK-1 antibody

Immunocytochemistry - Anti-IRAK-1 antibody (AB238)

  • 5
  • 6
Primary Antibodies

AB195045

Anti-PAX6 antibody [EPR15858]

BOND RX™ Validated|RabMAb|Recombinant|20ul selling size

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PAX6 antibody [EPR15858] (AB195045)

  • 5
  • 9
Primary Antibodies

AB52632

Anti-CD11c antibody [EP1347Y] - C-terminal

BOND RX™ Validated|20ul selling size|RabMAb|Recombinant

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-CD11c antibody [EP1347Y] - C-terminal (AB52632)

  • 5
  • 18
Primary Antibodies

AB71916

Anti-EpCAM antibody

BOND RX™ Validated

Immunocytochemistry/ Immunofluorescence - Anti-EpCAM antibody (AB71916)

  • 4
  • 20
style
left-column

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "WB" : {"fullname" : "Western blot", "shortname":"WB"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "WB-species-checked": "testedAndGuaranteed", "WB-species-dilution-info": "1/500 - 1/2000", "WB-species-notes": "<p></p>", "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "1/100 - 1/400", "ICCIF-species-notes": "<p></p>" } } }
style
left-column
style
left-column

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein G
Purification notes
Purified from tissue culture supernatant.
Storage buffer
Preservative: 0.05% Sodium azide Constituents: PBS
Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle
style
left-column

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

The IRAK-M protein also known as IRAKM or interleukin-1 receptor-associated kinase M is a member of the IRAK family and has a molecular mass of approximately 65 kDa. It plays an important role in the immune response regulation. This protein is expressed in monocytes and macrophages but it is also found in other immune cells. Unlike other IRAKs IRAK-M acts as a negative regulator helping to ensure the immune system does not overreact.
Biological function summary

IRAK-M inhibits the signaling pathways that lead to the activation of inflammatory responses. It predominantly affects signaling initiated by toll-like receptors (TLRs) and interleukin-1 receptors (IL-1Rs) preventing excessive inflammatory cytokine production. IRAK-M lacks kinase activity unlike other IRAK family members so it functions as a regulatory molecule rather than participating in kinase-mediated catalysis. It does not form part of a larger complex but interacts directly with other signaling components in these pathways.

Pathways

IRAK-M impacts TLR and IL-1 signaling pathways. These pathways are important in the innate immune system's response to pathogens and inflammation. IRAK-M interacts with proteins such as MyD88 and TNF receptor-associated factor 6 (TRAF6) reducing the downstream production of pro-inflammatory cytokines. This modulation helps to maintain immune system balance and prevent chronic inflammation.

IRAK-M is involved in conditions such as sepsis and autoimmune diseases. In sepsis IRAK-M's alteration can lead to an inadequate immune response influencing the body's ability to control infection. In autoimmune diseases abnormal IRAK-M expression may result in regulatory failures leading to persistent inflammation and tissue damage. IRAK-M's interaction with other proteins like MyD88 suggests its pivotal role in these disorders where misregulated pathways can contribute to disease progression.
style
left-column
style
left-column

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:
style
left-column

Target data

Putative inactive protein kinase which regulates signaling downstream of immune receptors including IL1R and Toll-like receptors (PubMed : 10383454, PubMed : 29686383). Inhibits dissociation of IRAK1 and IRAK4 from the Toll-like receptor signaling complex by either inhibiting the phosphorylation of IRAK1 and IRAK4 or stabilizing the receptor complex (By similarity). Upon IL33-induced lung inflammation, positively regulates expression of IL6, CSF3, CXCL2 and CCL5 mRNAs in dendritic cells (PubMed : 29686383).
See full target information IRAK3
style
left-column

Publications (1)

Recent publications for all applications. Explore the full list and refine your search

International journal of molecular sciences 26: PubMed41009720

2025

p.N370S Mutation Influences the Morphology and Lipid Composition of Extracellular Vesicles in Blood Plasma from Patients with Parkinson's Disease.

Applications

Unspecified application

Species

Unspecified reactive species

Tatiana S Usenko,Alena E Kopytova,Artem D Izyumchenko,Darya G Kulabukhova,Artemiy S Silantyev,Victoria D Kazakova,Katerina S Basharova,Anastasia I Bezrukova,Luiza A Garaeva,Evgeny B Pichkur,Alexandra V Artynyuk,Irina V Miliukhina,Alla A Timofeeva,Valentina V Miroshnikova,Stanislav N Naryzhny,Anton K Emelyanov,Natalya B Zakharzhevskaya,Andrey L Konevega,Tatiana A Shtam,Sofya N Pchelina
