Anti-LAG-3 antibody [EPR4392(2)] - BSA and Azide free

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-LAG-3 antibody [EPR4392(2)] - BSA and Azide free (AB209740)

Clone EPR4392(2) (ab209740) has been successfully conjugated by Abcam. This image was generated using Anti-LAG-3 antibody [EPR4392(2)] (Alexa Fluor® 647). Please refer to ab225278 for protocol details.

IHC image of LAG-3 staining in a section of formalin-fixed paraffin-embedded human Hodgkin's lymphoma*.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6) in a Biocare Medical NxGen pressure cooker using retrieval settings of 110^oC for 20 minutes. Non-specific protein-protein interactions were then blocked in TBS containing 0.025% (v/v) Triton X-100, 0.3M (w/v) glycine and 1% (w/v) BSA for 1h at room temperature.  The section was then incubated overnight at +4°C in TBS containing 0.025% (v/v) Triton X-100 and 1% (w/v) BSA with ab225278 at 1/100 dilution (shown in red) and counterstained using ab195887, Mouse monoclonal to alpha Tubulin (Alexa Fluor^® 488), at 1/250 dilution (shown in green). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Fluoromount^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre.

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-LAG-3 antibody [EPR4392(2)] - BSA and Azide free (AB209740)

Clone EPR4392(2) (ab209740) has been successfully conjugated by Abcam. This image was generated using Anti-LAG-3 antibody [EPR4392(2)] - C-terminal (Alexa Fluor® 488). Please refer to ab225277 for protocol details.

IHC image of LAG-3 - C-terminal staining in a section of formalin-fixed paraffin-embedded human Hodgkin's lymphoma*.

The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6) in a Biocare Medical NxGen pressure cooker using retrieval settings of 110^oC for 20 minutes. Non-specific protein-protein interactions were then blocked in TBS containing 0.025% (v/v) Triton X-100, 0.3M (w/v) glycine and 1% (w/v) BSA for 1h at room temperature. The section was then incubated overnight at +4°C in TBS containing 0.025% (v/v) Triton X-100 and 1% (w/v) BSA with ab225277 at 1/250 dilution (shown in green) and counterstained using ab195884, Rat monoclonal to Tubulin (Alexa Fluor^® 647), at 1/250 dilution (shown in red). Nuclear DNA was labelled with DAPI (shown in blue). The section was then mounted using Fluoromount^®.

Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).

For other IHC staining systems (automated and non-automated), customers should optimize variable parameters such as antigen retrieval conditions, antibody concentrations and incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-LAG-3 antibody [EPR4392(2)] - BSA and Azide free (AB209740)

Immunohistochemical analysis of paraffin embedded Human tonsil tissue labeling LAG-3 with ab180187 at 1/1000.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab180187).

Heat mediated antigen retrieval was performed before commencing with IHC staining protocol.

• IHC-P

Supplier Data

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-LAG-3 antibody [EPR4392(2)] - BSA and Azide free (AB209740)

This IHC data was generated using the same anti-LAG3 antibody clone, EPR4392(2), in a different buffer formulation (cat# ab180187).

Immunohistochemical analysis of paraffin embedded Human Hodgkins lymphoma tissue labeling LAG-3 with ab180187 at 1/1000.

Heat mediated antigen retrieval was performed before commencing with IHC staining protocol.
