Rabbit Recombinant Monoclonal Langerin antibody. Carrier free. Suitable for IHC-P, IHC-Fr, mIHC and reacts with Mouse, Human samples.

Be the first to review this product! Submit a review

Images

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (AB283714), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (AB283714), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (AB283714), expandable thumbnail
  • Immunohistochemistry (Frozen sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (AB283714), expandable thumbnail
  • Immunohistochemistry (Frozen sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (AB283714), expandable thumbnail

Key facts

Isotype

IgG

Host species

Rabbit

Storage buffer

pH: 7.2 - 7.4
Constituents: 100% PBS

Form

Liquid

Clonality

Monoclonal

Immunogen

  • The exact immunogen used to generate this antibody is proprietary information.

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
IPWBIHC-PIHC-FrFlow Cyt (Intra)mIHC
Human
Not recommended
Not recommended
Tested
Expected
Not recommended
Tested
Mouse
Not recommended
Not recommended
Tested
Tested
Not recommended
Tested
Rat
Not recommended
Not recommended
Not recommended
Not recommended
Not recommended
Not recommended

Not recommended
Not recommended

Species

Mouse, Human, Rat

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Mouse, Human, Rat

Dilution info

-

Notes

-

Tested
Tested

Species

Mouse, Human

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Rat

Dilution info

-

Notes

-

Tested
Tested

Species

Mouse

Dilution info

-

Notes

-

Expected
Expected

Species

Human

Dilution info

Use at an assay dependent concentration.

Notes

-

Not recommended
Not recommended

Species

Rat

Dilution info

-

Notes

-

Not recommended
Not recommended

Species

Mouse, Human, Rat

Dilution info

-

Notes

-

Tested
Tested

Species

Human

Dilution info

-

Notes

Perform heat mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Species

Mouse

Dilution info

-

Notes

Perform heat mediated antigen retrieval with Tris/EDTA buffer pH 9.0 before commencing with IHC staining protocol.

Not recommended
Not recommended

Species

Rat

Dilution info

-

Notes

-

Target data

Function

Calcium-dependent lectin displaying mannose-binding specificity. Induces the formation of Birbeck granules (BGs); is a potent regulator of membrane superimposition and zippering. Binds to sulfated as well as mannosylated glycans, keratan sulfate (KS) and beta-glucans. Facilitates uptake of antigens and is involved in the routing and/or processing of antigen for presentation to T cells. Major receptor on primary Langerhans cells for Candida species, Saccharomyces species, and Malassezia furfur. Protects against human immunodeficiency virus-1 (HIV-1) infection. Binds to high-mannose structures present on the envelope glycoprotein which is followed by subsequent targeting of the virus to the Birbeck granules leading to its rapid degradation.

Alternative names

Recommended products

Rabbit Recombinant Monoclonal Langerin antibody. Carrier free. Suitable for IHC-P, IHC-Fr, mIHC and reacts with Mouse, Human samples.

Key facts

Isotype

IgG

Form

Liquid

Clonality

Monoclonal

Immunogen
  • The exact immunogen used to generate this antibody is proprietary information.
Carrier free

Yes

Clone number

EPR24685-12

Purification technique

Affinity purification Protein A

Concentration
Loading...

Storage

Shipped at conditions

Blue Ice

Appropriate short-term storage conditions

+4°C

Appropriate long-term storage conditions

+4°C

Notes

a283714 the carrier-free version of Anti-Langerin antibody [EPR24685-12] ab283686.

Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Our carrier-free antibodies are typically supplied in a PBS-only formulation, purified and free of BSA, sodium azide and glycerol. The carrier-free buffer and high concentration allow for increased conjugation efficiency.

This conjugation-ready format is designed for use with fluorochromes, metal isotopes, oligonucleotides, and enzymes, which makes them ideal for antibody labelling, functional and cell-based assays, flow-based assays (e.g. mass cytometry) and Multiplex Imaging applications.

Use our conjugation kits for antibody conjugates that are ready-to-use in as little as 20 minutes with 1 minute hands-on-time and 100% antibody recovery: available for fluorescent dyes, HRP, biotin and gold.

This product is compatible with the Maxpar® Antibody Labeling Kit from Fluidigm, without the need for antibody preparation. Maxpar® is a trademark of Fluidigm Canada Inc.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.

Activity summary

Langerin also known as CD207 is a type II transmembrane protein involved in the immune response. It weighs approximately 40 kDa and is expressed mainly in Langerhans cells a specialized subset of dendritic cells found in the skin and mucosal tissues. Langerin functions as a C-type lectin receptor with the ability to recognize and internalize glycosylated antigens. This target facilitates the capture and presentation of antigens enhancing the immune surveillance process.

Biological function summary

Langerin supports Langerhans cells in the recognition and processing of pathogens. The protein forms homotrimers enabling it to bind specific mannose-rich glycan structures on pathogens such as viruses and bacteria. Through its endocytic properties Langerin internalizes these antigens into Birbeck granules unique organelles in Langerhans cells promoting antigen processing and presentation to T cells therefore initiating immune responses.

Pathways

Langerin is critical for antigen uptake and processing via the lectin pathway of endocytosis. It interacts with other dendritic cell receptors and influences signaling pathways that enhance immune activation such as the Syk and Raf-1 kinase pathways. Langerin’s ability to internalize antigens connects it with proteins like DC-SIGN and MR which share roles in pathogen recognition and immune modulation.

Associated diseases and disorders

Langerin plays a significant role in conditions like Langerhans Cell Histiocytosis (LCH) and HIV. In LCH abnormal proliferation of Langerhans cells occurs where Langerin expression helps in diagnosing and characterizing LCH lesions. In the context of HIV Langerin interacts with viral particles reducing their ability to infect immune cells. This protein also relates to other immune receptors like CD40 and CD86 which regulate immune responses in associated disorders.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

9 product images

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of paraffin-embedded Human skin tissue labelling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/500 (1.066 µg/mL) followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used. Positive staining on Langerhans cells in human skin. The section was incubated with Anti-Langerin antibody [EPR24685-12] ab283686 for 30 mins at room temperature.The immunostaining was performed on a Leica Biosystems BOND® RX instrument Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used.

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of paraffin-embedded Human lung carcinoma tissue labelling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/500 (1.066 µg/mL) followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used. Positive staining on scattered cells in human lung carcinoma. The section was incubated with Anti-Langerin antibody [EPR24685-12] ab283686 for 30 mins at room temperature.The immunostaining was performed on a Leica Biosystems BOND® RX instrument Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used.

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of paraffin-embedded Human cerebrum tissue labelling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/500 (1.066 µg/mL) followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used. Negative control: no staining on human cerebrum. The section was incubated with Anti-Langerin antibody [EPR24685-12] ab283686 for 30 mins at room temperature.The immunostaining was performed on a Leica Biosystems BOND® RX instrument Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used.

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.

  • Immunohistochemistry (Frozen sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse skin (fresh) tissue labeling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/100 (5.33 μg/mL) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 2 μg/mL dilution (Green). Positive staining on Langerhans cells of mouse skin is observed. The nuclear counterstain was DAPI (Blue).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 2 μg/mL dilution.

  • Immunohistochemistry (Frozen sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Frozen sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of 4% PFA-fixed, 0.2% Triton X-100 permeabilized frozen Mouse thymus (fresh) tissue labeling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/100 (5.33 μg/mL) dilution followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed at 1/1000 2 μg/mL dilution (Green). Positive staining on mouse thymus is observed. The nuclear counterstain was DAPI (Blue).

    Secondary antibody control: Secondary antibody is Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081 Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbedat 1/1000 2 μg/mL dilution.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of paraffin-embedded Mouse skin tissue labelling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/500 (1.066 µg/mL) followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used. Positive staining on Langerhans cells in mouse skin. The section was incubated with Anti-Langerin antibody [EPR24685-12] ab283686 for 30 mins at room temperature.The immunostaining was performed on a Leica Biosystems BOND® RX instrument Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used.

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Immunohistochemical analysis of paraffin-embedded Mouse thymus tissue labelling Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at 1/500 (1.066 µg/mL) followed by a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used. Positive staining on scattered immune cells in mouse thymic medulla. The section was incubated with Anti-Langerin antibody [EPR24685-12] ab283686 for 30 mins at room temperature.The immunostaining was performed on a Leica Biosystems BOND® RX instrument Counterstained with Hematoxylin.

    Secondary antibody only control: Secondary antibody is a ready to use LeicaDS9800 (Bond™ Polymer Refine Detection) was used.

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.

  • Multiplex immunohistochemistry - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Multiplex immunohistochemistry - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Panel A: merged staining of anti-Desmoglein 1/DSG1 (gray; Opal™690), anti-Langerin (green; Opal™520) and anti-TRP2/DCT (red; Opal™570) on human skin.
    Panel B: anti-TRP2/DCT stained on melanocytes.
    Panel C: anti-Langerin stained on Langerhans cells.
    Panel D: anti-Desmoglein 1/DSG1 stained on epidermis.

    The section was incubated in three rounds of staining: in the order of Anti-Desmoglein 1/DSG1 antibody [EPR20382] - BSA and Azide free ab236259, Anti-Langerin antibody [EPR24685-12] ab283686, and Anti-TRP2/DCT antibody [EPR21986] ab221144 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system.

    The immunostaining was performed on a Leica Biosystems BOND® RX instrument with an Opal™ 4-color kit. Image acquisition was performed with Leica SP8 confocal microscope.

  • Multiplex immunohistochemistry - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714), expandable thumbnail

    Multiplex immunohistochemistry - Anti-Langerin antibody [EPR24685-12] - BSA and Azide free (ab283714)

    This data was developed using Anti-Langerin antibody [EPR24685-12] ab283686, the same antibody clone in a different buffer formulation.

    Multiplex immunohistochemistry analysis of formalin/PFA-fixed paraffin-embedded Mouse skin staining of Cytokeratin 1 + Cytokeratin 2e with Anti-Cytokeratin 1 + Cytokeratin 2e antibody [EPR27257-91] ab315228 at a 1/2000 (0.263 μg/ml) dilution, Collagen I with Anti-Collagen I antibody [EPR24331-53] ab270993 and Langerin with Anti-Langerin antibody [EPR24685-12] ab283686 at a 1/1000 dilution followed by a ready to use secondary antibody Opal Polymer HRP Ms + Rb.

    Panel A: merged staining of anti-Cytokeratin 1 + Cytokeratin 2e (green; Opal™520), anti-Collagen I (magenta; Opal™690) and anti-Langerin (gray; Opal™570) on mouse skin.

    Panel B: anti-Cytokeratin 1 + Cytokeratin 2e staining epidermis keratin layer in mouse skin.

    Panel C: anti-Collagen I staining connective tissues in mouse skin.

    Panel D: anti-Langerin staining Langerhans cells in mouse skin.

    Nuclear DNA was labeled with DAPI (shown in blue).

    The section was incubated in three rounds of staining: in the order of Anti-Cytokeratin 1 + Cytokeratin 2e antibody [EPR27257-91] ab315228, Anti-Collagen I antibody [EPR24331-53] ab270993 and Anti-Langerin antibody [EPR24685-12] ab283686 for 30 mins at room temperature. Each round was followed by a separate fluorescent tyramide signal amplification system,

    Heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0, epitope retrieval solution2) for 20 mins.
