Rabbit Recombinant Monoclonal MTCO2 antibody. Carrier free. Suitable for IHC-P, WB, ICC/IF and reacts with Human samples.
Images
![Western blot - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--western-blot-img116712.jpg/_jcr_content/renditions/webp-475.webp "Western blot - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921)")
![Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--immunohistochemistry-formalin-pfa-fixed-paraffin-embedded-sections-img132927.jpg/_jcr_content/renditions/webp-475.webp "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921)")
![Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--immunohistochemistry-formalin-pfa-fixed-paraffin-embedded-sections-img12890.jpg/_jcr_content/renditions/webp-475.webp "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921)")
![Immunocytochemistry/ Immunofluorescence - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--immunocytochemistry-immunofluorescence-img444205.jpg/_jcr_content/renditions/webp-475.webp "Immunocytochemistry/ Immunofluorescence - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (AB247921)")
Key facts
- Isotype
- IgG
- Host species
- Rabbit
- Storage buffer
pH: 7.2 - 7.4
Constituents: PBS- Form
- Liquid
- Clonality
- Monoclonal
Immunogen
- The exact immunogen used to generate this antibody is proprietary information.
Reactivity data
Select an application| IHC-P | Flow Cyt | WB | ICC/IF | |
|---|---|---|---|---|
| Human | Tested | Not recommended | Tested | Tested |
| Mouse | Not recommended | Not recommended | Not recommended | Not recommended |
| Rat | Not recommended | Not recommended | Not recommended | Not recommended |
IHC-P
TestedTested
| Species | Dilution info | Notes |
|---|---|---|
Species Human | Dilution info - | Notes Antigen retrieval is recommended. Heat up to 98 degree C, below boiling, and then let cool for 10-20 min. Perform heat-mediated antigen retrieval via the pressure cooker method before commencing with IHC staining protocol. |
Not recommendedNot recommended
| Species | Dilution info | Notes |
|---|---|---|
Species Mouse, Rat | Dilution info - | Notes - |
Flow Cyt
Not recommendedNot recommended
| Species | Dilution info | Notes |
|---|---|---|
Species Human, Mouse, Rat | Dilution info - | Notes - |
WB
TestedTested
| Species | Dilution info | Notes |
|---|---|---|
Species Human | Dilution info - | Notes - |
Not recommendedNot recommended
| Species | Dilution info | Notes |
|---|---|---|
Species Mouse, Rat | Dilution info - | Notes - |
ICC/IF
TestedTested
| Species | Dilution info | Notes |
|---|---|---|
Species Human | Dilution info - | Notes - |
Not recommendedNot recommended
| Species | Dilution info | Notes |
|---|---|---|
Species Mouse, Rat | Dilution info - | Notes - |
Target data
Function
Component of the cytochrome c oxidase, the last enzyme in the mitochondrial electron transport chain which drives oxidative phosphorylation. The respiratory chain contains 3 multisubunit complexes succinate dehydrogenase (complex II, CII), ubiquinol-cytochrome c oxidoreductase (cytochrome b-c1 complex, complex III, CIII) and cytochrome c oxidase (complex IV, CIV), that cooperate to transfer electrons derived from NADH and succinate to molecular oxygen, creating an electrochemical gradient over the inner membrane that drives transmembrane transport and the ATP synthase. Cytochrome c oxidase is the component of the respiratory chain that catalyzes the reduction of oxygen to water. Electrons originating from reduced cytochrome c in the intermembrane space (IMS) are transferred via the dinuclear copper A center (CU(A)) of subunit 2 and heme A of subunit 1 to the active site in subunit 1, a binuclear center (BNC) formed by heme A3 and copper B (CU(B)). The BNC reduces molecular oxygen to 2 water molecules using 4 electrons from cytochrome c in the IMS and 4 protons from the mitochondrial matrix.
Alternative names
COII, COX2, COXII, MTCO2, MT-CO2, Cytochrome c oxidase subunit 2, Cytochrome c oxidase polypeptide II
Recommended products
Rabbit Recombinant Monoclonal MTCO2 antibody. Carrier free. Suitable for IHC-P, WB, ICC/IF and reacts with Human samples.
Key facts
- Isotype
- IgG
- Host species
- Rabbit
- Storage buffer
pH: 7.2 - 7.4
Constituents: PBS- Form
- Liquid
- Clonality
- Monoclonal
- Immunogen
- The exact immunogen used to generate this antibody is proprietary information.
- Carrier free
- Yes
- Clone number
- EPR3313
- Purification technique
- Affinity purification Protein A
- Concentration
Storage
- Shipped at conditions
- Blue Ice
- Appropriate short-term storage conditions
- +4°C
- Appropriate long-term storage conditions
- +4°C
- Storage information
- Do Not Freeze
Notes
ab247921 is the carrier-free version of Anti-MTCO2 antibody [EPR3313] ab109739.
Mouse, Rat: We have preliminary internal testing data to indicate this antibody may not react with these species. Please contact us for more information.
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.
This product is a recombinant monoclonal antibody, which offers several advantages including:
- - High batch-to-batch consistency and reproducibility
- - Improved sensitivity and specificity
- - Long-term security of supply
- - Animal-free batch production
For more information, read more on recombinant antibodies.
Our carrier-free antibodies are typically supplied in a PBS-only formulation, purified and free of BSA, sodium azide and glycerol. The carrier-free buffer and high concentration allow for increased conjugation efficiency.
This conjugation-ready format is designed for use with fluorochromes, metal isotopes, oligonucleotides, and enzymes, which makes them ideal for antibody labelling, functional and cell-based assays, flow-based assays (e.g. mass cytometry) and Multiplex Imaging applications.
Use our conjugation kits for antibody conjugates that are ready-to-use in as little as 20 minutes with 1 minute hands-on-time and 100% antibody recovery: available for fluorescent dyes, HRP, biotin and gold.
This product is compatible with the Maxpar® Antibody Labeling Kit from Fluidigm, without the need for antibody preparation. Maxpar® is a trademark of Fluidigm Canada Inc.
Supplementary info
- This supplementary information is collated from multiple sources and compiled automatically.
- Activity summary
'MTCO2' also known as 'mt-co2' or 'mtco2e' is a mitochondrial gene that encodes for a component of the cytochrome c oxidase complex referred to as Complex IV in the electron transport chain. The protein plays a mechanical role in facilitating electron transfer within mitochondria an essential process in cellular respiration. MTCO2 is predominantly expressed in tissues with high energy demands such as muscle and neurons. The known mass of the MTCO2 protein is approximately 25 kDa. It sits in the mitochondrial inner membrane where it contributes to creating the proton gradient driving ATP synthesis.
- Biological function summary
MTCO2 (or cytochrome c oxidase subunit II) serves as an important player in aerobic respiration. It is part of the cytochrome c oxidase complex which forms the last enzyme complex of the electron transport chain. As part of this complex MTCO2 facilitates the transfer of electrons from cytochrome c to oxygen resulting in the reduction of oxygen to water. This electron transfer is paired with proton translocation across the mitochondrial membrane which is critical for ATP production.
- Pathways
MTCO2 contributes significantly to the oxidative phosphorylation pathway which is essential for ATP production in eukaryotic cells. It directly interacts with other components of the mitochondrial electron transport chain like cytochrome c and NADH dehydrogenase which are critical for maintaining the flow of electrons and the integrity of the energy production process. Another pathway it is part of is the apoptosis pathway regulated by non-lethal stress conditions where controlled release of cytochrome c can trigger programmed cell death.
- Associated diseases and disorders
MTCO2 mutations and dysfunctions have been linked with mitochondrial disorders especially those affecting energy-demanding tissues leading to conditions such as mitochondrial myopathy and Leber's hereditary optic neuropathy. These disorders result from compromised oxidative phosphorylation leading to inadequate energy supply. The dysfunction of cytochrome c oxidase which contains the MTCO2 subunit is a central aspect of these diseases often tying this protein to other complexes within the electron transport chain that also underpin mitochondrial diseases.
Product promise
Tested
We have tested this species and application combination and it works. It is covered by our product promise.
Expected
We have not tested this specific species and application combination in-house, but expect it will work. It is covered by our product promise.
Predicted
This species and application combination has not been tested, but we predict it will work based on strong homology. However, this combination is not covered by our product promise.
Not recommended
We do not recommend this combination. It is not covered by our product promise.
We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.
In the unlikely event of one of our products not working as expected, you are covered by our product promise.
Full details and terms and conditions can be found here:
Terms & Conditions.
4 product images
![Western blot - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--western-blot-img116712.jpg "Western blot - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)")
Western blot - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)
This data was developed using Anti-MTCO2 antibody [EPR3313] ab109739, the same antibody clone in a different buffer formulation.
All lanes: Western blot - Anti-MTCO2 antibody [EPR3313] (Anti-MTCO2 antibody [EPR3313] ab109739) at 1/1000 dilution
Lane 1: HeLa cell lysate at 10 µg
Lane 2: K562 cell lysate at 10 µg
Lane 3: MCF7 cell lysate at 10 µg
Lane 4: THP1 cell lysate at 10 µg
Predicted band size: 25 kDa
![Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--immunohistochemistry-formalin-pfa-fixed-paraffin-embedded-sections-img132927.jpg "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)")
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)
This data was developed using Anti-MTCO2 antibody [EPR3313] ab109739, the same antibody clone in a different buffer formulation.Anti-MTCO2 antibody [EPR3313] ab109739 at 1/100 dilution staining Cytochrome C oxidase subunit II in paraffin-embedded Human kidney tissue by Immunohistochemistry. Perform heat mediated antigen retrieval via the pressure cooker method before commencing with IHC staining protocol.
![Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--immunohistochemistry-formalin-pfa-fixed-paraffin-embedded-sections-img12890.jpg "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)")
Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)
This data was developed using Anti-MTCO2 antibody [EPR3313] ab109739, the same antibody clone in a different buffer formulation.Anti-MTCO2 antibody [EPR3313] ab109739 at 1/100 dilution staining Cytochrome C oxidase subunit II in paraffin-embedded Human liver tissue by Immunohistochemistry. Perform heat mediated antigen retrieval via the pressure cooker method before commencing with IHC staining protocol.
![Immunocytochemistry/ Immunofluorescence - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921), expandable thumbnail](https://content.abcam.com/products/images/mtco2-antibody-epr3313-bsa-and-azide-free-ab247921--immunocytochemistry-immunofluorescence-img444205.jpg "Immunocytochemistry/ Immunofluorescence - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)")
Immunocytochemistry/ Immunofluorescence - Anti-MTCO2 antibody [EPR3313] - BSA and Azide free (ab247921)
This data was developed using Anti-MTCO2 antibody [EPR3313] ab109739, the same antibody clone in a different buffer formulation.
Immunofluorescent analysis of 4% Paraformaldehyde-fixed, 0.1% TritonX-100 permeabilized HepG2 (human hepatocellular carcinoma epithelial cell) cells labelling Cytochrome C oxidase subunit II with Anti-MTCO2 antibody [EPR3313] ab109739 at 1/1000 dilution, followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed (Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081) secondary antibody at 1/1000 dilution.
Confocal image showing mitochondria staining in HepG2 cell line (shown in green). The counterstain was observed in magenta. Nuclear DNA was labelled with DAPI (shown in blue). Image was taken with a confocal microscope (Leica-Microsystems, TCS SP8).
Anti-COX IV mouse monoclonal antibody - Mitochondrial Marker was used to counterstain COX IV at 1/1000 dilution (Magenta).
The negative controls are as follows:
-ve control 1: Anti-MTCO2 antibody [EPR3313] ab109739 at 1/1000 dilution, followed by Goat Anti-Mouse IgG H&L (Alexa Fluor® 594) (Goat Anti-Mouse IgG H&L (Alexa Fluor® 594) preadsorbed ab150120) secondary at 1/1000 dilution.
-ve control 2: anti-COX IV mouse monoclonal antibody - Mitochondrial Marker antibody at 1/1000 dilution, followed by Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed (Goat Anti-Rabbit IgG H&L (Alexa Fluor® 488) preadsorbed ab150081) secondary at 1/1000 dilution.
Downloads
Product protocols
- Visit the general protocols
- Visit troubleshooting
Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
