AB186470

Anti-NAK/TBK1 antibody [EP611Y] - BSA and Azide free

Be the first to review this product! Submit a review

|

(6 Publications)

Rabbit Recombinant Monoclonal NAK/TBK1 antibody. Carrier free. Suitable for WB, ICC/IF, IHC-P and reacts with Mouse, Rat, Human samples. Cited in 6 publications.

View Alternative Names

NAK, TBK1, Serine/threonine-protein kinase TBK1, NF-kappa-B-activating kinase, T2K, TANK-binding kinase 1

2 Images
Immunocytochemistry/ Immunofluorescence - Anti-NAK/TBK1 antibody [EP611Y] - BSA and Azide free (AB186470)
  • ICC/IF

Unknown

Immunocytochemistry/ Immunofluorescence - Anti-NAK/TBK1 antibody [EP611Y] - BSA and Azide free (AB186470)

Immunocytochemistry/Immunofluorescence analysis of MCF7 (Human breast adenocarcinoma) cells labeling NAK/TBK1 with purified ab40676 at 1/100. Cells were fixed with 4% paraformaldehyde and permeabilized with 0.1% Triton X-100. ab150077, Alexa Fluo®488-conjugated goat anti-rabbit IgG (1/1000) was used as the secondary antibody. Cells were counter-stained with ab195889 Anti-Alpha Tubulin antibody [DM1A] - Microtubule Marker (Alexa Fluor®594) at 1/200. DAPI (blue) was used as a nuclear counterstain. Secondary Only Control : PBS was used instead of the primary antibody as the negative control.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab40676).

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-NAK/TBK1 antibody [EP611Y] - BSA and Azide free (AB186470)
  • IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-NAK/TBK1 antibody [EP611Y] - BSA and Azide free (AB186470)

Immunohistochemical analysis of paraffin-embedded human hepatocellular carcinoma tissue sections labeling NAK/TBK1 with purified ab40676 at a dilution of 1/100 (11.5 μg/ml). ab97051 Goat Anti-Rabbit IgG H&L (HRP) at 1/500 was used as the secondary anitbody. Sections were counterstained with hematoxylin. Antigen retrieval was heat mediated using EDTA Buffer, pH 9.0. PBS was used instead of the primary antibody as the negative control and is shown in the inset.

This data was developed using the same antibody clone in a different buffer formulation containing PBS, BSA, glycerol, and sodium azide (ab40676).

Key facts

Host species

Rabbit

Clonality

Monoclonal

Clone number

EP611Y

Isotype

IgG

Carrier free

Yes

Reacts with

Mouse, Rat, Human

Applications

ICC/IF, IHC-P, WB

applications

Immunogen

The exact immunogen used to generate this antibody is proprietary information.

Specificity

This antibody may have weak cross-reactivity with IKBKE (IKKε).

Reactivity data

{ "title": "Reactivity Data", "filters": { "stats": ["", "Species", "Dilution Info", "Notes"], "tabs": { "all-applications": {"fullname" : "All Applications", "shortname": "All Applications"}, "WB" : {"fullname" : "Western blot", "shortname":"WB"}, "ICCIF" : {"fullname" : "Immunocytochemistry/ Immunofluorescence", "shortname":"ICC/IF"}, "IHCP" : {"fullname" : "Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections)", "shortname":"IHC-P"} }, "product-promise": { "all": "all", "testedAndGuaranteed": "tested", "guaranteed": "expected", "predicted": "predicted", "notRecommended": "not-recommended" } }, "values": { "Human": { "WB-species-checked": "guaranteed", "WB-species-dilution-info": "", "WB-species-notes": "<p></p>", "ICCIF-species-checked": "testedAndGuaranteed", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "<p></p>", "IHCP-species-checked": "testedAndGuaranteed", "IHCP-species-dilution-info": "", "IHCP-species-notes": "<p></p>" }, "Mouse": { "WB-species-checked": "guaranteed", "WB-species-dilution-info": "", "WB-species-notes": "<p></p>", "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "", "IHCP-species-checked": "predicted", "IHCP-species-dilution-info": "", "IHCP-species-notes": "" }, "Rat": { "WB-species-checked": "guaranteed", "WB-species-dilution-info": "", "WB-species-notes": "<p></p>", "ICCIF-species-checked": "predicted", "ICCIF-species-dilution-info": "", "ICCIF-species-notes": "", "IHCP-species-checked": "predicted", "IHCP-species-dilution-info": "", "IHCP-species-notes": "" } } }

Product details

ab186470 is the carrier-free version of ab40676.

Patented technology
Our RabMAb® technology is a patented hybridoma-based technology for making rabbit monoclonal antibodies. For details on our patents, please refer to RabMAb® patents.

What are the advantages of a recombinant monoclonal antibody?
This product is a recombinant monoclonal antibody, which offers several advantages including:

  • - High batch-to-batch consistency and reproducibility
  • - Improved sensitivity and specificity
  • - Long-term security of supply
  • - Animal-free batch production

For more information, read more on recombinant antibodies.

Conjugation ready
Our carrier-free antibodies are typically supplied in a PBS-only formulation, purified and free of BSA, sodium azide and glycerol. This conjugation-ready format is designed for use with fluorochromes, metal isotopes, oligonucleotides, and enzymes, which makes them ideal for antibody labelling, functional and cell-based assays, flow-based assays (e.g. mass cytometry) and Multiplex Imaging applications.

Use our conjugation kits for antibody conjugates that are ready-to-use in as little as 20 minutes with 1 minute hands-on-time and 100% antibody recovery: available for fluorescent dyes, HRP, biotin and gold.

Compatibility
This product is compatible with the Maxpar® Antibody Labeling Kit from Fluidigm, without the need for antibody preparation. Maxpar® is a trademark of Fluidigm Canada Inc.

Properties and storage information

Form
Liquid
Purification technique
Affinity purification Protein A
Storage buffer
pH: 7.2 - 7.4 Constituents: PBS
Shipped at conditions
Blue Ice
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
+4°C
Storage information
Do Not Freeze

Supplementary information

This supplementary information is collated from multiple sources and compiled automatically.

The NAK/TBK1 also known as TANK-binding kinase 1 is a fundamental protein kinase in various cellular processes. It weighs approximately 84 kDa and is expressed in many tissues including lymphoid organs and the brain. NAK acts as a serine/threonine-protein kinase which transfers a phosphate group to specific substrates modulating their function and activity. Phosphorylation by TBK1 initiates several signaling events making it an important regulator in immune responses and inflammatory signaling pathways.
Biological function summary

This kinase plays a significant role in antiviral defense and autophagy. NAK/TBK1 is also involved in innate immune signaling and cell survival. TBK1 forms part of a larger signaling complex interacting with adaptors like TRAF3 and TANK which are important for its proper localization and function. Phospho-NAK its phosphorylated form can activate other molecules driving various downstream immune and stress responses.

Pathways

The protein is integral to the type I interferon signaling pathway and NF-kB pathway. NAK/TBK1 interacts closely with IRF3 a transcription factor important for antiviral activity and plays a role alongside other proteins like IKKε. These interactions permit activation of genes necessary for defense mechanisms against viral pathogens and control of inflammation. In the NF-kB pathway TBK1 helps regulate cellular responses to stress and inflammatory signals.

NAK/TBK1 has associations with amyotrophic lateral sclerosis (ALS) and various cancers. Research shows connections between TBK1 mutations and ALS indicating its importance in neuronal function and health. Additionally aberrations in TBK1 activity contribute to oncogenesis as it can affect cell proliferation and survival. The protein's relation with signaling proteins such as p62/SQSTM1 highlights its diverse role in disease mechanisms making it a potential therapeutic target.

Product protocols

For this product, it's our understanding that no specific protocols are required. You can visit:

Target data

Serine/threonine kinase that plays an essential role in regulating inflammatory responses to foreign agents (PubMed : 10581243, PubMed : 11839743, PubMed : 12692549, PubMed : 12702806, PubMed : 14703513, PubMed : 15367631, PubMed : 15485837, PubMed : 18583960, PubMed : 21138416, PubMed : 23453971, PubMed : 23453972, PubMed : 23746807, PubMed : 25636800, PubMed : 26611359, PubMed : 32404352, PubMed : 34363755, PubMed : 32298923). Following activation of toll-like receptors by viral or bacterial components, associates with TRAF3 and TANK and phosphorylates interferon regulatory factors (IRFs) IRF3 and IRF7 as well as DDX3X (PubMed : 12692549, PubMed : 12702806, PubMed : 14703513, PubMed : 15367631, PubMed : 18583960, PubMed : 25636800). This activity allows subsequent homodimerization and nuclear translocation of the IRFs leading to transcriptional activation of pro-inflammatory and antiviral genes including IFNA and IFNB (PubMed : 12702806, PubMed : 15367631, PubMed : 25636800, PubMed : 32972995). In order to establish such an antiviral state, TBK1 form several different complexes whose composition depends on the type of cell and cellular stimuli (PubMed : 23453971, PubMed : 23453972, PubMed : 23746807). Plays a key role in IRF3 activation : acts by first phosphorylating innate adapter proteins MAVS, STING1 and TICAM1 on their pLxIS motif, leading to recruitment of IRF3, thereby licensing IRF3 for phosphorylation by TBK1 (PubMed : 25636800, PubMed : 30842653, PubMed : 37926288). Phosphorylated IRF3 dissociates from the adapter proteins, dimerizes, and then enters the nucleus to induce expression of interferons (PubMed : 25636800). Thus, several scaffolding molecules including FADD, TRADD, MAVS, AZI2, TANK or TBKBP1/SINTBAD can be recruited to the TBK1-containing-complexes (PubMed : 21931631). Under particular conditions, functions as a NF-kappa-B effector by phosphorylating NF-kappa-B inhibitor alpha/NFKBIA, IKBKB or RELA to translocate NF-Kappa-B to the nucleus (PubMed : 10783893, PubMed : 15489227). Restricts bacterial proliferation by phosphorylating the autophagy receptor OPTN/Optineurin on 'Ser-177', thus enhancing LC3 binding affinity and antibacterial autophagy (PubMed : 21617041). Phosphorylates SMCR8 component of the C9orf72-SMCR8 complex, promoting autophagosome maturation (PubMed : 27103069). Phosphorylates ATG8 proteins MAP1LC3C and GABARAPL2, thereby preventing their delipidation and premature removal from nascent autophagosomes (PubMed : 31709703). Seems to play a role in energy balance regulation by sustaining a state of chronic, low-grade inflammation in obesity, which leads to a negative impact on insulin sensitivity (By similarity). Attenuates retroviral budding by phosphorylating the endosomal sorting complex required for transport-I (ESCRT-I) subunit VPS37C (PubMed : 21270402). Phosphorylates Borna disease virus (BDV) P protein (PubMed : 16155125). Plays an essential role in the TLR3- and IFN-dependent control of herpes virus HSV-1 and HSV-2 infections in the central nervous system (PubMed : 22851595). Acts both as a positive and negative regulator of the mTORC1 complex, depending on the context : activates mTORC1 in response to growth factors by catalyzing phosphorylation of MTOR, while it limits the mTORC1 complex by promoting phosphorylation of RPTOR (PubMed : 29150432, PubMed : 31530866). Acts as a positive regulator of the mTORC2 complex by mediating phosphorylation of MTOR, leading to increased phosphorylation and activation of AKT1 (By similarity). Phosphorylates and activates AKT1 (PubMed : 21464307). Involved in the regulation of TNF-induced RIPK1-mediated cell death, probably acting via CYLD phosphorylation that in turn controls RIPK1 ubiquitination status (PubMed : 34363755). Also participates in the differentiation of T follicular regulatory cells together with the receptor ICOS (PubMed : 27135603).
See full target information TBK1

Publications (6)

Recent publications for all applications. Explore the full list and refine your search

Cell 155:688-98 PubMed24119841

2013

Cyclic dinucleotides trigger ULK1 (ATG1) phosphorylation of STING to prevent sustained innate immune signaling.

Applications

Unspecified application

Species

Unspecified reactive species

Hiroyasu Konno,Keiko Konno,Glen N Barber

Journal of immunology (Baltimore, Md. : 1950) 189:4630-9 PubMed23028052

2012

Endoplasmic reticulum stress regulates the innate immunity critical transcription factor IRF3.

Applications

Unspecified application

Species

Unspecified reactive species

Yi-Ping Liu,Ling Zeng,Austin Tian,Ashley Bomkamp,Daniel Rivera,Delia Gutman,Glen N Barber,Julie K Olson,Judith A Smith

Journal of neuroinflammation 9:39 PubMed22361049

2012

Microglial TIR-domain-containing adapter-inducing interferon-β (TRIF) deficiency promotes retinal ganglion cell survival and axon regeneration via nuclear factor-κB.

Applications

WB

Species

Unspecified reactive species

Sen Lin,Yajie Liang,Jiqiang Zhang,Chen Bian,Hongli Zhou,Qiang Guo,Ying Xiong,Shurong Li,Bingyin Su

PLoS pathogens 6:e1000778 PubMed20174559

2010

Optineurin negatively regulates the induction of IFNbeta in response to RNA virus infection.

Applications

Unspecified application

Species

Unspecified reactive species

Jamel Mankouri,Rennos Fragkoudis,Kathryn H Richards,Laura F Wetherill,Mark Harris,Alain Kohl,Richard M Elliott,Andrew Macdonald

Proceedings of the National Academy of Sciences of the United States of America 107:264-9 PubMed20018759

2009

miR-221 overexpression contributes to liver tumorigenesis.

Applications

WB

Species

Human

Pascal Pineau,Stefano Volinia,Katherine McJunkin,Agnès Marchio,Carlo Battiston,Benoît Terris,Vincenzo Mazzaferro,Scott W Lowe,Carlo M Croce,Anne Dejean

Nature 461:788-92 PubMed19776740

2009

STING regulates intracellular DNA-mediated, type I interferon-dependent innate immunity.

Applications

ICC/IF

Species

Mouse

Hiroki Ishikawa,Zhe Ma,Glen N Barber
View all publications

Product promise

We are committed to supporting your work with high-quality reagents, and we're here for you every step of the way. In the unlikely event that one of our products does not perform as expected, you're protected by our Product Promise.
For full details, please see our Terms & Conditions

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
