Anti-NAP1L1 antibody

• ICC/IF

Unknown

Immunocytochemistry/ Immunofluorescence - Anti-NAP1L1 antibody (AB21630)

ICC/IF image of ab21630 stained A431 cells. The cells were 4% formaldehyde fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab21630, 5µg/ml) overnight at +4°C. The secondary antibody (green) was ab96899, DyLight® 488 goat anti-rabbit IgG (H+L) used at a 1/250 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM.

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-NAP1L1 antibody (AB21630)

IHC image of ab21630 staining in human skin formalin fixed paraffin embedded tissue section, performed on a Leica Bond^TM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab21630, 5µg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

• WB

Unknown

Western blot - Anti-NAP1L1 antibody (AB21630)

For each lane, U2OS cells, either treated or not treated with ionizing radiation, were scraped from a 60 mm dish and added to 75μl of 2X Laemmli buffer. 20μl of these samples were loaded into each lane. ab21630 recognizes a major band of approximately 52 kDa corresponding closely in size to NAP1L1.

Lanes 1 - 2:

Western blot - Anti-NAP1L1 antibody (ab21630) at 1/1000 dilution

Lanes 3 - 4:

Western blot - Anti-NAP1L1 antibody (ab21630) at 1/500 dilution

Lanes 5 - 6:

Western blot - Anti-NAP1L1 antibody (ab21630) at 1/250 dilution

Lanes 1, 3 and 5:

U2OS cell lysate

Lanes 2, 4 and 6:

U2OS cell lysate treated with ionizing radiation

Predicted band size: 45 kDa

Observed band size: 49 kDa,52 kDa

false

• WB

Unknown

Western blot - Anti-NAP1L1 antibody (AB21630)

ab21630 recognizes a major band of approximately 52 kDa corresponding closely in size to NAP1L1. This band is competed away by the addition of the immunizing peptide, suggesting that this is a specific interaction.

All lanes:

Western blot - Anti-NAP1L1 antibody (ab21630) at 1 µg/mL

Lane 1:

HeLa whole cell lysate at 20 µg

Lane 2:

A431 whole cell lysate at 20 µg

Lane 3:

HEK293 whole cell lysate at 20 µg

Lane 4:

HeLa whole cell lysate at 20 µg with Human NAP1L1 peptide (<a href='/en-us/products/unavailable/human-nap1l1-peptide-ab22417'>ab22417</a>)

Lane 5:

A431 whole cell lysate with Human NAP1L1 peptide (<a href='/en-us/products/unavailable/human-nap1l1-peptide-ab22417'>ab22417</a>)

Lane 6:

HEK293 whole cell lysate at 20 µg with Human NAP1L1 peptide (<a href='/en-us/products/unavailable/human-nap1l1-peptide-ab22417'>ab22417</a>)

Secondary

All lanes:

Alexa fluor goat polyclonal to rabbit IgG at 1/10000 dilution

Predicted band size: 45 kDa

Observed band size: 35 kDa,49 kDa,52 kDa
