Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10]

• IHC-P

Unknown

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10] (AB140307)

Paraffin-embedded human ovary adenocarcinoma tissue stained for PI 3 Kinase catalytic subunit gamma/PI3K-gamma using ab140307 at 1/150 dilution in immunohistochemical analysis.

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10] (AB140307)

Negative control image : IHC image of PI3K gamma staining in a section of formalin-fixed paraffin-embedded normal human liver* performed on a Leica Biosystems BOND® RX instrument using the standard protocol. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20mins. The section was then incubated with ab140307, 10ug/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX. The inset secondary-only control image is taken from an identical assay without primary antibody.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

• IHC-P

Lab

Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10] (AB140307)

IHC image of PI3K gamma staining in a section of formalin-fixed paraffin-embedded normal human pancreas* performed on a Leica Biosystems BOND® RX instrument using the standard protocol. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (pH6, epitope retrieval solution 1) for 20mins. The section was then incubated with ab140307, 10ug/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX. The inset secondary-only control image is taken from an identical assay without primary antibody.

For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

*Tissue obtained from the Human Research Tissue Bank, supported by the NIHR Cambridge Biomedical Research Centre

• ICC/IF

Unknown

Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10] (AB140307)

COS-7 (african green monkey kidney fibroblast-like cell line) cells transiently transfected by pCMV6-ENTRY PI 3 Kinase catalytic subunit gamma/PI3K-gamma cDNA, labelling PI 3 Kinase catalytic subunit gamma/PI3K-gamma (green) with ab140307 at 1/100 dilution in ICC/IF.

• WB

Unknown

Western blot - Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10] (AB140307)

All lanes:

Western blot - Anti-PI 3 Kinase catalytic subunit gamma/PI3K-gamma antibody [OTI4G10] (ab140307) at 1/2000 dilution

Lane 1:

HEK-293T (human epithelial cell line from embryonic kidney transformed with large T antigen) cell lysate transfected with pCMV6-ENTRY control cDNA at 5 µg

Lane 2:

HEK-293T cell lysate transfected with pCMV6-ENTRY PI 3 Kinase catalytic subunit gamma/PI3K-gamma cDNA at 5 µg

Predicted band size: 126 kDa
