Mouse Monoclonal PI 3 Kinase p85 alpha antibody. Suitable for WB, ICC/IF, IHC-P and reacts with Human samples. Cited in 177 publications. Immunogen corresponding to Recombinant Fragment Protein within Human PIK3R1.


Images

Western blot - Anti-PI 3 Kinase p85 alpha antibody [M253] (AB86714), expandable thumbnail
  • Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase p85 alpha antibody [M253] (AB86714), expandable thumbnail
  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PI 3 Kinase p85 alpha antibody [M253] (AB86714), expandable thumbnail
  • Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase p85 alpha antibody [M253] (AB86714), expandable thumbnail

Publications

Key facts

Isotype
IgG2a
Host species
Mouse
Storage buffer

Preservative: 0.05% Sodium azide
Constituents: 50% Glycerol (glycerin, glycerine), 49% PBS, 0.1% BSA

Form
Liquid
Clonality
Monoclonal

Immunogen

  • Recombinant Fragment Protein within Human PIK3R1. The exact immunogen used to generate this antibody is proprietary information. Database link P27986

Abcam Recommends

Reactivity data

Select an application
Product promiseTestedExpectedPredictedNot recommended
WBICC/IFIHC-P
Human
Tested
Tested
Tested
Mouse
Predicted
Predicted
Predicted
Rat
Predicted
Predicted
Predicted
Chicken
Predicted
Predicted
Predicted

Tested
Tested

Species
Human
Dilution info
1/1000
Notes

-

Predicted
Predicted

Species
Mouse, Rat, Chicken
Dilution info
-
Notes

-

Tested
Tested

Species
Human
Dilution info
-
Notes

-

Predicted
Predicted

Species
Mouse, Rat, Chicken
Dilution info
-
Notes

-

Tested
Tested

Species
Human
Dilution info
5 µg/mL
Notes

-

Predicted
Predicted

Species
Mouse, Rat, Chicken
Dilution info
-
Notes

-

Associated Products

Select an associated product type

7 products for Alternative Product

Target data

Function

Binds to activated (phosphorylated) protein-Tyr kinases, through its SH2 domain, and acts as an adapter, mediating the association of the p110 catalytic unit to the plasma membrane. Necessary for the insulin-stimulated increase in glucose uptake and glycogen synthesis in insulin-sensitive tissues. Plays an important role in signaling in response to FGFR1, FGFR2, FGFR3, FGFR4, KITLG/SCF, KIT, PDGFRA and PDGFRB. Likewise, plays a role in ITGB2 signaling (PubMed:17626883, PubMed:19805105, PubMed:7518429). Modulates the cellular response to ER stress by promoting nuclear translocation of XBP1 isoform 2 in a ER stress- and/or insulin-dependent manner during metabolic overloading in the liver and hence plays a role in glucose tolerance improvement (PubMed:20348923).

Alternative names

GRB1, PIK3R1, Phosphatidylinositol 3-kinase regulatory subunit alpha, PI3-kinase regulatory subunit alpha, PI3K regulatory subunit alpha, PtdIns-3-kinase regulatory subunit alpha, Phosphatidylinositol 3-kinase 85 kDa regulatory subunit alpha, PI3-kinase subunit p85-alpha, PtdIns-3-kinase regulatory subunit p85-alpha

Recommended products

Mouse Monoclonal PI 3 Kinase p85 alpha antibody. Suitable for WB, ICC/IF, IHC-P and reacts with Human samples. Cited in 177 publications. Immunogen corresponding to Recombinant Fragment Protein within Human PIK3R1.

Key facts

Isotype
IgG2a
Form
Liquid
Clonality
Monoclonal
Immunogen
  • Recombinant Fragment Protein within Human PIK3R1. The exact immunogen used to generate this antibody is proprietary information. Database link P27986
Clone number
M253
Purification technique
Affinity purification Protein A
Concentration
Loading...

Storage

Shipped at conditions
Blue Ice
Appropriate short-term storage duration
1-2 weeks
Appropriate short-term storage conditions
+4°C
Appropriate long-term storage conditions
-20°C
Aliquoting information
Upon delivery aliquot
Storage information
Avoid freeze / thaw cycle

Notes

Phosphoinositide 3-kinase (PI3K) phosphorylates phosphatidylinositol (PI), PI-4-phosphate and PI-4,5-bisphosphate to catalyze the production of PI-3,4,5-triphosphate. Growth factors and hormones activate PI 3 Kinase to coordinate various cellular events, such as cell growth, cell cycle entry, cell migration and cell survival.

Supplementary info

This supplementary information is collated from multiple sources and compiled automatically.
Activity summary

PI 3 Kinase p85 alpha also known as PI3KR1 or phospho PI3K is a regulatory subunit of phosphoinositide 3-kinase (PI3K) that plays a fundamental role in various signaling pathways. The p85 protein has a molecular weight of approximately 85 kDa. This protein is widely expressed in many cell types facilitating essential cellular functions by forming a heterodimer with the class I PI3K catalytic subunit often implicated in regulating lipid signaling pathways.

Biological function summary

P85 alpha modulates intracellular signaling by interacting with other proteins in a complex formation with catalytic subunit p110. This interaction enables the initiation of downstream signaling cascades controlling cell growth proliferation and survival. PI 3 kinase activity mediated by p85 alpha is integral to cellular homeostasis and metabolism helping to execute cellular responses to a variety of growth factors and hormones.

Pathways

PI 3 Kinase p85 alpha integrates into two principal signaling networks: the PI3K-Akt and mTOR pathways. These pathways are instrumental for regulating anabolic processes and cell survival. The p85 form of PI3K interacts with additional proteins such as Akt and mTOR coordinating cellular energy balance promoting protein synthesis and inhibiting apoptosis. Through these interactions the protein ensures that cells respond accurately to nutritional and stress signals.

Associated diseases and disorders

Alterations in PI 3 Kinase p85 alpha function have been linked to cancer and type 2 diabetes. Aberrant signaling involving PI3K-Akt-mTOR pathways due to mutations in PI3KR1 can contribute to tumor progression and chemoresistance. Moreover dysfunction of this pathway affects insulin signaling connecting p85 alpha to diabetic pathologies. Proteins such as IRS-1 (insulin receptor substrate 1) act alongside p85 alpha in mediating these disease-associated processes emphasizing its importance in maintaining physiological balance.

Product promise

We are dedicated to supporting your work with high quality reagents and we are here for you every step of the way should you need us.

In the unlikely event of one of our products not working as expected, you are covered by our product promise.

Full details and terms and conditions can be found here:
Terms & Conditions.

4 product images

  • Western blot - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714), expandable thumbnail

    Western blot - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714)

    Lane 1: Western blot - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714) at 1/1000 dilution

    Lane 2: Western blot - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714) at 1/2000 dilution

    Lane 3: Western blot - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714) at 1/4000 dilution

    All lanes: A431 cell lysate

    Predicted band size: 83 kDa

    Observed band size: 85 kDa

  • Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714)

    Immunocytochemical labeling of PI 3 Kinase p85 in aldehyde-fixed and NP-40-permeabilized A431 cells. The cells were labeled with ab86714, then the antibody was detected using appropriate secondary antibody conjugated to DyLight® 594.

  • Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714), expandable thumbnail

    Immunohistochemistry (Formalin/PFA-fixed paraffin-embedded sections) - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714)

    IHC image of PI 3 Kinase p85 staining in Human skeletal muscle formalin fixed paraffin embedded tissue section, performed on a Leica BondTM system using the standard protocol F. The section was pre-treated using heat mediated antigen retrieval with sodium citrate buffer (100x Citrate Buffer pH 6.0 ab64236) (pH6, epitope retrieval solution 1) for 20 mins. The section was then incubated with ab86714, 5μg/ml, for 15 mins at room temperature and detected using an HRP conjugated compact polymer system. DAB was used as the chromogen. The section was then counterstained with haematoxylin and mounted with DPX.

    For other IHC staining systems (automated and non-automated) customers should optimize variable parameters such as antigen retrieval conditions, primary antibody concentration and antibody incubation times.

  • Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714), expandable thumbnail

    Immunocytochemistry/ Immunofluorescence - Anti-PI 3 Kinase p85 alpha antibody [M253] (ab86714)

    ICC/IF image of ab86714 stained SKNSH cells. The cells were 4% PFA fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum (Normal Goat Serum ab7481) / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab86714, 5μg/ml) overnight at +4°C. The secondary antibody (green) was Goat Anti-Mouse IgG H&L (DyLight® 488) preadsorbed ab96879, DyLight® 488 goat anti-mouse IgG (H+L) (Goat Anti-Mouse IgG H&L (DyLight® 488) ab96871) used at a 1/250 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43μM.

Downloads

Product protocols

For this product, it's our understanding that no specific protocols are required. You can:

Please note: All products are 'FOR RESEARCH USE ONLY. NOT FOR USE IN DIAGNOSTIC OR THERAPEUTIC PROCEDURES'.
